- Page 1 MICROFLUSH Half Gallon Toilets ® Air Operated Model LF-210 Model LF-219 Installation/Service Manual P/N 24563 452 East Hill Road, Willits, CA 95490 USA Tel: 707.459.5563 Tel: 800.358.8280 Fax: 707.459.6617 www.microphor.com www.wabtec.com...
-
Page 2: Customer Service
THANK YOU FOR PURCHASING A to water tight decks and bulkhead (46CFR56.69) MICROPHOR PRODUCT! Be sure airline from compressor is of sufficient size, Your Microflush toilet is designed to provide you with ® based on length of pipe run to head. We suggest 3/8" air years of reliable service while using only two quarts of line up to 40', 1/2"... - Page 3 FOR MARINE INSTALLATIONS: All Rear Discharge Models: Install inverted P-Trap For direct overboard discharge, contact Microphor or supplied with Microflush toilet. Do not glue or connect your dealer. fittings until fitting alignment has been checked. Caution: Outlet is 3/4" off centerline. Make sure toilet 4.
-
Page 4: Double Check
DOUBLE CHECK MAINTENANCE/CLEANING/CLEARING/ WINTERIZING 1.Air pressure at Microflush toilet is at least 60-65 PSI. 2.Water Pressure at ROUTINE MAINTENANCE Recommended Water Level Microflush toilet is between Your Microflush toilet has an USAGE LUBRICATE 20-50 PSI, 35 PSI optimal. air-operated Air/Water Se- Light Every 5 years 3.Water level in bowl should... -
Page 5: Design Changes
passage becomes clear, turn on water and press flush handle to start flush cycle. WINTERIZING (Out-of-Service Winter Storage) Shut OFF water to Microflush toilet. Flush Microflush toilet three times or until water no longer flows into the bowl. Unhook water supply at angle stop. Empty water in line into receptacle. -
Page 6: Troubleshooting
TROUBLESHOOTING Your Microflush ® toilet is designed to give you years of trouble-free operation. Please check the following before beginning any service or repair: Water supply: 1. Is the water turned on? 2. Is the water pressure between 20 and 50 PSI at the toilet for pressure water system? Fluctuating or high water pressure can cause intermittent problems with the toilet operation. -
Page 7: Exploded Views
EXPLODED VIEWS Toilet Shell Toilet Lid Closet Screws Flush Activator Air/Water Seq. Valve Vacuum Breaker Bleed Off Plug Valve Bracket Hopper Assembly P-Trap, Rear Discharge Hopper Bleed Valve Hopper Screws Air Cylinder Flapper Assembly Crank Assembly Water Supply Tube Water Connection Hopper Gasket Air Supply Kit Pressure Relief Valve... -
Page 8: Parts Chart
PARTS CHART t e l l l e e t i c s i t i u t e l e t i c s i t i u c i l & t l o e t i c s i t i u v i t e t i... - Page 9 AIRLINE CONNECTIONS - SERVICE KITS - AIR/WATER SEQUENCE VALVE COMPONENTS AIRLINE CONNECTIONS / r i Standard Flush, Integral i l y , r e o t t i t t i Black e t i i l y i t t i Blue Green v i t...
- Page 10 HOPPER REPLACEMENT CAUTION: Read this entire procedure before beginning work! 1. Remove toilet from floor. Place toilet upside down on a sheet of cardboard or other padded material. 2. Remove two (2) screws from either side of hopper and lift hopper from sealing adaptor. 3.
- Page 11 AIR/WATER SEQUENCE VALVE OPERATION 1. In the normal rest position, pressurized air enters Air & Water Sequence Valve Air In (60 PSI) the Flush Activator and goes from Flush Activator Water In Port 1 (Green tube) to Air/Water Sequence Valve Port 2, through Port 3 (Red tube) to Air Cylinder Flush Activator Port 4 holding the Flapper closed, sealing the water...
- Page 12 LF-210 ROUGH-IN DIMENSIONS NOTE: All dimensions may vary ½” ± Downward Discharge 13" AIR HOOK-UP 1/4" COPPER TUBING WATER HOOK-UP 14.5" 3.38" 1/2" STRAIGHT COMPRESSION FITTING TO AIR SUPPLY PIPE THREAD 11.25" 24.5" Round CUTOUT AT REAR 20.5" 22" 16.5" TOILET DISCHARGE 8"...
- Page 13 LF-219 ROUGH-IN DIMENSIONS NOTE: All dimensions may vary ½” NOTE: Do NOT use P-Trap in vertical rise waste line applications. Downward Discharge TOILET DISCHARGE 2.25“ DIA. THRU FLOOR 4" 14.5" 6.25" 1.12" 19.5" 17.25" 17.25" 16.5" Round TOILET DISCHARGE 13" 1-7/8"...
- Page 14 General Terms and Conditions Covering Sales All sales of merchandise by Microphor are subject to the General Terms and Conditions as provided herein and on invoices issued by Microphor. PRICES: All goods and products sold by Microphor will be billed to its customers according to the price lists contained in the current bulletins and price lists issued by Microphor.
