- Page 1 pack...
- Page 2 Stage 14 ©️ 2019 Editorial Planeta DeAgostini S.A.U. Assembling Todos los derechos reservados. the engine block (II) ©️ 2019 De Agostini Publishing Italia S.p.A. Tutti i diritti riservati. Stage 15 Warning: Not suitable for children under the age of 14. Assembling This product is not a toy and is not designed or intended for use in play.
- Page 3 Assembling STAGE the engine block (i) In this assembly session, you will start to build the engine block of your model car. Follow our instructions carefully, using the illustrations to help you. PIECES FOR THIS STAGE PIECES FOR THIS STAGE 13A Engine block, left bank 13F Left engine mounting bracket 13B Oil filter mount...
- Page 4 STAGE 13 13.1 lign the linchpin inside the oil filter 13C with the hole in the mount 13B. Join the pieces together with a type AP screw. 13.2 ow AttAch the piece you have just made to the left bank of the engine block 13A. To do this, insert the linchpins on the oil filter mount 13B into the corresponding holes.
- Page 5 STAGE 13 13.4 the rectangular groove on the top surface of the left bank 13A. Put the left engine mounting bracket 13F into the groove, with the longest arm facing the oil filter. Join the pieces with two type AM screws. 13.5 the gearbox you assembled in the last session and position it as...
- Page 6 STAGE 13.7 ow put the two banks of the engine block (13A and 13D) together by aligning the holes with the fixing linchpins. Fix in place with two type AM screws. 13.8 the oil pan 13E, ow AttAch ensuring that it is facing the same way as shown in the illustration.
- Page 7 Assembling STAGE the engine block (ii) In this assembly session, you will continue assembling the engine block of your model car. Follow our instructions carefully, using the illustrations to help you. PIECES FOR THIS STAGE 14A Cylinder head, left bank 14E Oil filler cap covers (x2) 14B Cylinder head, right bank CP Screws 1.7×3 mm (x 14)*...
- Page 8 STAGE 14 14.1 Ake one of the oil filler caps 14D and slide it onto the corresponding linchpin on one of the two cylinder head covers 14C. Attach with a type DP screw. 14.2 a cap cover 14E on it. Press down gently to attach it.
- Page 9 STAGE 14 14.4 the previously assembled cover 14C onto the cylinder head 14A. Ensure that both pieces are facing the correct way and then join them together with four type CM screws. 14.5 the oil filler cap 14D and the corresponding cap cover 14E onto the second cover 14C.
- Page 10 STAGE 14.7 inAlly attach the right cylinder head cover to the engine block with four type CM screws. STAGE 14 FINAL RESULT The engine for your model now has two cylinder heads with covers. You will continue building the engine in the following assembly sessions.
- Page 11 Assembling STAGE the engine block (iii) In this assembly session, you will be working with the inlet manifold and the air intake of the supercharger. Follow our instructions carefully, using the illustrations to help you. PIECES FOR THIS STAGE 15A Inlet manifold (piece 1) 15G Fuel injection lines 1 (x 2) 15B Inlet manifold (piece 2) 15H Fuel injection lines 2 (x 2)
- Page 12 STAGE 15 15.1 lign the four mounting holes in piece 1 of the inlet manifold 15A with the corresponding linchpins on piece 2 15B, ensuring the pieces face the same way as those in the illustration. Attach with four type AP screws. 15.2 ou will now attach piece 3 of the inlet manifold...
- Page 13 STAGE 15 15.5 the piece you assembled above to piece 2 ttAch of the inlet manifold 15B, with the parts facing the same way as those in the illustration. Join with four type AP screws. 15.6 the air intake unit you assembled in the first assembly session. Carefully detach the air intake from the supercharger.
- Page 14 STAGE 15 15.9 the air intake over, as shown in the illustration. Insert the free end of the fuel injection line 3 15I into the top left hole in the distributor 1L, and the linchpin on its fuel injector 15F into the third hole from the left in the injector plate 1G.
- Page 15 Assembling STAGE the engine block (iV) In this assembly session, you will prepare the second wheel and attach the front section of the chassis to your model car. PIECES FOR THIS STAGE 16A Timing cover 16G Spark plug wire 7 cm 16M Spark plug wire 15 cm 16B Water pump 16H Spark plug wire 6 cm...
- Page 16 STAGE 16 16.1 AreFully detAch the connectors 16E from the sprue, ensuring that you don’t break the mounting linchpins. Now insert eight connectors into the distributor cap 16D, ensuring they are facing the same way as those in the illustration. 16.2 the distributor cap to the rotor 16C, ttAch...
- Page 17 STAGE 16 16.7 16.6 ttAch the water pump 16B to the front the engine block. Put the timing cover of the engine and fix in place with two type 16A onto the front of the block and fix in CM screws. place with two type CM screws.
- Page 18 STAGE 16.10 one end of the spark plug lide wire 16M (15 cm) onto the top left spark plug wire connector 16E and the wire 16J (10 cm) onto the bottom right connector. On the other side, by passing the wires underneath the supercharger pulley 1I, slide the free end of the wire 16M onto the furthest linchpin on the cylinder head cover 14C, and the free end of wire 16J onto the first linchpin on the...
