Batch Packaging - Ebyte E73-2G4M04S1A User Manual

Chengdu Ebyte Electronic Technology Co., Ltd.
Product Type
TX2400-NP-5010 Flexible antenna
TX2400-JZ-3 Rubber antenna
TX2400-JZ-5 Rubber antenna
TX2400-JW-5 Rubber antenna
TX2400-JK-11 Rubber antenna
TX2400-JK-20 Rubber antenna
TX2400-XPL-150 Sucker antenna

9. Batch packaging

Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co.,Ltd.
Frequency Gain
Hz dBi
2.4G 2.0
2.4G 2.0
2.4G 2.0
2.4G 2.0
2.4G 2.5
2.4G 3.0
2.4G 3.5
Size Wire Interf
mm cm ace
10*50 - IPEX
30 - SMA-J
50 - SMA-J
50 - SMA-J
110 - SMA-J
200 - SMA-J
150 150 SMA-J
E73-2G4M04S1AX User manual
Feature
Built-in flexible FPC soft
Short straight, omnidirectional
Short straight, omnidirectional
Fixed bend, omnidirectional
Bendable, omnidirectional
Bendable, omnidirectional
Small sucker antenna, cost effective
10
