- Page 1 INSTALLATION INSTRUCTIONS Dishwasher FD24DI...
-
Page 2: Before You Begin
Before You Begin Read these instructions completely and carefully. IMPORTANT The dishwasher MUST be installed to allow for future removal from the enclosure if service is required. If you received a damaged dishwasher you should immediately contact your dealer or builder. IMPORTANT Observe all governing codes and ordinances. -
Page 3: Installation Preparation
Installation Preparation Parts Supplied • Four flat head wood screws to secure dishwasher to underside of countertop (in literature package) 4 Wood Screws Screw Type Drain Hose 2 Top • Screw type hose clamps and one Hose Clamp Mounting Clips drainhose. - Page 4 Installation Preparation Tools You Will Need: • Phillips head screwdriver Phillips Head 6” Adjustable Level • 6” Adjustable wrench Screwdriver Wrench • Level • Carpenter’s square • Measuring tape Carpenter’s Measuring Tape Safety Glasses • Safety glasses Square • Flashlight •...
-
Page 5: Cabinet Preparation
Installation Preparation • The dishwasher must be installed so that drain hose is no more than 10 feet in length for proper drainage. • The dishwasher must be fully enclosed on the top, sides and back, and must not support any part of the enclosure. Countertop CLEARANCES: When installed into a corner, allow 2”... - Page 6 Installation Preparation Prepare Electrical Wiring WARNING FOR PERSONAL SAFETY: Re- move house fuse or open circuit breaker before beginning instal- lation. Do not use an extension cord or adapter plug with this appliance. Electrical Requirements • This appliance must be supplied with 120V, 60 Hz., and connected to an individual properly grounded branch circuit, protected by a 15 or 20 ampere circuit breaker or time delay fuse.
-
Page 7: Installation Instructions
Installation Instructions CAUTION PREPARE HOT WATER LINE • The line may enter from either side, rear or floor within the shaded area shown in Figure F. Opening the door will cause • The line may pass through the same hole as the the dishwasher to tip forward. - Page 8 Installation Instructions STEP 3: Remove Toekick STEP 2: Adjust Leveling Legs • Remove the 2 toekick screws. Lift off the 1 piece • Move the dishwasher close to the installation location toekick. and lay it on its back. • Measure installation height and dishwasher height. Extend leveling legs out from the dishwasher base, 1/4”...
- Page 9 Installation Instructions STEP 6: Install Drain Hose STEP 8: Slide Dishwasher Partially into Cabinet • Install the screw type hose clamps to the drain hose. DO NOT PUSH AGAINST FRONT PANEL WITH • Install the drain hose to the drain hose installation KNEES.
- Page 10 Installation Instructions STEP 9: Position Dishwasher Under Countertop • Check to be sure that wires are secure under the dishwasher and not pinched or in contact with door springs or other dishwasher components. TIP: Check tub insulation blanket, if equipped. It should be positioned so it is not bunched up or inter- fering with door springs.
- Page 11 Installation Instructions STEP 11: Secure Dishwasher to the Countertop For countertops made of wood or that will not be damaged by drilling, use Method 1. For countertops made of granite, marble, or other materials that could be damadged by drilling, use Method 2. Important Drive screws straight and flush.
- Page 12 Installation Instructions STEP 13: Connect Drain Line Drain Line Installation FOLLOW ALL LOCAL CODES AND ORDINANCES. FOLLOW ALL LOCAL CODES AND ORDINANCES. The drain hose molded end will fi t 5/8”, 3/4” or 1” diam- • Connect drain line to air gap, waste tee or disposer eter connections on the air gap, waste tee or disposer.
- Page 13 Installation Instructions STEP 14: Connect Power Supply STEP 15: Pre-Test Checklist Review this list after installing your dishwasher to avoid SKIP THIS STEP IF EQUIPPED WITH POWER CORD. Verify that power is turned off at the source. charges for a service call that is not covered by your warranty.
- Page 14 Installation Instructions STEP 16: Dishwasher Wet Test STEP 17: Replace Toe Kick • Turn on power supply (or plug power cord into outlet, if equipped). • T urn on your dishwasher (please refer to the Own- er’s Manual for instructions). •...
