Does the Pure 12-String fit into your guitar?

The Pure 12-String may be too big for some guitar models. K&K recommends the

Pure Mini pickups for all 6-string guitars.

This is an actual size diagram of the Pure 12-String:

pin hole side

soundhole side

Please print out this page and double-check the dimensions below:

Total dimensions mm (all 3 pickups):

22mm (height) x 61mm (length-left to right)

Total dimensions inches (all 3 pickups):

0.86" (height) x 2.4" (length-left to right)

Please cut out the diagram along the outer edges and along the dotted line in the

center (you should end up with ONE connected piece).
