- Page 1 VPP500 Vacuum Pickup System Operating Manual info@fisnar.com www.fisnar.com...
-
Page 2: Table Of Contents
VPP500 Vacuum Pickup System Operating Manual Table of Contents Machine Overview Product Safety Statements Specifications Accessories External Controls Machine Setup Vacuum Pickup Pen Setup Operation Mode External Machine Actuation Spare Parts List © 2020 Fisnar - 2 - VPP500 Rev 01... -
Page 3: Machine Overview
OVERVIEW Model VPP500 Vacuum Pick System The VPP500 Vacuum Pickup System is designed for safely and efficiently picking up and placing delicate lightweight components with ease. Unlike conventional tweezers, the use of a rubber suction cup prevents possible accidental damage or contamination to the component during the lifting and positioning process. -
Page 4: Product Safety Statements
VPP500 Vacuum Pickup System Operating Manual SAFETY General Precautions Do not operate the machine in excess of its maximum ratings / settings. Make sure that the input air supply is clean and dry. A 5 micron air filter/regulator (item number 560567) is recommended to ensure the input air supply is clean and dry. - Page 5 Immediately disconnect power if any sparking or smoke appears. Do not expose the machine directly to sunlight. Maintenance The VPP500 is generally a maintenance free machine. However, to ensure smooth operation please follow the below instructions. Only use non-woven cleaners on the machine.
-
Page 6: Specifications
VPP500 Vacuum Pickup System Operating Manual SPECIFICATIONS Dimensions (W x D x H): 5.12” x 5.04” x 3.00” (130 x 128 x 76 mm) Weight: 1.49 lbs (0.68 kg) Input AC to Power 100 – 240 VAC, 50 / 60 Hz... -
Page 7: External Controls
VPP500 Vacuum Pickup System Operating Manual EXTERNAL CONTROLS FRONT REAR FIG. 1: External Controls - Overview Item Illustration Item Illustration Item Illustration Power Indicator Light Vacuum Control ESD Grounding Point Vacuum Inlet Port Foot Switch Connector Exhaust Port ESD Input Connector... - Page 8 VPP500 Vacuum Pickup System Operating Manual EXTERNAL CONTROLS FIG. 2: External Controls – Front Power Indicator Indicates if the machine is switched on or off. If the green color light is Light on this confirms the machine power is on.
- Page 9 FIG. 3: External Controls - Back The foot pedal switch (#5601888) is connected here. Or it can be used Foot Switch for connecting to an external device (e.g. Fisnar dispense robot) that Connector will send the start signal to the machine.
-
Page 10: Machine Setup
VPP500 Vacuum Pickup System Operating Manual MACHINE SET UP FIG. 4: Machine Setup Connect air hose (1) from compressed air 70-100 psi (5-7 bar) to the air inlet port on the back of the machine. See FIG. 4. Insert the Foot Pedal connector (2) to the port on the back of the machine. See FIG. 4. -
Page 11: Vacuum Pickup Pen Setup
VPP500 Vacuum Pickup System Operating Manual VACUUM PICKUP PEN SETUP FIG. 5: Vacuum Cup Attachment Select the correct size vacuum cup based on the size and weight of the component to be picked up. Select the correct size pickup tip, by choosing one which has a larger outside diameter, than the internal hole on the stem of the chosen vacuum cup. -
Page 12: Operation Mode
VPP500 Vacuum Pickup System Operating Manual OPERATION MODE FIG. 6: Operation Mode Place the suction cup installed on the pick-up pen over the component and apply a light force so there is no gap between the surface of the suction cup and surface of the component. -
Page 13: External Machine Actuation
VPP500 Vacuum Pickup System Operating Manual EXTERNAL MACHINE ACTUATION FIG. 7: External Machine Actuation A dry contact closure (0 Volt) between the Input (Pin #1) and Common (Pin #2) Input pins will trigger a dispense signal. See FIG. 7. PLEASE READ: Do not apply a voltage between the input pin (1) and the common pin (2). -
Page 14: Spare Parts List
Power Adaptor (Input: 100 – 240 VAC / Output: 24 VDC) 5601888 Foot Pedal Switch 561851 Air Inlet Hose Assembly 5601947 ESD Grounding Cable Assembly 5601948 Vacuum Pickup Pen Holder 580046NH-ESD Vacuum Pickup Pen (VPP500) – ESD Safe *Item Not Shown © 2020 Fisnar - 14 - VPP500 Rev 01... - Page 15 VPP500 Vacuum Pickup System Operating Manual SPARE PARTS LIST – QK-VTK Ref. Item Number Description QK-VTK Vacuum Tip Selection Kit 14ga 45° Vacuum Pickup Tip 580052 18ga 45° Vacuum Pickup Tip 580053 5601942 14ga Vacuum Pickup Tip 5601941 18ga Vacuum PickupTip 580047 Vacuum Cup –...
- Page 16 In no event shall manufacturer be liable for consequential or incidental damages. A return authorization is required prior to shipping a defective machine to the factory. Manufacturer reserves the right to make engineering or product modifications without notice. info@fisnar.com www.fisnar.com...
