AAVIX AGT310 Owner's Manual

2x9v smart metal detector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SMART METAL DETECTOR 2 X 9 V
A A V I X D E T E C T O R S
Read this manual carefully. Learn how to operate and maintain your product properly to avoid
injury and product damage. You are responsible for operating the product properly & safely.
WARNING:
FOR SAFE OPERATION, READ
OWNER'S MANUAL PRIOR TO USE.
OWNER'S MANUAL
WORK SAFELY WITH TOOLS BY
WEARING SAFETY GLASSES!
AGT310
FOR SERVICE OR SUPPORT
PLEASE CALL TOLL FREE:
1-866-591-8921

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGT310 and is the answer not in the manual?

Questions and answers

Related Manuals for AAVIX AGT310

Summary of Contents for AAVIX AGT310

  • Page 1 A A V I X D E T E C T O R S OWNER’S MANUAL AGT310 Read this manual carefully. Learn how to operate and maintain your product properly to avoid injury and product damage. You are responsible for operating the product properly & safely.
  • Page 2 FEATURES With your AGT310 metal detector, you can hunt for coins, relics, jewelry, gold, and silver just about anywhere. The detector comes with high sensitivity and strong ability of discrimination. It is versatile and easy to use. The detector’s features include: Display: Show the probable type of metal, the depth of the target, range of DISC&NOTCH, the level of SENS, and battery...

  • Page 3: Assembling The Detector

    PREPARATION ASSEMBLING THE DETECTOR Assembling your detector is easy and requires no special tools. Just follow these steps. 1. Insert the latch on the top of the handle into the assembly hole on the bottom of the control box. Then slightly push the control box in the direction of IN marked on the handle to fix the latch in place.

  • Page 4: Installing The Batteries

    upright with the detector in your hand, and the search coil is level with the ground with your arm relaxed at your side. Then counter-clockwise rotate to tighten the lock nut. 4. Wind the search coil cable around the stem. Insert the search coil’s plug into the search coil jack on the detector’s control housing.

  • Page 5: Using Headphones

    Dispose of old batteries promptly and properly. Never bury or burn them. Cautions: Use only fresh alkaline batteries of required size. Do not mix old and new batteries or different types of batteries. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.

  • Page 6: Lcd Display

    comfortable level. Do not listen at extremely high volume levels. Extended high volume listening can lead to permanent hearing loss. Do not wear headphones while operating your detector near high-traffic areas. Pay attention to traffic safety. INSTRUCTIONS FOR CONTROL PANEL Volume / Power switch Control buttons...

  • Page 7: Control Buttons

    Target Indicator DISC / NOTCH Indicator SENS/DEPTH Indicator DISC Numeric Indicator Low BATT Indicator Target Numeric Indicator 4. CONTROL BUTTONS SENS: Press SENS then + or – to increase or decrease the sensitivity. LCD will display the current setting of sensitivity. If the target depth is beyond the max.
  • Page 8 detector sounds low , medium, high tones respectively. After about 2 seconds the detector enters into stand-by state. At this time the default mode is DISC. LCD displays DISC of 00 and SENS of 6 bars. 2. TESTING AND USING THE DETECTOR To learn how the detector reacts to different metals, you should test it before you use it the first time.
  • Page 9 be notched. The cursor above the selected target will flash. Press NOTCH again, the target name below the cursor will disappear. It means this target will be notched during the detection and the detector will have no reaction to the notched target. If you want to pick up the target notched, simply press NOTCH again.

  • Page 10: Target Indications

    6. Slowly sweep a sample of the material you want the detector to find (such as a gold ring or a coin) 2-3 inches or more above the face of the search coil. When the detector detects any metal, it sounds a tone and the cursor above the target name will light.
  • Page 11 reference only. 2. Types of target IRON: It indicates that the target is probably iron. 5¢: It indicates that the target is probably 5¢ or a nickel. Some small gold rings might register within this range. P-TAB: It indicates that the target is probably a pull tab of an aluminum can.

  • Page 12: Outdoor Testing And Use

    OUTDOOR TESTING AND USE 1. Rotate the VOLUME switch clockwise away from OFF to power on the detector. 2. Follow the steps of 2 described in section of Indoor Testing and Use to set the operating mode. 3. Find an area on the ground outside where there is no metal. 4.
  • Page 13 with the ground If the detector detects the item, it sounds a tone, and the cursor above the target name will light. Also LCD displays the numeric range of target as well as the depth (signal strength). If the detector does not detect the item, make sure that the mode is set correctly for the type of metal you’re searching for.
  • Page 14 position, or the detector will receive interference and false signal from broadcast antenna and other electronic lines. The detector will have unstable and irregular indications. Pinpointing The Target Accurately pinpointing a target makes digging it up easier. But it takes practice. We suggest you practice finding sample on your own property before you search other locations.

  • Page 15: Care And Maintenance

    The depth of the target. The level of oxidization of the target. The size of the target. Electro-magnetic and electrical interference surrounding the target. In area of highly mineralized ground or wet sand, the detector will sound even if there is no metal. In this case, you can lower the sensitivity or increase the DISC numeric value.

  • Page 16: Warranty

    Selective collection of household electric and electronic waste WARRANTY AAVIX product carries a limited one (1) year warranty against defects in workmanship and materials from date of purchase under normal household use. If product is to be used for commercial, industrial or rental use, a 30 days limited warranty will apply.
