Freedom 650 Quick Start Manual

NEW Features!

Multi-car operation
2-stage disarm
Standard Features: Dual light flash outputs w/ selectable polarity; starter interrupt; Automatic re-
arming; Last door arming; ignition activated doorlocks; anti-carjacking protection; includes mini 6
tone siren; includes two 5 button controllers; 22 programmable features; window mount antenna;
includes AU-84TM dual zone shock sensor.
TWO 2-way Controllers included: New! 5 button blue backlit LCD 2-way controllers
feature proximity (hands-free) disarm/unlock; power save mode; keypad lock; multicar use.

Controller Operations:

Arm/Lock Button - Press and release to arm/lock. Press and hold to activate panic.
Disarm/Unlock Button -Press and release to disarm/unlock.
Small "Button 3" - Press and hold to activate auxiliary channel.
Small "Button 4" - Activate 3
Small "Button 5" - Turn on backlighting; setting times and other functions.
Button Combinations - Sensor bypass; hands free on/off; controller power-saver on/off;
keypad lock on/off; chirp or vibrate; change vehicle type icon (multicar operation).
How to Code the Controllers: Turn "on" the ignition, then press the valet switch 5 times
and wait for siren to chirp. Then press and release any button on each controller, one at a time.
The system will respond to each with an audible confirmation. Note: Choose the desired
controller vehicle type icon (car, pickup or van/SUV) before programming the controller to the system. The multi-
car operation is programmable from vehicle to vehicle by changing the controller's vehicle type icon.
Feature #
Feature #1 Pin Code (for overriding alarm)
Feature #2 Last Door Arming
Feature #3 Doors Lock With Last Door Arming
Feature #4 Auto Rearming
Feature #5 Doors Lock With Automatic Rearming
Feature #6 Siren & Horn or Horn
Feature #7 Ignition Lock
Feature #8 Ignition Unlock
Feature #9 System Trigger Cycle
Feature #10 Double Pulse Unlock
Feature #11 Immobilizer Mode
Feature #12 Shock Sensor False Alarm Bypass
Feature #13 Dome Light Delay Bypass
Feature #14 Auxiliary Channel Output
Feature #15 Auxiliary Function
Feature #16 3rd Channel Output
Feature #17 Controller Activated Anti-Carjacking
Feature #18 Open Door Activated Anti Car-Jacking
Feature #19 Ignition Activated Anti Car-Jacking
Feature #20 "Hands Free" Activated Anti-Carjacking
Feature #21 "Hands Free" Activated Anti-Carjacking
Feature #22 Lock Pulse Time
Feature #23 Factory Settings Reset
Specifications subject to change
Immobilizer mode Proximity disarm/unlock
Programmable auxiliary channels
Has siren output & horn honk output
rd channel; vehicle finder; remote anti-carjack.

Programmable Features

(B3) Remote Start Mode
11/07
Freedom 650
2-Way Keyless Entry & Security System
Proximity anti-carjack
Silent arm & disarm
Onboard doorlock relays
Omega part #
#651-09
Default Arm/Lock
1 Press options are: 2 through 12 Presses
OFF ON
ON ON
OFF ON
ON ON
Siren & Horn Siren & Horn
ON ON
ON ON
30 Seconds 30 Seconds
1 Pulse 2 Pulses
OFF ON
OFF ON
OFF ON
1.5 Second 1.5 Second
Disarm Disarm
(A/L) 30 Second Latched
OFF ON
OFF ON
OFF ON
OFF ON
OFF ON
.8 Second 4 Seconds
- Reset (all features to factory settings)
Disarm/Unlock
OFF
OFF
OFF
OFF
Horn
OFF
OFF
60 Seconds
1 Pulse
OFF
OFF
OFF
30 Seconds
Maintain Status
(D/U) 30 Seconds Upon Arm
OFF
OFF
OFF
OFF
OFF
.8 Second
