CUBEX SkyMaster Series Manual page 8

Instructions:
Note: These terminals are not supplied when Cubex Matching Transformer is ordered with Antenna
Matching Stub dimensions: Table I
Electrical Quarter wave 75 ohm coax ; velocity factor = 0.66
BAND
10 Meters
12 Meters
15 Meters
17 Meters
20 Meters
40 Meters
Note 1- that any length 50 ohm coax maybe connected to the end of these matching stubs.
Note 2- Some experimentation may be required in adjusting each matching stub to optimize the
impedance transformation.
Note 3- 17 meters should not require any stub and match okay with 50 ohm cable.
For ¾ wave lengths multiply the lengths above by a factor of 3, excess cable may be
coiled into a 6 inch dia. Coil and taped together.
Cubex Co., Inc.
CABLE TYPE
RG11/U 75 ohm
RG11/U
RG11/U
Note 3
RG 8/U 50 ohm
RG11/U 23.35 ft (420 in)
L
Dimensions above
Pg. 8
Cubex SkyMaster Series
LENGTH (IN.) LENGTH (CM)
68 in
79 3/4 in
92 in.
Any length
172.72 cm
202.74 cm
233.68 cm
711.71 cm
05-06 Rev 0
