Powerbase
User manual
General information
* It is essential that you and any other operator of this product read and
understand the content of this manual before installing and using this product !
* In order to avoid operating errors, these manual must be accessible
to the staff at all times.
* The hoverboard should only be used for the purpose as described.
Please refer particularly to the instructions of the used stretcher.
* The illustrations do not necessarily correspond to the delivered equipment
and are not true to scale.
* We take no liability for damages caused by operating errors
or incorrect assembly or repair.
* Please pay close attention to the country-related, applicable safety regulations
for patient transfer.
* Subject to technical changes.
HOVERBOARD
GmbH
Gewerbepark 10
HOVERBOARD
HOVERBOARD
A-6068 Mils - AUSTRIA
Edition: 10/2019
www.hover.at
Advertisement
Table of Contents
Related Manuals for Hoverboard Powerbase
Summary of Contents for Hoverboard Powerbase
- Page 1 * In order to avoid operating errors, these manual must be accessible to the staff at all times. * The hoverboard should only be used for the purpose as described. Please refer particularly to the instructions of the used stretcher.
-
Page 2: Specification
HOVERBOARD HOVERBOARD Powerbase Specification 1... Pneumatic suspensions with automatic weight adjustment from 40-520 kg/88-1146 lbs and hydraulic shock absorbers. Total vertical stroke 170 mm/6.7" 2... Stretcher mounting platform 3... Lateral movement device with pneumatic release (option) 4... Switch box, contains: a) Relay, 12V... -
Page 3: Technical Data
The valve-control-circuit is internally fused with 5A Max. power consumption 25A at 12V DC Disinfection and cleaning * Disinfection and cleaning of the Hoverboard shall be performed according to the regulations of the respective country. * Never use disinfectants containing chloroacetic acid... - Page 4 8 bar/115 psi, the compressor starts automatically for approx. 20 seconds again. This allows constant operating pressure. * By turning off the ignition or the blue main switch, the hoverboard automatically lowers for loading and unloading.
-
Page 5: Connection Layout
HOVERBOARD HOVERBOARD Powerbase Connection layout Option lateral movement device (LMD): blue, Option reanimation (RA):red target colour cross-section target colour/cross-section ground (31) brown compressor black bridge grey Powerload black bridge grey mag. valve 1 black grey mag. valve 2 black bridge... -
Page 6: Spare Parts
HOVERBOARD HOVERBOARD Powerbase Spare parts Air suspension 30311 air cushion 30057 magnetic valve block 30620 > with shock absorber 30621 > without shock absorber 30209 external compressor 30058 magnetic valve 1 30059 magnetic valve 2 (without Box) 30291 level control valve... - Page 7 HOVERBOARD HOVERBOARD Powerbase Spare parts 30302 adjustable shock absorber 30072 Reed switch 30091 Cable conduit 30073 Block magnet 31270 terminal grey 30251 fuse holder 30500 connector 2 pins, T, f 31272 terminal blue 30252 fuse 30A 30501 connector 3 pins, T, f...
- Page 8 HOVERBOARD HOVERBOARD Powerbase Spare parts 35010 main switch (blue) 35011 toggle switch (red) 35012 LMD pushbutton 30244 pressure tube 4 mm, red 30248 teflon tube, 30066 pressure switch, 30245 pressure tube 4 mm, blue white pre-adjusted 8,5 bar 30246 pressure tube 4 mm, yellow...
- Page 9 HOVERBOARD HOVERBOARD Powerbase Spare parts 30083 bellows, without lateral movement device 30221 box for external compressor (without compressor) 30084 bellows, with lateral movement device 31011 LMD pneumatic cylinder 31030 linear bearing 31040 knob 51031 toothcomb back 51062 locking bolt 51041 toothcomb front...
