- Page 1 HTT70 For all variants of the HTT70 Hardware Manual Revision 1.4 PCB Revision: 1.0 or Higher...
-
Page 2: Table Of Contents
Power ..............................12 Display ..............................12 Touch ............................... 13 Resources ..............................14 Multi-touch Firmware ..........................14 HTT Utility Program ..........................14 Dimensional Drawings ..........................15 Characteristics ............................. 19 Optical ..............................19 Touch Panel ............................. 19 MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... - Page 3 Power ..............................19 Environmental ............................19 Recommended Accessories ........................20 USB Cable ............................20 Power Adaptor ............................ 20 Support ............................... 20 Contact ................................ 20 MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca...
- Page 4 Added new Resources section Divino May 29, 2018 Corrected Header Population and Drawings Divino May 10, 2018 Corrected Header and Mates Table Divino February 22, 2018 Added -TPC variant drawing Divino November 6, 2017 First Release Divino MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca...
-
Page 5: Introduction
Low profile mounting holes Industrial 5-35V power input (-VPT) option Available with: o No touch panel o Resistive touch panel o Capacitive touch panel Functional Diagram Figure 1: HTT Block Diagram MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... -
Page 6: Ordering
-H6: Barrel Jack with Vertical Connectors -H7: Micro MATE-N-LOK with Horizontal Connectors -H8: Micro MATE-N-LOK with Vertical Connectors Protocol -CH: HDMI interface Voltage -V5: 5V Input Voltage -VPT: Regulated 5V - 35V Input Voltage MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... -
Page 7: Hardware
Mini USB, Vertical: Touch & Power Mini-B USB Cable -H6 & -H8 (TPC and TPR Only) Barrel Jack: 2.1mm Center Positive Power Adaptor -H5 & -H6 External Power, 2-1445057-2 Micro MATE-N-LOK 1445022-2 -H7 & -H8 MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... -
Page 8: Type A Hdmi Port
HTT settings through the HTT Utility Program. If necessary, up to 500mA of power can be provided through the Mini-USB header to power the HTT. Table 5: Mini USB Pinout Function Figure 5: Mini USB Connector MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... -
Page 9: Barrel Jack Power Adaptor
When choosing an adaptor, please ensure that it conforms to the voltage and current requirements of your display. Please consult the Power section for details. Table 7: Power Adaptor Pinout Function Figure 7: Micro MATE-N-LOK Power Adaptor MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... -
Page 10: Getting Started
HTT’s display settings. No further software configuration is required. The HTT is not fully compatible with TinkerOS-Android Marshmallow. BeagleBone The BeagleBone board will autodetect the HTT’s EDID display settings automatically. No further software configuration is required. MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... -
Page 11: Usb Drivers
Once the HTT is properly installed on Windows, two new devices will be present in Device manager. HID-Compliant Mouse USB Composite Device Table 8: HTT Device VID/PID Table 9: HTT Device VID/PID 0x1B3D 0x1B3D 0x14C2 0x14C9 Figure 8: HTT USB Driver Listing Figure 9: HTT USB Driver Listing MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... -
Page 12: Extended Display Information Data (Edid)
HTT will use the host device’s built-in touch drivers. This allows the HTT70 to take advantage of the host device’s touch driver and pre-installed touch gestures. MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... -
Page 13: Troubleshooting
If there are large black bars on the edges of the display, or if the video image appears to be offset, please use the Contact section to reach a friendly Matrix Orbital support representative MATRIX ORBITAL Phone: 403.229.2737... -
Page 14: Touch
If you are using a capacitive touch display, make sure the screen is clear of debris or droplets. If you are still unable to resolve the issue, please use the Contact section to reach a friendly Matrix Orbital support representative. MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... -
Page 15: Resources
Through this program, users will be able to change HTT configuration settings such as the touch panel’s software orientation, touch screen calibration, touch sensitivity (capacitive touch panel only), backlight brightness and more. MATRIX ORBITAL Phone: 403.229.2737 Email:... -
Page 16: Dimensional Drawings
Dimensional Drawings Figure 10: HTT70A-TPN Dimensional Drawing MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... - Page 17 Figure 11: HTT70A-TPC Dimensional Drawing MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca...
- Page 18 Figure 12: HTT70A-TPR Dimensional Drawing MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca...
- Page 19 Figure 13: HTT70G-TPC Dimensional Drawing MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca...
-
Page 20: Characteristics
Wide Voltage Backlight 12.0 35.0 (VPT) Environmental Table 14: HTT70 Environmental Characteristics Operating Temperature -20°C to +70°C Storage Temperature -30°C to +80°C Operating Relative Humidity* 90% (T < 60°C) *Note: No condensation at any temperature MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca... - Page 21 AC Plugs Included: North American (NEMA), Europlug (Type C), UK (Type G), Australia/China/New Zealand/Argentina (Type I) Support Phone: 403.229.2737 Email: support@matrixorbital.ca Manuals and Drivers: http://www.matrixorbital.ca Forums: http://www.lcdforums.com/forums Contact Sales Support Online Phone: 403.229.2737 Phone: 403.229.2737 Purchasing: www.matrixorbital.com Email: sales@matrixorbital.ca Email: support@matrixorbital.ca Support: www.matrixorbital.ca MATRIX ORBITAL Phone: 403.229.2737 Email: support@matrixorbital.ca...
