Banana Bike LT Instructions

Thank you for purchasing your Banana Bike. A Banana Bike is a fantastic first bike and a great way for
your child to learn the basics of biking, learning to balance and steer whilst having massive fun!
For full instructions, including video, please visit: http://www.banana-bike.com/instructions

Attach the Handlebars to the Frame

The headset which connects the front forks and
frame together is pre-assembled, which makes
attaching the handlebars very easy.
1. Remove the black plastic cap from the
bottom of the handlebars
2. Slide the handlebars fully into the headset.
3. Start to tighten the hex nut on top of the
handlebars using the supplied hex key.
4. Check the alignment of the handlebars.
5. Tighten the nut until the handlebars are
firmly locked in place and cannot move,
check regularly. Important!

Attach the Seat to the Frame

Firstly place the quick release bracket over the
top of the frame which receives the seat post.
www.banana-bike.com
2
3
Slide the seat post into the frame. Tighten the left
screw, then close the clamp. Tighten until there is
no movement in the seat stem. Important!
1
2
1
