- Page 1 USER’S MANUAL Cassette Type Series MH✴✴✴FKEA MH✴✴✴FMEA Free Joint Multi Air Conditioner (Cooling and Heating) E S F I P D G R DB98-20235A(5)
-
Page 2: Preparing Your Air Conditioner I Safety Precautions
URING OPERATION ISPOSING OF THE UNIT THERS Register your product at www.samsung.com/global/register • Risk of electric shock can cause injury or death. • Disconnect all remote electric power supplies before servicing, installing or cleaning. • This must be done by the manufacturer or its service agent or a similar qualified person in order to avoid a hazard. -
Page 3: Table Of Contents
Contents REPARING YOUR AIR CONDITIONER Safety Precautions ........2 View of the Unit . -
Page 4: View Of The Unit
View of the Unit The figures are shown in this instruction may differ from yours depending on the model. Indoor Unit Remote control sensor On/Off indicator(Green) & Removing frost indicator(Red) Indoor Unit Filter Sign indicator Timer indicator On/Off indicator On/Off button MH✴✴✴FKEA MH✴✴✴FMEA Air flow blades(outlet) - Page 5 Outdoor Unit MH040FXEA2 Air Inlet (Rear) Air Outlet Outdoor Unit MH068FXEA4 Air Inlet (Rear) Air Outlet If the heat exchanger in the outdoor unit gets dusty, cooling efficiency may fall. So clean the heat exchanger with water when it becomes dirty. However, be careful when you wash the surface of the heat exchanger because it is very sharp.
-
Page 6: Wireless Remote Controller-Buttons And Display
Wireless Remote Controller-Buttons and Display To use the wireless remote controller, refer to an appropriate manual. Operating mode Temperature setting Fan speed Air flow direction On Timer setting Off Timer setting Battery discharge indicator After cleaning the air filter, press the Mode selection button Temperature adjustment buttons... -
Page 7: Wired Remote Controller-Buttons And Display
Wired Remote Controller-Buttons and Display The wired remote controller is an optional accessory and it is installed on the wall. To use the wired remote controller, refer to an appropriate manual. Removing frost indicator Communication error indicator On Timer setting Off Timer setting Test indicator Temperature adjustment... -
Page 8: Centralized Controller
Centralized Controller The centralized controller is an optional accessory and it is installed on the wall. To use the centralized controller, refer to an appropriate manual. Front View The operating lamp comes on even when only one air conditioner connected to the centralized controller is operating. Side View Operating Mode Switch Choose the appropriate operating mode with the Operating Mode Switch... -
Page 9: Function Controller
Function Controller The function controller is an optional accessory and it is installed on the wall. The function controller is an additional controller which is used with the centralized controller. To use the function controller, refer to an appropriate manual. Removing frost indicator Communication error indicator... -
Page 10: Operating Recommendations
Operating Recommendations Here are a few recommendations that you should follow when operating your air conditioner. Topic Recommendation Heating The heat pump function of the air conditioner absorbs heat performances from outside air and brings it indoors. As the temperature of the outside air drops, the heating performance of air conditioner will decrease. -
Page 11: Temperature And Humidity Ranges
Temperature and Humidity Ranges The following table indicates the temperature and humidity ranges, within which the air conditioner can be used. If the air conditioner is used at... High temperature Low temperature High humidity levels Mode Outdoor Temperature Indoor Temperature Heating -15°C to 24°C approx. -
Page 12: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner Wired Remote Controller Wireless Remote Controller For the best use of your air conditioner, you must clean it every 2 weeks regularly to remove the dust that accumulates on the air filter. Before cleaning your air conditioner, ensure that you have switched off the electric circuit breaker used for the unit. - Page 13 MH✴✴✴FMEA Open the front grille by pushing the tabs on the grille. You must give attention when disassembling the front grille and must check the safety clips have been installed. If you do not check them, the front grille will drop suddenly and you will be hurt.
-
Page 14: Bio-Pure Filter Installation (Optional)
Bio-Pure Filter Installation (Optional) (Only for MH✴✴✴FKEA) Bio-pure filter Deodorizing filter The air conditioner can be fitted with a Bio-Pure or deodorizing filter to remove minute dust particles or odours. The service life of the filter is approximately 3 months depending on the time during which the air conditioner is used. Remove the vinyl packing from the filter. -
Page 15: Solving Common Problems
Solving Common Problems Before contacting the after-sales service, perform the following simple checks. They may save your time and expense of an unnecessary call. Problem N Check that the breaker used for the air conditioner is switched on. The air conditioner does not operate at all Wired Remote Controller The air conditioner does not... - Page 16 Contact SAMSUNG WORLD WIDE If you have any comments or questions regarding a Samsung products, contact the SAMSUNG customer care center. Country BELGIUM CZECH REPUBLIC DENMARK FINLAND FRANCE GERMANY HUNGARY ITALIA LUXEMBURG NETHERLANDS NORWAY POLAND PORTUGAL SLOVAKIA SPAIN SWEDEN RUSSIA...
