Technical Data - SNOWJOE SUNJOE SPX4600-MAX-RM Operator's Manual

Know Your Electric Pressure Washer
Read the owner's manual and safety rules carefully before operating the pressure washer. Compare the illustration below to
the unit in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for future
reference.
1. Soft grip
2. High-pressure hose holder
3. Power cord holder
4. High-pressure hose
5. Power cord with GFCI
6. Detergent dial
7. ON/OFF switch
8. Garden hose adapter/connection

Technical Data

Rated Voltage .............................................120 V ~ 60 Hz
Motor ...........................................................14.5 amp
Max Water Inlet Temperature ......................104ºF/40ºC
Max Water Inlet Pressure ............................0.7 MPa
Rated Flow ..................................................1.1 GPM
Max Flow* ....................................................1.3 GPM
* Max rating per CSA test standards. Maximum internal pressure is 3000 PSI and flow is 1.3 GPM. Under typical load, working pressure is 2300 PSI and flow is 1.1 GPM.
1
10
2
3
11
4
12
5
6
13
7
8
14
9
15
9. Wheel (2)
10. Trigger gun
11. Trigger gun holder
12. On-board nozzle storage
13. Spray wand
14. Water outlet/high-pressure hose
connection
15. Detergent tank
Rated Pressure .......................................... 2300 PSI
Max Pressure* ............................................ 3000 PSI
Detergent Tank Capacity ............................ 1 Gal (3.8 L)
High-pressure Hose Length ....................... 20 ft (6 m)
Power Cord Length .................................... 35 ft (10.7 m)
Weight ........................................................ 36.6 lbs (16.6 kg)
7
16. Needle clean-out tool
17. 0º Quick-Connect nozzle (orange)
18. 15º Quick-Connect nozzle (yellow)
19. 25º Quick-Connect nozzle (green)
20. 40º Quick-Connect nozzle (gray)
21. Soap Quick-Connect nozzle (black)
22. Heavy-duty turbo nozzle
22
21
20
19
18
17
16
