APPLIED ACOUSTICS 1082 Operation Manual

Firmware version 1.12
Hide thumbs Also See for 1082:
Table of Contents

Advertisement

Quick Links


1082 Smart Switch
Firmware Version 1.12
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1082 and is the answer not in the manual?

Questions and answers

Related Manuals for APPLIED ACOUSTICS 1082

Summary of Contents for APPLIED ACOUSTICS 1082

  • Page 1   1082 Smart Switch Firmware Version 1.12 Operation Manual...
  • Page 2   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          THIS PAGE IS INTENTIONALLY LEFT BLANK __________________________________________________________________________________________________________ Page 2 of 48...

  • Page 3: Revision History

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Revision History Change Issue Reason for change Date Additions for 1100 Series Beacons and Sigma2, refer to DCR 1852 15/08/17 note. Addition to Section 3.4.1 Identified Beacon Model and 1501 22/07/14 Configuration Message, refer to DCR note.

  • Page 4: Table Of Contents

    1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Table of Contents   REVISION HISTORY ............................3   1. INTRODUCTION TO THE 1082 SMART SWITCH ..................6   2. GETTING STARTED ............................. 7   2.1 U ............................7 NTERFACE   2.2 C ............................
  • Page 5   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Thank you for choosing Applied Acoustic Engineering as one of your subsea equipment suppliers. We hope you experience many years of reliable operational use from our products. If you do encounter any technical issues with any of our products then please don’t hesitate to contact our Technical Team via the following methods.

  • Page 6: Introduction To The 1082 Smart Switch

    CHA-1082-8000/11 __________________________________________________________________________________________________________                          1. Introduction to the 1082 Smart Switch The AAE 1082 Smart Switch is a pocket size solution to configuration, testing and charging of AAE 1000 / 1100 Series beacon ranges. Main features are: -  AAE 1000 / 1100 Series beacon configuration, including channel and depth telemetry transmission selection.

  • Page 7: Getting Started

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          2. Getting Started 2.1 User Interface The Smart Switch user interface comprises a 2-way backlit L.C.D. and four stylised selection keys on the face of the unit. The Smart Switch does not include a power switch the unit is ‘always on’.

  • Page 8: Connector Panel

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          2.2 Connector Panel A connector panel includes a DC input socket for the included 30VDC power supply unit, a 9-way ‘D’ socket for RS232 serial communication and beacon charging, and a reset button concealed against accidental operation.

  • Page 9: Smart Switch Operation

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3. Smart Switch Operation 3.1 Connecting to a Beacon Your Smart Switch arrives supplied with a Beacon Connection Cable for connection to compatible AAE beacons. Connect the cable between the Smart Switch connector panel 9-way ‘D’ socket and compatible AAE beacon 5-way MCBH5M bulkhead plug.

  • Page 10: Main Menu Options

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.3 Main Menu Options The Smart Switch menu structure has a top tier of 6 main menu options. Press for next main menu option. Press to select a main menu option: - Fig.

  • Page 11: Fast Id Beacon

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.4 Fast ID Beacon Quickly identifies a connected beacon model and configuration. NOTE: - This action is not required prior to configuring a connected beacon. Refer Section 3.5 for further information.

  • Page 12: Identified Beacon Model And Configuration Message

    Beacon model, 1019D in this example. Enabled Options (only displayed for beacons with MCU firmware revision 4.00 onward) “OPT=1,3” Options 1 and 3 are enabled in this example. Contact Applied Acoustics for details. Configuration “CFG=AAE” AAE defined “channel” configuration (including Sigma1™).
  • Page 13   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          iXBlue (IXB) Compatible Configuration “IF=19.5kHz” Interrogate Frequency (IF), 19.5kHz in this example. “RC=00” Reply Code, 00 in this example. “TAT=020ms” Turn-Around-Time (TAT), 20ms in this example. Sonardyne Wideband™ (SWB) Compatible Configuration “QS=A1”...

  • Page 14: Beacon Configuration

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.5 Beacon Configuration Contains further sub menu options for beacon configuration: - Fig. 7 3.5.1 Select beacon channel configuration. 3.5.2 Check beacon battery voltage. 3.5.3 Check select beacon depth telemetry transmission status.
  • Page 15   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Press to return to top tier menu option “Beacon Config”. Press for next sub menu option. Press to select a sub menu option. On selection of a sub menu option except “Channel”, if the Smart Switch is not currently communicating with a connected beacon, i.e.

  • Page 16: Channel

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.5.1 Channel Contains further sub menu options for channel configuration: - Fig. 8 3.5.1.1 Select AAE “channel” combination configuration. 3.5.1.2 Select AAE Sigma2™ “Quickset” scheme configuration. 3.5.1.3 Select AAE Sigma2™ configuration.

  • Page 17: Aae Channel

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          On selection of a sub menu option, if the Smart Switch is not currently communicating with a connected beacon, i.e. is “Standing by”, the Smart Switch will first attempt serial communication with a connected beacon, indicated by a “Searching...”...

  • Page 18: Sigma2 Quickset

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.5.1.2 Sigma2 Quickset A user selection for AAE Sigma2™ “Quickset“ scheme is displayed: - Fig. 10 Change “Quickset” scheme. Select “Quickset” scheme. Press to return to the previous tier sub menu option “SIGMA2 Qkset”. Press to change the “Quickset”...

  • Page 19: Sigma2 Channel

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.5.1.3 Sigma2 Channel Sigma2 Channel configuration consists of confirming a Wake-Up Tone (WUT), Interrogate Code (IC), Reply Code (RC) and Turn-Around-Time Extension (TATX) in sequence before selecting the confirmed configuration: - Fig.
  • Page 20   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Next, a user selection for Interrogate Code (IC) is displayed. Press to return to the previous tier sub menu option “SIGMA2 Chnl”. Press to change the Interrogate Code (IC) 00 through 15.

  • Page 21: Ixb Channel

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.5.1.4 IXB Channel iXBlue compatible configuration consists of confirming an Interrogate Frequency (IF), Reply Code (RC) and Turn-Around-Time (TAT) in sequence before selecting the confirmed configuration: - Fig. 12 Change Interrogate Frequency (IF)
  • Page 22   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Next, a user selection for Turn-Around-Time (TAT) with flashing cursor highlighting one digit is displayed. Press to return to the previous tier sub menu option “IXB Channel”. Valid Turn- Around-Times (TAT) are between 20ms (020ms displayed) and 200ms in 1ms steps. Press change the highlighted decimal digit.

  • Page 23: Swb Quickset

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.5.1.5 SWB Quickset A user selection for Sonardyne Wideband™ compatible “Quickset“ scheme is displayed: - Fig. 13 Change “Quickset” scheme. Standing by to select SW SWB Quickset Select A1 Select “Quickset” scheme.

  • Page 24: Swb Channel

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.5.1.6 SWB Channel Sonardyne Wideband™ compatible configuration consists of confirming an Interrogate Channel (IC), Acoustic Command Address (ACA) and Turn-Around-Time (TAT) in sequence before selecting the confirmed configuration: - Fig. 14...

  • Page 25: Battery

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Next, a user selection for Turn-Around-Time (TAT) is displayed. Press to return to the previous tier sub menu option “SWB Channel”. Press to change Turn-Around-Time (TAT) 62.5ms (062.5ms displayed) through 875.0ms. Press to confirm the Turn-Around-Time (TAT).

  • Page 26: Depth Status

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.5.3 Depth Status A connected beacons depth telemetry transmission status and a user selection are displayed: - Fig. 16 Change ON or OFF. MDL=1019D Depth=OFF Select depth telemetry Depth Status Select OFF transmission status.

  • Page 27: Mcu Firmware Version

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.5.5 MCU Firmware Version A connected beacons MCU firmware version is displayed: - Fig. 18 Press to return to the previous tier sub menu option “MCU F/W Ver”. - Fig. 18 beacon model and firmware version for example only.

  • Page 28: Responder Test

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.6 Responder Test Test responder operation of a connected compatible AAE beacon. Refer beacon manual for compatibility details: - - Refer NOTE: beacon manual for compatibility and responder details. Fig. 20...

  • Page 29: Trickle Charge

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.7 Trickle Charge Trickle charge a connected compatible AAE beacon. Trickle charge activation is controlled by an electronic switch within the Smart Switch, sourcing power for beacon trickle charging from the...

  • Page 30: Fast Charge

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.8 Fast Charge - A connected beacons selector switch has a dedicated position for fast charging. NOTE: Refer beacon manual for details. Refer Section 3.8.1 Fast Charge Activation Step 1. - For fast charging Model 1060 Beacons ensure Smart Switch firmware is V1.08 or NOTE: above.

  • Page 31: Fast Charge Activation

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          - Fig. 24 charge time for example only. NOTE: - Trickle charging is deactivated and serial communication with a connected beacon is NOTE: stopped on selection of fast charge main menu option.

  • Page 32: Fast Charge Status

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.8.2 Fast Charge Status NOTE: The Smart Switch will not enter low power standby while a connected beacon is fast charging. After fast charge activation, the Smart Switch continually monitors fast charge status information from a connected beacon.

  • Page 33: Fast Charge Termination

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.8.3 Fast Charge Termination NOTE: - After charge termination, the Smart Switch will now enter low power standby mode after 2 minutes of no user activity. When fast charging terminates, the electronic switch within the Smart Switch will open, isolating the beacon from the 30VDC power supply unit.
  • Page 34   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          No Beacon Fast Charger Status Fig. 29 No status! Refer 3.8.4 Halted 1h23m The Smart Switch does not detect fast charge status information from a connected beacon. Check the following: - ...
  • Page 35   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Smart Switch Terminates Charging After Timeout Fig. 31 Timeout! Refer 3.8.4 Halted 7h00m The Smart Switch terminated beacon charging. The Smart Switch monitors overall beacon charging time. If the overall charging time exceeds a defined time limit or “timeout”, the Smart Switch terminates beacon charging.

  • Page 36: Smart Switch Configuration

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          3.9 Smart Switch Configuration Contains further sub menu options for Smart Switch configuration: - Fig. 34 3.9.1 MDL=1019D MDL=1019D Check Smart Switch firmware version. Smart Switch F/W Version 3.9.2 MDL=1019D Smart Switch Backlight backlight control.

  • Page 37: Backlight

    Within the EU all electronic components and batteries must be taken for separate collection at the end of their working life under EU WEEE directives. Applied Acoustics as a manufacturer within the EU will responsibly dispose of any returned end of life Applied Acoustics components / batteries through a registered WEEE scheme.

  • Page 38: Spares

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          7. Spares The following spares are available from stock: - Beacon Connection Cable RS232 serial cable 30VDC Power supply unit (100-250VAC mains input) Mains lead (IEC) 1000 Series PRV Actuator 8. Fault Finding The Smart Switch doesn’t work, what can we do?

  • Page 39: Specification

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          9. Specification Physical Dimensions 117mm x 73mm x 24mm Weight 160g User Interface 4 selection buttons 2-line backlit liquid crystal display Other Reset button Operating Temperature 0°C to 30°C Storage Temperature 0°C to 55°C...
  • Page 40   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Operation Modes Fast I.D. Beacon Beacon Configuration Responder Test Trickle Charge Fast Charge Smart Switch Firmware Field upgradeable Electrical Serial Comms RS232 compliant 9600 baud rate 8 data bits 1 stop bit...

  • Page 41: Transportation By Air

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          10. Transportation by Air NiMH Battery Pack These battery packs are not classified as dangerous goods for transportation by air. It is advised that any paperwork accompanying the Smart Switch state this clearly.

  • Page 42: Appendix A Connector Details

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          11. Appendix A Connector Details Smart Switch DC Input Socket OUTER INNER Smart Switch 9-Way ‘D’ Socket 9-WAY ‘D’ SOCKET FACE VIEW 9-WAY ‘D’ SOCKET FUNCTION RS232 TXD / KEY PULSE...
  • Page 43   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Beacon Connection Cable 9-WAY ‘D’ PLUG FACE VIEW MCIL5F PIGTAIL FACE VIEW 9-WAY ‘D’ PLUG MCIL5F PIGTAIL 1 (BLACK) / 5 (ORANGE) 3 (RED) 2 (WHITE) 4 (GREEN) __________________________________________________________________________________________________________ Page 43 of 48...

  • Page 44: Appendix B Quick Start Guide

      1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          12. Appendix B Quick Start Guide __________________________________________________________________________________________________________ Page 44 of 48...

  • Page 45: Appendix C Firmware Update Instructions

    RS232 serial cable (1 to 1, not crossover cable). Instruction: 1. Connect 1082 Smart Switch to PC com port via serial lead. 2. Run “SmartSwitchProgrammer.exe”. The software will automatically start searching for a connected Smart Switch. (The software will automatically use the com port that was last used with the software, if this is incorrect, please select correct com port from the menu) 3.
  • Page 46   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          4. Program will try to detect a connected Smart Switch and display the current firmware revision. If the software does not detect a Smart Switch within approximately 15 seconds the detection will be aborted. To attempt a reconnect you may press the ‘Search’ button on the tool bar 5.
  • Page 47   1082 Smart Switch Operation Manual  CHA-1082-8000/11 __________________________________________________________________________________________________________                          Click “Yes” to confirm programming. You will be alerted if the version you are attempting to program to the Smart Switch is the same, or older, than the currently installed version 7.
  • Page 48  ...
