- Page 1 USE + CARE MANUAL Dishwasher FD24DI...
-
Page 2: Table Of Contents
Congratulations on your recent Forza purchase! Before you begin using your new Forza product, please take a moment to review the Use + Care Manual. You will find the answers to all of your questions as well as some very important safety information. -
Page 3: Important Safety Instructions
Important Safety Instruction WARNING: For your safety, please follow the information in this manual to minimize the risk of fire, explosion, electric shock, and to help prevent property damage or personal injury. Proper Installation Please install your dishwasher properly. Follow the installation guide. •... -
Page 4: Features Of Your New Dishwasher
Features of Your New Dishwasher Specifications Capacity 16 place settings Dimension 606 x 623 x 857 mm (W x D x H) Power Supply 120 volts, 60Hz Rated Power Usage Wash motor 50 W Heater 840 W Water Feed Pressure 20 ~ 120 psi (138 ~ 828kPa) Top Cutlery Rack Detergent Dispenser... -
Page 5: Filter System
Features of Your New Dishwasher Features Filter System Your dishwasher has a multiple Filter System. In the System there are four filter-meshes. It can separate soiled water and clean water in different chambers. The multiple filter system helps your dishwasher to get better performance with less water and less energy. -
Page 6: How Your Dishwasher Cleans
Features of Your New Dishwasher How Your Dishwasher Cleans Your dishwasher cleans by spraying a mixture of hot water and detergent through the spray arms against soiled surfaces. The dishwasher fills with water covering the filer area. Water is then pumped through the multiple filter and spray arms. Separated soil particles go down the drain as the water is pumped out and replaced with clean water. -
Page 7: Control Panel
Features of Your New Dishwasher Control Panel STEAM WASH NOTE For use with heavily soiled items, the STEAM WASH option adds 30 minutes to the cycle time. The option is available This model is a built-in model. All the buttons can with the cycles of “POTS &... - Page 8 Operating Dishwasher DELAY START/CANCEL To delay the start of a selected cycle, open the door, press Open the door, select the wash cycle you desire and the the Delay Start pad until the desired delay time shows in the indicator light will turn on. Press the Start/Cancel button and LED display screen.
- Page 9 Operating Dishwasher Cycle progress indicator Located on the right side of the front of the dishwasher, these lights indicate how far along the current wash cycle is while the dishwasher is running. Wash Clean When the dishwasher is in a wash or rinse portion of a cycle, the Wash lights are Wash illuminated.
-
Page 10: Cycle Chart
Operating Dishwasher Satus Window NOTE H:01-H:24 If the Delay Start option is selected, the number of delay start hours 1. Your dishwasher has the top control panel. shows in the Status Window. The door should be opened first if you want to operate the machine. -
Page 11: Preparing And Loading Dishes
Preparing and Loading Dishes Adjustable Upper Rack The upper rack height can be easily adjusted to accommodate loading taller dishes in either rack. To accommodate taller dishes in the bottom rack, there are 2 positions available: Lift the rack for upper position Press the handle up to lower the rack Upper Rack The upper rack in the upper position... -
Page 12: Loading The Upper Rack
Preparing and Loading Dishes Loading Cutlery rack Cutlery should be placed in the cutlery rack separatelyfrom each other in the appropriate positions, and do make sure the utensils do not nest together, this maycause bad performance. For a top quality cleaning, place the silverware in the basket making sure that: •... - Page 13 Preparing and Loading Dishes Bottom Rack 8 Place Settings Cutlery Rack 8 Place Settings Upper Rack 8 Place Settings Cutlery Rack 12 Place Settings Upper Rack 12 Place Settings Bottom Rack 12 Place Settings Cutlery Rack 14 Place Settings Upper Rack 14 Place Settings Bottom Rack 14 Place Settings Cutlery Rack 16 Place Settings Upper Rack 16 Place Settings...
-
Page 14: Loading The Silverware Basket
Preparing and Loading Dishes Loading the Silverware Basket The silverware basket could be divided into three separate modules that can be used in both upper and lower racks. • Spoons • Knives • Salad forks • Forks • Large spoons •... -
Page 15: Filling The Detergent Dispenser
Preparing and Loading Dishes Filling the Rinse Aid Dispenser WARNING: Your dishwasher is designed to use a liquid rinse aid. The use of rinse aids greatly improves drying performance after the final rinse. Do not use a solid or bar-type rinse aid. Under normal conditions, the rinse aid will last approximately one month. - Page 16 Preparing and Loading Dishes Filling the Detergent Dispenser (Con’t) 3. Close the dispenser cover. The amount of the detergent needed depends on the cycle and soil level of dishes. Refer to the table below and adjust the recommended amount as necessary for your load. Soft Water Medium Hard Water Hard Water...
-
Page 17: Care & Cleaning
Care & Cleaning Cleaning the Exterior Door and Panel 1. STAINLESS STEEL PANEL Clean the stainless steel door and handle regularly to remove the debris with a soft cloth. Do not use appliance wax, polish, bleach or products containing chlorine to clean the stainless steel door. 2. -
Page 18: Cleaning The Fine Filter
Care & Cleaning Cleaning the Fine Filter Take out the Cylinder Filter and remove the Fine Filter from the dishwasher tub bottom. To remove the Fine Filter you must first remove the bottom spray arm as shown below. Flush the Fine Filter by holding it under running water and replace. -
Page 19: Air Gap
Care & Cleaning Clean the Door Gasket Clean the door gasket with a damp cloth to remove food particles regularly. Air Gap If there is an air gap installed with your dishwasher, make sure it is clean so the dishwasher will drain properly. An air gap is not part of your dishwasher. -
Page 20: Troubleshooting
Troubleshooting Before Calling for Service PROBLEM POSSIBLE CAUSE SOLUTION Door may not be closed properly Confirm the door is shut all the way Check latch and connect the power Power supply or power line is not connected supply Dishwasher won’t start Delay Start option has been selected Refer to this manual to reset Deactivate the child lock. - Page 21 Troubleshooting Before Calling for Service (Con’t) PROBLEM POSSIBLE CAUSE SOLUTION For extremely hard water install a water Water hardness is too high softener Load the dishes again as the manual Improper loading of dishes Spots and filming on dishes indicates Old or damp powder rinse aid is used Use fresh rinse aid Rinse dispenser empty...
-
Page 22: Error Codes
Error Codes When some malfunctions come on, the appliance will display error codes to warn you: CODES MEANINGS POSSIBLE CAUSES Faucets are not opened, water intake is Longer inlet time restricted, or water pressure is too low Overflow Elements of the dishwasher leaked Failure of orientation of distributary valve Open circuit or break of distributary valve Keep touching a button more than 30 seconds... -
Page 23: Forza Warranty U.s.a
Duration of warranty: For twenty-four (24) months from the original date of purchase, the Forza warranty covers all parts and labor to repair or replace, under normal residential use, any part of the product proving to be defective in material or workmanship as a result of the original manufacturing process. - Page 24 20) Defects and damage arising from external forces beyond the control of Forza such as fire, flood, earthquakes and other acts of God. 21) Forza cannot guarantee the availability of service in areas more than 30 miles from an authorized retailer. In such cases where travel charges are levied, those will be borne by the consumer.
- Page 25 FULL NINETY DAY TOTAL PRODUCT WARRANTY For ninety days from the original date of purchase, the FORZA product warranty covers all parts and labor to repair or replace, under normal residential use, any part of the product proving to be defective in material or workmanship as a result of the original manufacturing process.
- Page 26 20) Defects and damage arising from external forces beyond the control of Forza such as fire, flood, earthquakes and other acts of God. 21) Forza cannot guarantee the availability of service in areas more than 30 miles from an authorized retailer. In such cases where travel charges are levied, those will be borne by the consumer.
