- Page 1 ™ User Manual...
- Page 2 P/N: 6317-00001 The Measure of Excellence...
- Page 3 • Supply Voltage: 12-24 VDC • Max Input Current: 120mA • Output Voltage Typical: 9.45V • Fused output Download the Free Rochester Gauges e-Dial™ App Today! Rochester Gauges LLC Customer Service, Toll Free (888) 723-5549 DS-1857, Related Drawing 11616 Harry Hines Blvd. • P.O. Box 29242 • Dallas, TX 75229...
- Page 4 Specifications are subject to change without notice. Pressure ratings subject to change due to temperature and other environmental considerations. e-Dial™ gauges are designed for center line mounting on bulk storage tanks, or angle mounting on bobtails or transports. Materials of construction are carefully selected for compatibility with liquid to be gauged, so the unit you are about to install can be expected to give long and trouble-free services.
- Page 5 2 screws (0040-00413) each bracket. You may use 4 of the 6 screws from removal of existing dial brackets for 8” dial. 4. Provided with the e-Dial™ are two metal standoffs. Screw the standoffs on the existing mounting bracket holes where the 4”...
-
Page 6: Safety Barrier Installation Instructions
This is the power input for the device. e-Dial™ comes with a minimum 24ft (7.3m) cable that can be cut to length. Use only a current limited source of ≤ 4.5 Amp to the e-Dial™ Barrier. Utilisez uniquement une source de courant limitée de ≤ 4.5 Amp à la barrière e-Dial™. - Page 7 Barrier. L’équipement fait référence au neutre comme à la terre. L’utilisateur final doit s’assurer qu’il n’y a pas de différence de potentiel entre les connexions neutres entre le e-Dial™ et la barrière d’ e-Dial™.
-
Page 8: Safety Specifications
Caution must be used when handling or cleaning products so there is no static charge buildup. Do not wipe off the e-Dial™ sensor with dry cloth. Use only water damp cloth and allow to air dry for cleaning device. Do not use or install in high charge areas. - Page 10 Barrier are certified as complete intrinsic safety system (Reference Intrinsic Safety Control Drawing SD-581) and the maximum supply voltage to the barrier should not exceed Um=32VDC. e-Dial™ Barrier device is intended to be installed in safe (non-hazardous) location and e-Dial™ sensor device is intended for...
- Page 11 Ex ia Ex ia Temperature classification Ambient −40°C to +60°C −40°C to +80°C -40°C to +60°C – Barrier temperature -40°C to +80°C – e-Dial Parameter comparison ✓ Voltage U o : 9.45 V U i : 9.45 V ✓ Current...
- Page 12 Rochester Gauges LLC Customer Service, Toll Free (888) 723-5549 DS-1857, Related Drawing 11616 Harry Hines Blvd. • P.O. Box 29242 • Dallas, TX 75229 Revision A, 11/30/2020 For more information visit rochestergauges.com info@rochestergauges.com ISO 9001:2015 CERTIFIED...
