Summary of Contents for Curtec Packo
- Page 2 Washing The washing instructions below apply to the cleaning of all CurTec packaging products that are made of polyethylene and polypropylene: Best results will be achieved with a washing installation that is equipped with spray nozzles or a so-called Ultra-Sonic installation.
- Page 3 Close The UN marking on a Packo is only valid if the following closing instruction is applied. The following instruction applies to both Packo with inner seal and lid and Packo with two-component lid. To close Packo with two-component lid you can start at point 2.
- Page 4 Open The following instruction applies to both Packo with inner seal and lid and Packo with two-component lid. For the opening of a Packo with a two-component lid, point 3 does not apply. 1. Hold the container firmly with one hand. Take the lip of the tamper evident strip with your other hand and tear it off counterclockwise.
- Page 5 Since CurTec has no influence on the use of its packaging by end users, they advise to test each transport mode. It remains the responsibility of end users to verify whether a package and content comply with relevant transport regulations.
- Page 6 Attention! The weights mentioned in the table have been established after simulation and can only serve as indications. CurTec recommends users to perform tests at all times. The table allows you to calculate the number of containers that can be stacked: Reduce the stacking weight mentioned with the relevant share of the weight of intermediate layers and divide by the weight of the container with content.
- Page 7 35°C. The stacking load in the table is at 50°C only 75% of the last mentioned value and at 60°C only 50%. When a stack is higher than 2.5 meters, the floor angle cannot exceed 0.5%. CurTec strongly discommends stacking containers horizontally, lying on the side. Packo manual 2020-7...
- Page 8 Attention! The weights mentioned in the table have been established after simulation and can only serve as indications. CurTec recommends users to perform tests at all times. The table allows you to calculate the number of containers that can be stacked: Reduce the stacking weight mentioned with the relevant share of the weight of intermediate layers and divide by the weight of the container with content.
- Page 9 The containers must be stowed professionally and fixed in such a way that makes moving impossible. For the use of pallets, see instruction 6 (Palletization). For stacking containers in a warehouse, see instruction 4 (Static load). Packo manual 2020-7...
- Page 10 A pallet should have an almost closed surface fitted with planks that are no more than 5 cm/ 2 inches apart. CurTec advises not to exceed a total stacking height of 2 meters. In case a pallet is placed on top of another pallet, an intermediate layer is required to enable an equal spread of the pressure.
- Page 11 Art. No. 4303 ▪ 4305 ▪ 4306 ▪ 4310 ▪ 4313 (84) 1200 x 800 mm (105) 1200 x 1000 mm 48 x 40 inch Art. No. 4315 ▪ 4320 ▪ 4325 (66) 1200 x 800 mm (88) 1200 x 1000 mm 48 x 40 inch Packo manual 2020-7...
- Page 12 CurTec manufactures packaging material for a wide range of purposes. This declaration is restricted to the packaging material as it leaves the production facility. CurTec has neither control over final end use of the product nor over processing conditions. It is...
