Agromehanika AGT 106 Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Rev.09/2020
SINCE 1968
AGT 1060
OPERATING INSTRUCTIONS
AGROMEHANIKA reserves the rights to make design changes or to change the product without any obligation on
informing the client before or after the changes have been made.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGT 106 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Agromehanika AGT 106

Summary of Contents for Agromehanika AGT 106

  • Page 1 Rev.09/2020 SINCE 1968 AGT 1060 OPERATING INSTRUCTIONS AGROMEHANIKA reserves the rights to make design changes or to change the product without any obligation on informing the client before or after the changes have been made.
  • Page 2 The following operating and maintenance instructions refer to this tractor. Variant/version………………………. Agromehanika d.d Hrastje 52a Serial number……………………… 4000 Kranj, Slovenia https://agromehanika.si/...

  • Page 3: Declaration Of Conformity

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 DECLARATION OF CONFORMITY The manufacturer: AGROMEHANIKA, proizvodnja in trgovina Kranj d. d. Hrastje 52 a, KRANJ, SLOVENIA hereby declares that the product: AGT 1060 tractor is manufactured in accordance with: the Regulation on the approval and market surveillance of agricultural and forestry vehicles (EU) no.

  • Page 4: Table Of Contents

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 CONTENTS DECLARATION OF CONFORMITY ........................ 2 CONTENTS ................................3 GENERAL ..............................8 TERMS ............................... 9 SAFETY ..............................10 SAFETY WARNINGS ........................11 DEALER ............................11 OPERATOR OR EMPLOYER ......................11 2.3.1 PERSONAL PROTECTION ..................... 12 2.3.2 IMPROPER USE .......................
  • Page 5 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 GENERAL DESCRIPTION OF THE TRACTOR ................34 DESCRIPTION OF THE MAIN COMPONENTS OF THE TRACTOR .......... 35 DESCRIPTION OF THE MAIN COMPONENTS OF THE CAB ............ 38 DESCRIPTION OF THE DRIVER'S SEAT ..................39 HYDRAULIC SYSTEM DESCRIPTION ..................40 4.4.1 HYDRAULIC DIAGRAM ....................
  • Page 6 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.3.3 ADJUSTING THE TOP LINK ..................119 6.3.4 ADJUSTING THE LATERAL TENSIONERS............... 121 ADJUSTING THE FRONT HYDRAULIC LIFT MECHANISM (OPTIONAL) ......122 6.4.1 ADJUSTING THE LOWER LINK ARMS ..............123 6.4.2 ADJUSTING THE TOP LINK ..................123 ADJUSTING THE HEIGHT OF THE REAR TOW HOOK ............
  • Page 7 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.2.3 THE REST FOR THE FINAL WHEEL POSITION ............165 8.2.4 WHEEL TRACK ADJUSTMENT .................. 166 ELECTRICAL SYSTEM ......................... 167 8.3.1 CHANGING THE BATTERY ..................167 8.3.2 CHANGING THE LIGHT BULBS ................. 169 CLEANING THE TRACTOR ......................177 ENGINE MAINTENANCE ......................
  • Page 8 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 TECHNICAL DATA OF THE TRACTOR ..................217 TRACTOR DIMENSIONS ......................217 9.1.1 DIMENSIONS OF THE REAR HYDRAULIC LIFT MECHANISM ......219 9.1.2 DIMENSIONS OF THE FRONT HYDRAULIC LIFT MECHANISM (OPTIONAL EQUIPMENT) ......................... 222 9.1.3 DIMENSIONS OF THE REAR TOW HOOK ..............223 9.1.4 TRACTOR WHEELBASES ....................

  • Page 9: General

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 GENERAL The AGT tractors were designed and manufactured to provide the highest level of reliability and work performance to its users. However, a lot also depends on the user, their approach to work and to subsequent maintenance and proper care of the tractor. For this purpose, these operating instructions have been prepared in such a way as to prevent the user or to minimise the risk of contact with exposed components of the tractor.

  • Page 10: Terms

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 TERMS The terms used in these operating instructions are explained below for easier understanding of the text that follows. FOPS (Falling objects protective structure), safety structure, which protects the driver in case of falling objects from above; OPS (Operator protective structure), safety structure, which protects the driver from penetrating objects;...

  • Page 11: Safety

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 SAFETY This chapter contains all the necessary information which the driver or the operator of the tractor must be aware of and therefore require particular attention. The operator must follow all safety warnings and procedures, which are required to ensure safe operation. As the operator, you must carefully read this chapter, as only proper handling will ensure your safety and protection against potential dangers that may be present while performing work with the tractor.

  • Page 12: Safety Warnings

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 SAFETY WARNINGS • Carefully read all the instructions related to safety rules in the operating instructions for your tractor. • Learn how to operate and handle your tractor and its control units; • Make sure to become familiar with all the characteristics of the tractor, including weight, loads (load carrying capacity), speed, stability of the tractor etc.

  • Page 13: Personal Protection

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • That the operator or the employer ensures proper maintenance and inspection of the tractor and its components; • That the operator or the employer ensures that damaged or faulty parts are only replaced with original products, otherwise the manufacturer may void the warranty without prejudice;...

  • Page 14: Safety Instructions Before Using The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 SAFETY INSTRUCTIONS BEFORE USING THE TRACTOR Before using the tractor, always check if all safety devices (safety belt, roll bar etc.) are correctly installed (securely attached) and functional. Only use the tractor with original parts and safety devices installed by the manufacturer.

  • Page 15: Improper Use Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • Take special care when filling up the tractor’s fuel tank. Stop the engine and allow the engine to cool down before filling the fuel tank in a well-ventilated area. In case of spillage always wipe off any fuel spilt. •...

  • Page 16: Safety Instructions During Tractor Operation

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 SAFETY INSTRUCTIONS DURING TRACTOR OPERATION When working with the tractor, always comply with the rules and road traffic regulations when driving on the road and strictly follow the safety instructions. Before commencing work, make sure that other persons, especially elderly and children, are outside of the tractor's danger area, especially when it is running or moving.

  • Page 17: Improper Use Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Always adjust your driving style to environment conditions to avoid the risk of accidents or property damage and ensure the safety and health of persons. During operation, both the tractor and its implement generate a certain level of noise. •...

  • Page 18: Safety Instructions After Operating The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 SAFETY INSTRUCTIONS AFTER OPERATING THE TRACTOR Before exiting the tractor or leaving the tractor unsupervised, take the following safety precautions. Observe the concept “Tractor stopped under safe conditions with the engine running”: • Stop the tractor. •...

  • Page 19: Safety Instructions For Operating The Tractor On Steep Slopes

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 SAFETY INSTRUCTIONS FOR OPERATING THE TRACTOR ON STEEP SLOPES • When operating the tractor, avoid working on uneven ground, steep slopes or embankments. Particular attention should be paid when driving near ditches or holes. • Adverse weather conditions can soften the ground and reduce the stability of the tractor, which can lead to slipping or even overturning, therefore you should always make sure the ground is solid before driving, particularly during poor weather conditions.

  • Page 20: Tractor Mounted Implements

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 2.8.1 TRACTOR MOUNTED IMPLEMENTS • Attach the tractor mounted implement to the three-point linkage system of the tractor and secure it with pins. The implement height and the tractor must be on the same level to enable connection to the PTO drive shaft.

  • Page 21: Improper Use Of Implements

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • Always make sure that all the protections are in place and that they cover all the rotating parts, including the “crosses” on both sides of the universal joint. • Do not use the universal joints if the safety guards are not installed. •...

  • Page 22: Improper Use Of The Tractor On The Road

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 2.9.1 IMPROPER USE OF THE TRACTOR ON THE ROAD • Do not drive aggressively, do not brake hard or make sudden sharp turns. • If you are driving on public roads, do not engage the PTO drive shaft; it can only be engaged during work.

  • Page 23: Safety Instructions For Maintenance Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 2.11 SAFETY INSTRUCTIONS FOR MAINTENANCE OF THE TRACTOR In the period of tractor operation, ensure regular maintenance of the tractor in accordance with time intervals prescribed by the manufacturer. Proper maintenance will ensure a long service life of the tractor and an appropriate level of safety.
  • Page 24 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • Do not heat the painted parts of the tractor as heating generates toxic gases with can damage your health. If any painted parts of the tractor must be repaired by welding, soldering or heating, you must first remove the paint by sanding (Fig.

  • Page 25: Improper Use During Maintenance

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 2.11.1 IMPROPER USE DURING MAINTENANCE • Do not use open fire in the vicinity of hoses under high pressure. Damage to any hose under high pressure may cause the leakage of flammable liquid (fuel, oil) and result in severe burns.

  • Page 26: Improper Use Of Weights

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 2.12.1 IMPROPER USE OF WEIGHTS • Be careful not to overload the tractor with weights installed and do not exceed the maximum weight. • Do not use weights on the tractor unless necessary. • Do not use weights that are not compatible with those prescribed by the manufacturer. •...

  • Page 27: Safety Instructions For Operating The Tractor In Forestry Operations

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 2.14 SAFETY INSTRUCTIONS OPERATING TRACTOR FORESTRY OPERATIONS When the tractor is used in forestry operations, you must be aware of potential hazards, which often occur if trees, branches or other object fall or penetrate the drivers area. •...

  • Page 28: Additional Safety Requirements

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • Any waste liquids must therefore be collected in suitable containers and disposed of correctly, in accordance with local regulations. • When the tractor reaches the end of its service life, it must be cleaned, disassembled and its materials must be sorted by individual components and taken to a waste management organization.

  • Page 29: Description Of Safety Signs On The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 2.18 DESCRIPTION OF SAFETY SIGNS ON THE TRACTOR Safety and warning signs can be found on the tractor and in the operating instructions. Take a close look of them to ensure your own safety. Follow the instructions and recommendations related to the safety precautions from the previous chapter.
  • Page 30 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Position of safety signs, rear left side view of the tractor Fig. 34 No. Position Code Meaning Description Image (sign) Danger of burns, hot surfaces Before On the 535040 Danger performing any engine cover operations, wait until the engine cools down.
  • Page 31 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 No. Position Code Meaning Description Image (sign) Danger of falling. Do not carry persons on On the front inappropriate places and and the rear 535026 Danger do not climb on and off fender the machine if the tractor is not safely stopped.

  • Page 32: Technical Specifications Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 TECHNICAL SPECIFICATIONS OF THE TRACTOR The tractor is fitted with type plates in accordance with the Commission Delegated Regulation (EU) No. 1322/2014. MANUFACTURER’S INFORMATION Fig. 35...
  • Page 33 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 DESCRIPTIONS OF TYPE PLATES A – Type plate with information about the manufacturer and the tractor, installed at the right side of the platform under the tractor's console (in the driving direction). The type plate contains the following information: 1.

  • Page 34: Replacement Parts

    Using non-original parts may void the tractor warranty coverage. It is therefore recommended that only original replacement parts or accessories, delivered by Agromehanika d.d., are used. In case of any malfunction or damage to the tractor, the manufacturer will provide the required servicing and a reliable technical support from its expert staff.

  • Page 35: General Description Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 GENERAL DESCRIPTION OF THE TRACTOR The AGT 1060 tractors are designed for different requirements or tasks in agriculture and horticulture. By adding some technical accessories, they can also be used for public utility services or forestry. Thanks to their rigid transmission with different widths, small turning radius, constant four- wheel drive and low barycentre, these tractors can also be used in hilly areas.

  • Page 36: Description Of The Main Components Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 DESCRIPTION OF THE MAIN COMPONENTS OF THE TRACTOR All the main components, including detailed explanations, are described in the following pages. Fig. 36...
  • Page 37 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 1. Driver's seat The driver’s seat has an ergonomic design, which means that it can be adjusted to the user’s working environment according to their physical features. The position of the seat allows the user to have a complete overview of the surroundings and a convenient access to the controls. 2.
  • Page 38 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 11. Rear hydraulic couplings Hydraulic couplings are used for quick connection of hydraulically powered implements. 12. Electric connection The electric connection consists of a 7-pin electrical socket to connect the electrical system of the implements (trailer). 13.

  • Page 39: Description Of The Main Components Of The Cab

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 DESCRIPTION OF THE MAIN COMPONENTS OF THE CAB A tractor equipped with a cab can be used for driving on the road. The cab is a category 1 equipment and is not suitable for working with dangerous substances because it does not provide protection for the driver in this type of work;...

  • Page 40: Description Of The Driver's Seat

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7. Windscreen washing tank The tanks contain a cleaning solution for washing the front and the rear windscreen. 8. Rotating lamp The rotating lamp is used on tractors with tractor implements exceeding the width of the tractor or on tractors with tractor mounted implements, when the rear edge of the implement extends 1.5 m beyond the rear edge of the tractor.

  • Page 41: Hydraulic System Description

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 HYDRAULIC SYSTEM DESCRIPTION The main component of the hydraulic system is the hydraulic pump, which supplies all hydraulic components. It is directly connected to the engine and connects two independent systems: • The first system supplies the lifting components and additional distributors or connectors through control devices.
  • Page 42 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 13. PTO drive shaft The PTO drive shaft is engaged through a multi plate clutch in an oil bath, which is independent and separate from the main clutch. The housing is fitted with an integrated choke valve for soft starting or preventing a sudden thrust of the drive shaft when the solenoid valve is switched on.

  • Page 43: Hydraulic Diagram

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.4.1 HYDRAULIC DIAGRAM Hydraulic circuit diagram Fig. 41...

  • Page 44: Description Of The Front Hydraulic Lift Mechanism (Optional)

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 DESCRIPTION OF THE FRONT HYDRAULIC LIFT MECHANISM (OPTIONAL) The tractor can be equipped with a front three-point hydraulic lift mechanism. It is controlled by means of two single-acting hydraulic cylinders and comes equipped with quick couplings, which are used to connect the mechanism to the hydraulic system.

  • Page 45: Description Of The Rear Hydraulic Lift Mechanism

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 DESCRIPTION OF THE REAR HYDRAULIC LIFT MECHANISM As standard, the tractor is equipped with a category I three-point linkage system for pulling implements. The three-point linkage system basically consists of two lower link arms and a top link.
  • Page 46 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 The lower link arms can be connected in two different ways, which are further divided into several options: • Ball link connection can be made when the ball has a standard bore, which is used to insert the connection bolt installed on the implement to be attached to the tractor.

  • Page 47: Description Of The Main Safety Components

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 DESCRIPTION OF THE MAIN SAFETY COMPONENTS The main safety components of the tractor are described in the following pages. Fig. 45...
  • Page 48 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 1. Front roll bar (ROPS) The roll bar protects the driver in case of an accident or a tractor rollover. The front roll bar is designed so it can be moved to horizontal position. This is only allowed when it cannot be avoided due to circumstances during work, on even ground where there is no risk of rollover and for short distances.
  • Page 49 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8. Front PTO drive shaft switch (optional equipment) For engaging and disengaging the front drive shaft. • When the switch is on, it prevents the engine from being started. 9. Switch on the driving direction selector lever (neutral gear) The indicator lamp “N”...

  • Page 50: Description Of Instruments And Controls

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 DESCRIPTION OF INSTRUMENTS AND CONTROLS For easier explanation and understanding of all the controls on the tractor, this chapter is divided into different categories. • Signs on controls; • Tractor console; • Driving controls; • Operating controls;...
  • Page 51 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 No. Position Code Meaning Description Image (sign) Approximate representation of engine On the 535037 Important rpm according to the console accelerator lever position. Left gear shift lever - On the illustration speed transmission groups: between the turtle (intermediate), seat and the...
  • Page 52 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 No. Position Code Meaning Description Image (sign) On the protection Control lever no. 3 of the (see Fig. 46) - controls 535047 Important control quick couplings (right side marked with red. of the seat) On the Rotary knob (choke...
  • Page 53 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 No. Position Code Meaning Description Image (sign) selecting engagement method On the left, of the PTO drive next to the 535013 Important shaft; standard, seat, at the though the engine or bottom synchronized with the gearbox.
  • Page 54 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Position of signs, rear left side view of the tractor Fig. 48 No. Position Code Meaning Description Image (sign) Under the rear roll bar, Selection of the PTO 535011 Important next to the drive shaft rpm lever...

  • Page 55: Tractor Console

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.2 TRACTOR CONSOLE Illustration of devices installed on the console, which are described in detail on the following pages. Fig. 49 1. Dashboard 2. Ignition key 3. Multi-function lever, it controls the lamps, the horn and direction indicators 4.
  • Page 56 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.2.1 DASHBOARD The dashboard provides the required visual information to the driver of the tractor. The instruments or gauges indicate the current state of tractor operation and the indicator lamps inform or alert to the general state of the tractor. Fig.
  • Page 57 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4. Indicator lamps (meaning of symbols) Symbol Description Signal type General alarm: This warning lamp indicates a Red LED lamp malfunction. Parking brake (activated) This warning lamp flashes if the parking brake was not activated when the driver leaves the seat during tractor Red LED lamp operation.
  • Page 58 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Exhaust gas: This warning lamp turns on when the exhaust gas temperature is too high. Orange LED lamp This can be caused by the DPF filter blockage and may require filter regeneration. Glow plugs: This indicator lamp illuminates before the engine is started or when the ignition key is in position 1.
  • Page 59 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6. Multifunction display Display overview during normal tractor operation Fig. 52 A) Tractor speed, it indicates the current speed of the tractor. B) Time and date, it indicates the exact time and date. C) Rear PTO drive shaft revolutions, it indicates the number of revolutions of the rear PTO drive shaft when the PTO shaft is engaged.
  • Page 60 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 H) Field, it indicates the condition of the DPF filter: • DPF filter regeneration, yellow LED, this warning lamp turns on then regeneration is required. If filter regeneration setting was not change, it is automatically performed. •...
  • Page 61 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Level Scale Warning sign Description • The engine is running at full “Level 3” forced power (100%); • Forced shut-down by the user is regeneration required Illuminated not possible. DPF filter clogging • Automatic regeneration is not level is 95% possible, even if the operating conditions are met.
  • Page 62 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.2.2 USER MENU Description of functions which can be adjusted by the user. 1. Date and time setting Before adjusting this setting, the tractor must be immobilized and safely stopped, with a zero speed on the gauge. To adjust the clock: •...
  • Page 63 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Forced regeneration can be manually started when the DPF filter blockage reaches level 3 (recommended). This is required when it reaches level 4, with the warning sign illuminated, to prevent further blockage and the resulting engine damage. Forced regeneration setting: •...
  • Page 64 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 IMPORTANT: DPF filter regeneration can only be forcibly turned off until the next time the engine is stopped. Each time the engine is started, this setting switches to automatic mode! IMPORTANT: Automatic regeneration is performed when the filter blockage reaches 80 or 90%, at the minimum water temperature 65°C or higher and the engine rpm range higher than idle.
  • Page 65 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.2.3 IGNITION KEY It is used to activate the electrical system and start the tractor’s engine. The key can be turned to the following positions: P – The parking lamps turn on. Push the key into the lock and turn it to the left. When in this position, the key can be removed from the lock.
  • Page 66 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.2.5 SWITCHES FOR ACTIVATING THE OPERATING FUNCTIONS These switches are located under the steering wheel and are used to activate the following functions. • Switch in position 0, the function is off (the indicator lamp in the switch is off). •...
  • Page 67 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.2.6 SWITCHES FOR ACTIVATING THE OPERATING FUNCTIONS These switches are located on the right side of the steering wheel and are used to activate the following functions. • Switch in position 0, the function is off (the indicator lamp in the switch is off). •...

  • Page 68: Driving Controls

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.3 DRIVING CONTROLS All driving controls required by the user for driving are described below. Fig. 63 1. Foot brake, when driving, it is used to reduce the speed or stop the tractor. 2. Parking brake, it is used to block the tractor in place; comply with the rule “stop the tractor when conditions are safe”.
  • Page 69 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 64 To disconnect the brake pedals, follow the procedure shown in the figure Fig. 64. Pull the safety latch upwards (figure 1), then move it to the left (figure 2) and insert it back into the groove (figure 3).
  • Page 70 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.3.3 CLUTCH The clutch is used to control the tractor when driving off and shifting gears. The clutch is controlled by means of the pedal installed on the left side of the driver's seat. When the seat is turned, the clutch pedal is pushed upwards; refer to the chapter “Turning the seat”.
  • Page 71 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.3.6 CONTROL LEVERS 1. Speed group adjustment lever (reduction gear) • The rabbit position activates the fast transmission level. • The turtle position activates the intermediate transmission level. • The snail position activates the slow transmission level. 2.

  • Page 72: Operating Controls (Pto Drive Shaft)

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.4 OPERATING CONTROLS (PTO DRIVE SHAFT) The figure below illustrates all controls related to the operation of the PTO drive shaft. The data regarding the rotation speed of the drive shaft are provided in the chapter “Technical data – PTO drive shaft”.

  • Page 73: Hydraulic Controls

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • “Position 2” – The synchronized method of PTO drive shaft connection to the gearbox; move the lever upwards. The PTO drive shaft rotates in relation to the gearbox ratio; depending on the driving direction, it rotates to the left or to the right. When connected to the gearbox, the PTO drive shaft can only be engaged when the tractor is moving! 3.
  • Page 74 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Below is the description of functions attributed to control levers for the standard hydraulic system, see Fig. 71: A. Lever, for controlling the front hydraulic lift mechanism. B. Lever, for controlling the hydraulic system through a quick coupling. C.
  • Page 75 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.5.2 HYDRAULIC SYSTEM CONTROL THROUGH QUICK COUPLINGS Control lever B - Control lever C Each control lever directs the oil from the pressure circuit, by means of a control valve in the control device, through two hydraulic connections or quick couplings for controlling the external implements equipped with a hydraulic system and a double-acting hydraulic cylinder.
  • Page 76 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • If the lever is moved down along the groove to position 3, the oil flow from the single- acting hydraulic cylinder is released back into the tractor’s hydraulic system. By means of an external acting force or an integrated spring, the cylinder on the connection begins to lower (depending on the version).

  • Page 77: Cab Controls

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.8.6 CAB CONTROLS These controls are located on the roof of the upper part of the cab. The ventilation device installed above the roof supplies fresh air into the cab through the lateral filters and provides the option of air heating.
  • Page 78 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 A) Switch, for controlling the work lights on the cab, the main on/off switch is located on the console, see the section “Switches for turning on the work functions”. • Position 0, all four work lights are on; •...
  • Page 79 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 3. Fuses The cab system has separate fuses for the protection of the electrical system. See description in the chapter “Electrical system of the tractor”. 4. Air vents Adjustable slots for internal air circulation The slots are opened and closed by rotating the rotary knob and pressing the blades.

  • Page 80: Description Of Optional Equipment

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 DESCRIPTION OF OPTIONAL EQUIPMENT This chapter describes optional equipment, which can be installed according to the requirements of the tractor operator. Fig. 84...

  • Page 81: Front Hydraulic Lift Mechanism

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 A. Front hydraulic lift mechanism, it is provided with a protection system consisting of hoses for the protection of radiators and the engine cover and it can be fitted with a top link, which is used for attaching the third linkage point, see description below. B.

  • Page 82: Weights

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.9.2 WEIGHTS Weights are used to increase the stability of the tractor with implements installed. For the standard tractor version, two types of wheel weights can be used, depending on the wheels installed. 4.9.2.1 WHEEL WEIGHTS These weights are installed on all four wheels –...

  • Page 83: Additional Hydraulic Controls

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.9.3 ADDITIONAL HYDRAULIC CONTROLS Additional control devices are installed on the left side of the tractor. Each lever is used to control a particular function through a control valve installed in the control device. Description of control levers and their arrangement according to function is available on the following pages.
  • Page 84 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 The control lever E is used to activate the blue hydraulic connections A or the quick couplings for controlling external implements, which are equipped with a hydraulic system with a single or a double-acting cylinder. The control lever has four positions: •...
  • Page 85 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.9.3.2 ADDITIONAL CONTROL DEVICE ON HYDRAULIC SYSTEM WITH A FRONT HYDRAULIC LIFT MECHANISM Control levers A, B and C, see Fig. 87, are fitted as standard equipment and their functions are described in the chapter “Hydraulic controls”. Control lever D, see Fig.
  • Page 86 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 90 The control lever F is used to activate the orange hydraulic connections B or the quick couplings for controlling external implements, which are equipped with a hydraulic system with a single or a double-acting cylinder. The control lever has four positions, which are the same as with control lever E, see description above.

  • Page 87: Rear Hydraulic Lift Mechanism

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.9.4 REAR HYDRAULIC LIFT MECHANISM The rear hydraulic lift mechanism can be fitted with a wider range of optional equipment and the user can choose between different lower link arms. The rear lift mechanism also enables two- way operation.
  • Page 88 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.9.4.2 TOP LINK Optionally, the user may replace the standard mechanical top link with a hydraulic top link for hydraulic adjustment of the top link or the connection bar, which is used for connecting the third linkage point, directly from the driver’s seat by means of a shift lever.
  • Page 89 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • Two-way operation of hydraulic cylinder, the pressure from hydraulic oil acts on the piston in the cylinder alternately from both sides (depending on the position of the control lever), which allows the cylinder to be moved in both directions. LIFTING LOWERING DISCHA...
  • Page 90 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 When the control lever is in position 3, the operator can use the float position option, which means that the implement attached to the tractor will automatically adapt to the ground. This only applies if the three-way valve is in position 1, see description below. With this version of hydraulic lift mechanism, it is possible to convert the double-acting hydraulic cylinder into a single-acting cylinder by means of an additional three-way valve installed on the right side, next to the driver's seat.

  • Page 91: Floating Hydraulics With Support

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.9.5 FLOATING HYDRAULICS WITH SUPPORT This figure shows all the control devices required for controlling the floating hydraulics with support. Fig. 96 Before commencing work with floating hydraulics with support, the pressure in the hydraulic accumulator must be adjusted to a specific pressure value, which can be read from the gauge C and depends on the weight of the implement.
  • Page 92 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 To be adjusted correctly, the pressure according to the weight of the implement must be 20% lower than pressure reading on the gauge C. Readjust the pressure with control lever A for lifting the hydraulic mechanism. When the pressure adjustment in the hydraulic accumulator is successfully completed, move the lever B on the bottom valve B to position 2.

  • Page 93: Hydraulic Brake On A Trailed Implement

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.9.6 HYDRAULIC BRAKE ON A TRAILED IMPLEMENT Optionally, the tractor can also be equipped with a system for connecting trailed implements with a hydraulic brake. Fig. 97 Operation When the brake pedal is depressed, the valve on the hydraulic brake redirects the oil from the pressure circuit through a hydraulic conductor to the braking system of the trailed implement and the implement starts to brake.

  • Page 94: Description Of Devices For Using The Tractor On The Road

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 IMPORTANT: Before making the connection, check that the system of the trailed implement is suitable for the operating pressure of the tractor. IMPORTANT: Always make sure the pressure is released before performing and work on the hydraulic system. To do this, shut down the tractor and depress the brake pedal several times.

  • Page 95: Description Of The Electrical System Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.11 DESCRIPTION OF THE ELECTRICAL SYSTEM OF THE TRACTOR The main components of the tractor’s electrical system are described below. 4.11.1 BATTERY The battery with a rated voltage of 12 V is a source of electric power for the entire power supply system of the tractor.

  • Page 96: Alternator

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 A large amount of power is consumed when the engine is started, which is why the following must be taken into account when using the starter: • The started can be activated, without interruption, for a maximum of 10 seconds. •...

  • Page 97: Fuses

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.11.5 FUSES When a blown fuse is detected, remove the fuse box cover and replace the blown fuse. If the fault keeps re-occurring, the electrical system must be inspected by a service technician or a qualified person.
  • Page 98 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.11.5.1 FUSES IN THE ENGINE COMPARTMENT The fuses are located in a housing on the positive side of the battery. To access the fuses, open the engine cover and remove the cover of the fuse box. Arrangement of fuses (diagram) Fig.
  • Page 99 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.11.5.2 FUSES IN THE TANK COMPARTMENT The fuses are located inside a fuse bow, which is on the right side of the tank, near the roll bar bracket. Relays, described below, are also installed next to the fuses. Before replacing a relay, safely stop the tractor as described in the chapter “Fuses”.
  • Page 100 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Designation/position Description Rating Cab (F13) 15 A Rear stop lamp (F8) 15 A Direction indicators (F9) 15 A Air conditioning (F20) 10 A Rotating lamp (F14) 10 A Engine computer (F3) 7.5 A Position lights (F6) 15 A Table with a description of relays Designation/position Description...
  • Page 101 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.11.5.3 FUSES IN THE CAB The fuses are located in a fuse box at the left side of the cab roof. To access the fuses, open the cover of the fuse box. Arrangement of fuses and relays (diagram) Fig.

  • Page 102: External 7-Pin Socket For Implements

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 4.11.6 EXTERNAL 7-PIN SOCKET FOR IMPLEMENTS The socket is made in accordance with the standard ISO 1724. It has seven pins and it is designed to connect the electrical system of trailed or mounted implements to the tractor. Fig.

  • Page 103: Transporting The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 TRANSPORTING THE TRACTOR When transporting the tractor, the operator or the driver of the transport vehicle must comply with the manufacturer's instructions as laid out in the operating instructions. Depending on the final destination, there are several possible solutions available for transporting the tractor on various means of transport.
  • Page 104 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • Turn the rotating knob for damping the lowering of the rear hydraulic lift mechanism all the way to block the lowering operation; refer to the chapter “The rear hydraulic lift mechanism control”: • Slowly drive the tractor up the ramp or the loading ramp and onto the transport vehicle.

  • Page 105: Unloading

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 UNLOADING The procedure for unloading the tractor is carried out in reverse order of the loading procedure. Before driving the tractor off the transport vehicle, make sure that the load-bearing capacity of the loading ramp is sufficient. Adjust the position of the ramp to the wheelbase of the tractor, see, and securely fasten it to the transport vehicle and the ground.
  • Page 106 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 If possible, keep the engine running during the towing process for easier steering wheel control. Otherwise the hydraulic system is turned off, which makes the steering wheel stiff and harder to turn. Fig. 114 WARNING: Before towing, always make sure that the main bolts on the tractor and the towing vehicle are correctly inserted and blocked with a safety pin.

  • Page 107: Tractor Adjustments

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 TRACTOR ADJUSTMENTS The person authorized to adjust the tractor must comply with the basic safety instructions and take the necessary precautions to ensure the appropriate level of safety in the place of work. Unless otherwise specified for exceptional cases, all tractor adjustments must be performed with the engine off.
  • Page 108 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 C) Adjusting the suspension of the seat, see Fig. 115 The seat suspension system can be individually adjusted according to the terrain where you intend to perform work or drive. Use the rotary knob to adjust the suspension of the seat. •...

  • Page 109: Rotating The Driver's Seat

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.1.2 ROTATING THE DRIVER'S SEAT The tractor provides the option of seat rotation by 180°. Rotating the seat will simultaneously rotate the entire console with instruments and controls. Rotating the seat also activates a switch valve under the dashboard, which automatically determines the position and reverses the oil flow in the hydraulic system to match the steering to the direction of steering wheel turning when the operator drives in reverse.
  • Page 110 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • Release the safety device 7 and lift the seat. The gas spring ensures that the seat remains in the upright position. Fig. 117 • Rotate the seat to the right (clockwise) by 180°. Fig. 118 •...

  • Page 111: Steering Wheel Adjustment

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.1.3 STEERING WHEEL ADJUSTMENT The operator is able to adjust the steering wheel of the tractor according to his ergonomic needs. Safely stop the tractor and perform the adjustment with the engine off and the parking brake applied.

  • Page 112: Adjustment Of Rear-View Mirrors

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.1.4 ADJUSTMENT OF REAR-VIEW MIRRORS Rear-view mirrors, which can be adjusted to the ergonomic needs of the operator, provide a good view of the rear-view field. Horizontal adjustment To make a horizontal adjustment, loosen the screws (1) on the bracket and move the mirror by hand to the left or to the right until you reach the desired position.

  • Page 113: Adjusting The Lights

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 ADJUSTING THE LIGHTS This chapter describers the lights on the tractor, which can be adjusted. 6.2.1 ADJUSTING THE FRONT HEADLIGHTS To adjust the front headlights, position the tractor on a horizontal surface, make sure the tyre pressure is correctly adjusted and that the front wheels are straight.

  • Page 114: Adjusting The Working Lamps

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.2.1.1 ADJUSTMENT To determine the projection points of headlights on the wall, drive the tractor to the wall with the headlights on, mark the middle point of the light beam, then back-up the tractor until it is 5 m from the wall.

  • Page 115: Adjusting The Working Lamps (Version With A Cab)

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.2.3 ADJUSTING THE WORKING LAMPS (VERSION WITH A CAB) Adjusting the lamps up and down, this adjustment can be performed manually. If this is not possible, do the following: • First, loosen the screw on the articulated part of lamps. •...

  • Page 116: Adjusting The Rear Hydraulic Lift Mechanism

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 ADJUSTING THE REAR HYDRAULIC LIFT MECHANISM With suitable adjustments, this tractor model allows for the connection of category I implements. Before connecting an implement for the first time, it is important to check that the weight does not exceed the maximum permissible axle load on the tractor.

  • Page 117: Adjusting The Lower Link Arms

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.3.1 ADJUSTING THE LOWER LINK ARMS This chapter describes how to adjust the link arms with standard and automatic linkage systems, with two possible versions for a fixed connection to the link arm or adjustable connection. 6.3.1.1 STANDARD LINKAGE WITH A BALL LINK To adjust the lower link arms: •...
  • Page 118 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.3.1.3 AUTOMATICALLY CONTROLLED LINKAGE FOR IMPLEMENTS WITH A BALL JOINT (OPTIONAL) The automatic linkage is a separate component, which is moved along the link arm. Vertical adjustment can be made by means of an adjustable arm and horizontal adjustment can be made by moving the linkage along the arm to the left and to the right.

  • Page 119: Adjusting The Vertical Tensioners

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.3.2 ADJUSTING THE VERTICAL TENSIONERS The adjustment of vertical tensioners regulates the height of lower link arms. Extending the tensioners reduces the height to which the lower link arms are lifted and retracting the tensioners increases the lift height.

  • Page 120: Adjusting The Top Link

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.3.2.2 VERTICAL HYDRAULIC TENSIONER The vertical hydraulic tensioner is adjusted with a control lever on the control device, which is used for controlling the double-acting hydraulic system. • The tensioner is retracted by moving the lever upwards in position 1 and extended by moving the lever downwards in position 2.
  • Page 121 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.3.3.1 STANDARD TOP LINK The standard top link is mechanically operated and manually adjusted according to the procedure below. • Release the safety lever (1). • The top link is extended by rotating the handle (2) on the central part of the bar in the clockwise direction and retracted by rotating in the opposite direction.

  • Page 122: Adjusting The Lateral Tensioners

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 140 6.3.4 ADJUSTING THE LATERAL TENSIONERS The lateral tensioners are designed to limit or prevent lateral movement of the implement. They are adjusted when the implement is already attached to the tractor. Manually adjust the lateral tensioners by following the procedure below: •...

  • Page 123: Adjusting The Front Hydraulic Lift Mechanism (Optional)

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 ADJUSTING THE FRONT HYDRAULIC LIFT MECHANISM (OPTIONAL) With suitable adjustments, this tractor model allows for the connection of category I implements. Before connecting an implement for the first time, it is important to check that the weight does not exceed the maximum permissible axle load on the tractor.

  • Page 124: Adjusting The Lower Link Arms

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 6.4.1 ADJUSTING THE LOWER LINK ARMS The automatic connection is fixed and can only be adjusted vertically with the adjustable arm. To adjust the lower link arms: • Remove the safety pin (1) and pull out the bolt (2). •...

  • Page 125: Adjusting The Height Of The Rear Tow Hook

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 ADJUSTING THE HEIGHT OF THE REAR TOW HOOK The tow hook is designed for attaching trailed implements and is suitable for single-axle or double-axle trailers. When performing the attachment for the first time, it is important to check whether the tow hook on the tractor is suitable for the traction load and the vertical load on the attachment point of the trailed implement.

  • Page 126: Operation Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 OPERATION OF THE TRACTOR Before operating the tractor, the driver must always read the operating and maintenance instructions, become familiar with the operating controls and perform a test drive with the tractor. • For a proper operation of the tractor, it is important to be familiar with the operation of all the operating controls.

  • Page 127: Using The Roll Bar

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 USING THE ROLL BAR Before starting to work, always make sure that the roll bar is properly installed in the upright position. The roll bar can only be lowered when the nature of work does not allow otherwise, but only over short distances and in areas where there is no danger of rollover.
  • Page 128 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 After the drive is finished, immediately raise the roll bar in the upright position. To raise the roll bar, follow the procedure below. • Before raising the roll bar, make sure that the operating area is safe to avoid any injuries when handling the roll bar.

  • Page 129: Starting The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 STARTING THE TRACTOR When purchased, the tractor is immediately ready for use. However, we RECOMMEND that the tractor is not operated at full load for at least 20 hours of operation to ensure that all the moving parts are properly worn in.
  • Page 130 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 To start the tractor, follow the instructions below, see Fig. 149 • Always turn off all consumers connected to the electrical system (lights, wipers, fans etc.). • Sit on the driver’s seat. • Depress the brake pedal (H) or activate the parking brake (I) to avoid losing control over the tractor on uneven ground.

  • Page 131: Shutting Off The Engine

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 WARNING: DO NOT accelerate to full speed when the engine is cold, particularly if the tractor is equipped with a turbo charger. Leave the engine running for at least a few minutes to ensure that the oil is heated slowly and the engine parts are properly lubricated! If the engine does not start •...

  • Page 132: Starting The Engine Using A Battery

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.3.3 STARTING THE ENGINE USING A BATTERY When the tractor fails to start because the battery is weak, you can use the battery of another vehicle. Both batteries must have the same nominal voltage (12 V DC) and the equal or greater current.
  • Page 133 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Connection and disconnection diagram, see Fig. 152 Order 2 – 4 – 3 – 1 Connecting the cables 1 – 3 – 4 – 2 Disconnecting the cables A – Discharged battery B – Auxiliary battery Fig.

  • Page 134: Engine Cover

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 ENGINE COVER The engine cover protects the engine assembly and the other components against external factors or damage, which may occur during work. To lift the engine cover, follow the procedure below. • Insert the hex key (6 mm) into the lock through the opening in the cover. •...

  • Page 135: Using The Tractor Cab

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 USING THE TRACTOR CAB This chapter provides some instructions for handling the cab doors and windscreens. 7.5.1 CAB DOORS Opening the doors • To open from the outside, push the button on the handle and pull the door towards you. •...
  • Page 136 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 156 Partial opening of the front windscreen The closing mechanism enables the partial opening position of the windscreen. To do this, follow the procedure described below: • Open the windscreen and move it forward (1); •...

  • Page 137: Rear Windscreen

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.5.3 REAR WINDSCREEN Opening the rear windscreen • To open the rear windscreen, turn to handle to the left (anti-clockwise direction). • Release the handle. The windscreen will slowly open to the final position by means of gas springs.

  • Page 138: Pto Drive Shaft

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 PTO DRIVE SHAFT The PTO drive shaft is used for direct transmission of drive to the implement on the tractor. 7.6.1 PTO DRIVE SHAFT ENGAGEMENT The controls for operating the PTO drive shaft are described in the chapter “Operating controls – PTO drive shaft”.
  • Page 139 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Conditions for engaging the PTO drive shaft, driver in the seat (short description) Condition Action Driver's seat activated All PTO control levers activated The switch on the console is activated IMPORTANT: For safety reasons, the PTO drive shaft will disengage after 7 seconds when the driver leaves the seat! It can only be engaged again when the operator sits back on the seat or engages the shaft through the external switch on the fender.
  • Page 140 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Conditions for engaging the PTO drive shaft, driver not in the seat (short description) Condition Action Driver's seat NOT activated Parking brake activated All PTO control levers activated The PTO engagement switch on the console activated The switch on the fender activated Fig.

  • Page 141: Pto Drive Shaft Rotation

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.6.2 PTO DRIVE SHAFT ROTATION Diagram of PTO drive shaft rotation according to the operation mode. Tractor driving Operation mode PTO drive shaft rotation direction Driven through the Rotating to the left (anti-clockwise Forwards gearbox direction) Driven through the Rotating to the right (clockwise...

  • Page 142: Universal Joint

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 UNIVERSAL JOINT The universal joint IS NOT included with the tractor and is a part of the implement. 7.7.1 CONNECTING THE UNIVERSAL JOINT Before connecting the universal joint, always stop the tractor in safe conditions and shut off the engine.
  • Page 143 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 164 WARNING: Do not use the universal joints if protective devices are not in place! DANGER: If the universal joint is connected to the tractor first and it accidentally engages, it may start to wobble and cause serious injuries or death! If the universal joint is too long and needs to be shortened, disassemble the universal joint and separately install each part to the PTO shaft of the...

  • Page 144: Disconnecting The Universal Joint

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 WARNING: The tubes of the universal joint must overlap by a minimum of 150 7.7.2 DISCONNECTING THE UNIVERSAL JOINT To disconnect the universal joint from the tractor and the implement (mounted or trailed), follow the procedure below. •...

  • Page 145: Use Of Implements

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 USE OF IMPLEMENTS Connection and disconnection of the implement to the rear hydraulic lift mechanism of the tractor is usually performed by the operator alone, but it can also be done with the assistance of another person who can show to the driver or the operator the accuracy of approaching the tractor to the implement.
  • Page 146 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 WARNING: The manufacturer prepared an assessment of risks, which are only applicable for the tractor without an implement installed or in combination with an implement determined by the manufacturer. The operator must therefore be familiar with all the risks which may occur when installing an implement not prescribed by the manufacturer of the tractor and must take full responsibility in case of an accident! Fig.
  • Page 147 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 WARNING: When attaching the implement, take care to avoid crushing of body parts! To disconnect the implement from the tractor, follow the procedure below. • Stop the tractor in safe conditions. • Lower the support legs on the implement (if equipped). •...
  • Page 148 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • Connect all electrical and hydraulic connections of the implement to the connection system on the tractor. • Install the universal joint, first to the PTO drive shaft on the side of the implement and then on the side of the tractor, refer to “Connecting the universal joint”.
  • Page 149 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 WARNING: When attaching the implement, take care to avoid crushing of body parts! DANGER: After installing the universal joint, always make sure that the safety devices are securely attached and functional and the safety pins are locked in position to prevent the universal joint from coming off the implement or the tractor.

  • Page 150: Connecting And Disconnecting The Implement On The Front Hydraulic Lift Mechanism

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.8.2 CONNECTING AND DISCONNECTING THE IMPLEMENT ON THE FRONT HYDRAULIC LIFT MECHANISM The description of the connection procedure is based on the assumption that the front hydraulic lift mechanism is already adjusted for the implement, otherwise a new adjustment is required first, refer to the chapter "Adjusting the front hydraulic lift mechanism".
  • Page 151 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 175 To disconnect the implement from the tractor, follow the procedure below. • Stop the tractor in safe conditions. • Lower the support legs on the implement (if equipped). • Lower the implement to the ground using the lever on the control device. •...

  • Page 152: Connecting And Disconnecting The Implement On The Rear Tow Hook

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.8.3 CONNECTING AND DISCONNECTING THE IMPLEMENT ON THE REAR TOW HOOK The description of the connection procedure is based on the assumption that the tow hook is already adjusted for the implement, otherwise it must be adjusted again, refer to “Adjusting the height of the rear tow hook”.

  • Page 153: Using Connection Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 USING CONNECTION OF THE TRACTOR This chapter explains how to use all hydraulic and electric connection installed on the tractor. 7.9.1 USING HYDRAULIC CONNECTIONS Before installing hydraulic connection hoses, make sure that hydraulic connections and hydraulic connection hoses are not damaged and check their length between the tractor and the implement to ensure smooth operating during work.

  • Page 154: Using Electric Connections

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 To disconnect hydraulic connection hoses • Stop the tractor in safe conditions, turn off the engine and lower the implement (mounted). • Release the pressure from the hydraulic system. • Disconnect hydraulic connection hoses. Push the hose towards the connection and then pull it back vigorously to release it.

  • Page 155: Using The Weights

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.10 USING THE WEIGHTS The weights can only be installed and removed from the tractor in areas with suitable equipment and which provide safe working conditions (suitably equipped workshops). WARNING: When installing or removing weights, take care to avoid crushing of body parts! WARNING: When installing wheel weights, always ensure that the weight is evenly distributed on both sides of the tractor.

  • Page 156: Kg Wheel Weights

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 179 7.10.2 48 KG WHEEL WEIGHTS These wheel weights are designed for 15-inch wheels. To install the weights, follow the procedure below; refer to the figure Fig. 180. • Unscrew the wheel nuts (1) and remove the wheel, refer to the chapter “Installation of wheels”.

  • Page 157: Recommendations For Using The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.11 RECOMMENDATIONS FOR USING THE TRACTOR As the operator, you must always follow the recommendations described below. • Even if you are familiar with them, always test all operating controls, particularly the control devices for starting and stopping before using the tractor for the first time. •...

  • Page 158: Using The Tractor On The Road

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.11.1 USING THE TRACTOR ON THE ROAD The tractor can only be used on the road when in perfect technical condition, after passing the roadworthiness test and registration, and if the driver has a valid driver's license. Comply with the following instructions when driving the tractor on the road.

  • Page 159: Driving The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.11.2 DRIVING THE TRACTOR To start driving the tractor, follow the instructions for starting described below. • Depress the clutch pedal (1) and hold it down. • Start the tractor's engine, refer to the chapter “Starting the engine”; •...

  • Page 160: Extended Period Of Inactivity And Restarting The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.12 EXTENDED PERIOD OF INACTIVITY AND RESTARTING THE TRACTOR This chapter provides instructions in case the tractor will not be used for a while, for example, before the winter season. 7.12.1 EXTENDED PERIOD OF INACTIVITY OF THE TRACTOR If the tractor will not be used for some time, carry out the following operations to ensure that some vital components remain functional.

  • Page 161: Tank Filling

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 7.13 TANK FILLING Only use diesel fuel complying with the standards prescribed by engine manufacturer. For detailed information, read the engine operating instructions. It is recommended that you never run the tank completely empty, as this may interrupt the fuel supply to the entire system, which must be vented again in this case.

  • Page 162: Tractor Maintenance

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 TRACTOR MAINTENANCE As the operator, you must always follow the maintenance recommendations described below. • Regularly perform maintenance operations on the tractor. Proper maintenance ensures a long-life span and performance. • Only use original replacement parts for replacing worn parts and only use oils and lubricants recommended by the manufacturer.

  • Page 163: Wheels

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 WHEELS Comply with the following instructions before changing the wheels. • Park the tractor on a solid and level surface, activate the parking brake and immobilise the tractor by placing safety wedges under the wheels. •...

  • Page 164: Tyres

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Tightening torques Description Dimensions Torque Nm / Kgm Rim screws M 14 x 1,5 150 / 15.3 Wheel nuts M 16 x 1,5 210 / 21.4 IMPORTANT: Regularly check that the nuts and screws on front and rear wheels are tightened according to the prescribed tightening torque.
  • Page 165 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.2.2.1 TYRE PRESSURE CHECK Check the tyre pressure with the tractor weights and implements removed and by following the procedure described below. • Stop the tractor on a level and solid surface. • Shut off the tractor's engine (ignition key in position 0). •...

  • Page 166: The Rest For The Final Wheel Position

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.2.3 THE REST FOR THE FINAL WHEEL POSITION The rest is designed to protect the steering mechanism against sudden loads when the wheel is turned to the final turning position. To adjust the rest, follow the procedure below. •...

  • Page 167: Wheel Track Adjustment

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.2.4 WHEEL TRACK ADJUSTMENT The rim is assembled in such a way that the connective plate is asymmetrically welded to the arch to allow the base plate to be attached in two different positions. • If the base plate is turned to the other side of the connective plate, the rim and the base plate can be positioned in four ways, see Fig.

  • Page 168: Electrical System

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 ELECTRICAL SYSTEM Before performing maintenance work on the electrical system, stop the tractor in safe conditions, turn off the main switch for disconnecting the battery, refer to “Description of the main safety components”. 8.3.1 CHANGING THE BATTERY Check the batter charge level or the electrolyte level.
  • Page 169 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Connecting the battery • Place the new battery (1) back into the battery compartment; • Install the bracket (2) and tighten the screw (3); • Connect the cables to both battery terminals, first connect the positive cable to the positive terminal and then connect the grounding cable to the negative terminal.

  • Page 170: Changing The Light Bulbs

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.3.2 CHANGING THE LIGHT BULBS The figure shows the position of lights on the tractor. To change the light bulbs, see description below. • A – Front headlights • B – Lamp assembly on the front fenders •...
  • Page 171 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 197 8.3.2.2 LAMP ASSEMBLY ON THE FRONT FENDERS The lamp assembly on the front fenders includes • two position lights (1); • two direction indicators (2). Fig. 198 Position light The position lights use LED technology and are therefore not fitted with light bulbs. In case of failure, the entire lamp must be replaced.
  • Page 172 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 199 Direction indicator Light bulb type P21 12V 21W (single filament). To replace the light bulb in the direction indicator, perform the procedure described below. Refer to the figure Fig. 200. • Unscrew the screws (A) under the lamp housing on the fender and remove the protective cover.
  • Page 173 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • Insert the holder with the bulb back into the direction indicator and rotate it to the right to fasten it. • Reinstall the protective cover and tighten the screws (A). Fig. 200 IMPORTANT: Only use lamps with technical characteristics matching the original lamps!
  • Page 174 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.3.2.3 LAMP ASSEMBLY ON THE REAR FENDERS The lamp assembly on the rear fenders includes • two rear stop lamps (1); • two direction indicators (2). Fig. 201 Direction indicator Light bulb type P21 12V 21W (single filament). The rear direction indicator functions in the same ways as the front direction indicator and the light bulb replacement procedure is the same, refer to the description and the illustration in the section “Lamp assembly on front fenders”.
  • Page 175 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Rear stop lamp The light bulb type for the stop lamp is P21 12V 21W (double filament). To replace the light bulb in the lamp, perform the procedure described below. • Unscrew the screws (A) under the lamp housing on the fender and remove the protective cover.
  • Page 176 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.3.2.4 LICENSE PLATE ILLUMINATION LAMP The light bulb type for the license plate illumination lamp is 12V 5W (single filament). To replace the light bulb in the lamp, perform the procedure described below. • Unscrew the two screws and remove the lamp housing. •...
  • Page 177 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.3.2.6 INTERIOR LAMP (TRACTOR VERSION WITH A CAB) The light bulb type for the interior lamp is 12V 5W (single filament). To replace the light bulb in the lamp, perform the procedure described below. • Remove the cover on the lamp with a flat screwdriver. •...

  • Page 178: Cleaning The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 CLEANING THE TRACTOR Clean the tractor with a water jet, taking care not to point it towards electrical parts, particularly the engine assembly, where the air filter, alternator and starter are installed. If you decide to clean the engine, protect these parts with suitable covers.

  • Page 179: Changing The Engine Oil

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.5.2 CHANGING THE ENGINE OIL The engine oil should be changed when the engine is still warm, following the procedure below; this way it is easier to drain the oil through the opening. • Open the engine cover. •...

  • Page 180: Changing The Oil Filter

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 WARNING: Used engine oil must not be disposed of in the environment. In accordance with applicable regulations, it must be collected in suitable collection containers. 8.5.3 CHANGING THE OIL FILTER To change the oil filter, follow the procedure described below. •...

  • Page 181: Changing The Air Filter

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.5.4 CHANGING THE AIR FILTER When the air filter is blocked, a warning lamp illuminates on the dashboard, refer to the chapter “Dashboard” and the filter mist be cleaned or replaced. To replace the air filter, follow the procedure described below. •...

  • Page 182: Cleaning The Air Filter

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.5.5 CLEANING THE AIR FILTER As a precaution, if the tractor is used in a dusty environment, it is recommended to check the filter for blockage sooner and clean it if necessary. Cleaning the filter insert with compressed •...

  • Page 183: Changing The Fuel Filter

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.5.6 CHANGING THE FUEL FILTER Due to deposits and water accumulating in the filter while the tractor is running, the fuel filter must be always be replaced within the prescribed intervals, refer to “Maintenance table”. To change the fuel filter, follow the procedure described below.
  • Page 184 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.5.6.1 CHANGING THE AUXILIARY FUEL FILTER The auxiliary filter is installed under the cover of the tank. It is designed to prevent larger particles from entering the fuel circuit. If you see there are many particles present through the transparent housing, replace the filter.

  • Page 185: Changing The Belt

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.5.7 CHANGING THE BELT This procedure must be performed by a qualified person. Before working on the area with the belt assembly, stop the tractor in safe conditions, shut off the engine and remove the key from the ignition lock.

  • Page 186: Cooling System Maintenance

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 COOLING SYSTEM MAINTENANCE Before performing any maintenance work on the cooling system, comply with the instructions described below. • Stop the tractor in safe conditions and in a suitable area. • Because the coolant is under pressure when the engine is running, you must wait for the engine to properly cool down to avoid burns.

  • Page 187: Draining The Coolant

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.6.2 DRAINING THE COOLANT This procedure must be performed by a qualified person. Before working on the area with the engine assembly, stop the tractor in safe conditions, shut off the engine and remove the key from the ignition lock.

  • Page 188: Cleaning The Radiator

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.6.3 CLEANING THE RADIATOR Regularly check that the radiator is clean to ensure adequate ventilation and correct cooling. If the slots are blocked, the radiator fins will not receive enough air to allow for sufficient ventilation, which may result in overheating and subsequent damage to engine parts under load.

  • Page 189: Transmission Maintenance

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 TRANSMISSION MAINTENANCE Before performing any maintenance work on the transmission assembly, comply with the instructions described below. • Stop the tractor in safe conditions, on a horizontal surface, lower the hydraulic lift mechanisms (front and rear) and lower the rest of the equipment, powered by the gearbox oil.
  • Page 190 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 • Run the engine for a few moments and perform a few hydraulic operations. While doing so, check the hydraulic oil filter (if replaced) and screws on the gearbox for leakage. • Shut off the engine, lower the lift mechanism (if they were operated) and check the oil level again.

  • Page 191: Changing The Hydraulic Oil Filter

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.7.3 CHANGING THE HYDRAULIC OIL FILTER The gearbox oil filter must be replaced if the indicator lamp for hydraulic oil filter blockage illuminates when the oil is heated and the engine is running. To change the oil filter, follow the procedure described below. •...

  • Page 192: Checking The Front Differential Oil Level

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.7.4 CHECKING THE FRONT DIFFERENTIAL OIL LEVEL Before checking the front differential oil level, the tractor must always be parked with the engine turned off to allow the parts to cool down. Check the oil level in the indicator on the front left sleeve. If you see oil inside the indicator, there is enough oil.

  • Page 193: Checking The Oil In Lateral Reducers

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 199 WARNING: Used oil must not be disposed of in the environment. In accordance with applicable regulations, it must be collected in suitable collection containers. 8.7.6 CHECKING THE OIL IN LATERAL REDUCERS To check the oil in lateral reducers, follow the procedure described below. •...

  • Page 194: Changing The Oil In Lateral Reducers

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.7.7 CHANGING THE OIL IN LATERAL REDUCERS To change the oil in lateral reducers, follow the procedure described below. • Park the tractor on a horizontal surface, shut off the engine and activate the parking brake.

  • Page 195: Air Conditioner Maintenance (Cab Version)

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 AIR CONDITIONER MAINTENANCE (CAB VERSION) The following section contains some recommendations for air conditioning maintenance, which must be followed by the operator. • The air conditioner compressor on the tractor must be installed in a stable position. •...

  • Page 196: Air Conditioner Filling

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.8.1 AIR CONDITIONER FILLING WARNING: The air conditioner can only be filled by a specialist or a service centre! • The filling valves for the air conditioner are located at the left side of the engine, behind the rear side of the compressor.

  • Page 197: Changing The Cab Filter

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Fig. 233 8.8.3 CHANGING THE CAB FILTER • The cab filter is located at the front of the cab roof. To replace the cab filter, follow the procedure described below. • • Loosen the screws (A) and remove the cover; •...

  • Page 198: Braking System Maintenance

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 BRAKING SYSTEM MAINTENANCE Before performing any maintenance work on the braking system, comply with the instructions described below. • Stop the tractor in safe conditions and in a suitable area. • If the tractor was operating, wait until the engine cools down enough. •...

  • Page 199: Brake And Clutch Bleeding

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.9.2 BRAKE AND CLUTCH BLEEDING • The clutch bleeding system (1) is located at the left side of the platform, behind the plug on the sheet metal, which is parallel to control devices. • The parking brake bleeding and adjustment system (2) is located on the rear transmission, behind the rear hydraulic lift mechanism.

  • Page 200: Greasing Points On The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.10 GREASING POINTS ON THE TRACTOR To ensure proper operation, regularly grease the parts with grease fittings according to the prescribed intervals. The following page contains some advice which must be followed. • Every 50 hours of operation, all moving parts must be properly greased. •...

  • Page 201: Diagram Of Greasing Points

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.10.1 DIAGRAM OF GREASING POINTS No. Greasing point Description / Greasing point Grease fitting function Transmission Lubricates the joint on Grease fitting at the left Type A the front axle. side next to the transmission joint. Grease fitting at the left Type A side of the central...
  • Page 202 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Rear left side view of the tractor Fig. 237...
  • Page 203 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Front right side view of the tractor Fig. 238 Front left side view of the tractor Fig. 239...

  • Page 204: Maintenance Table

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.11 MAINTENANCE TABLE Material / spare Frequency Operation Type of work part Refer to “Checking the engine oil level”. Each Engine oil Check the level working Check braking Test – apply brake while driving. Brakes performance Perform a visual check.
  • Page 205 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Frequency Material / spare Operation Type of work part Refer to the chapter “Changing the engine 3rd service Engine oil Change the engine oil oil”. Call an authorized service centre. After Refer to the chapter “Changing the oil hours or 2 Engine oil filter Change the engine oil filter...
  • Page 206 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Frequency Material / spare Operation Type of work part – Refer to the chapter “Cooling system 6th service Coolant Replace the engine coolant. maintenance”. Call an authorized service After 1500 antifreeze hours centre. Engine oil, filter, Perform all the changes Refer to the corresponding chapters for fuel filters, air...

  • Page 207: Tractor Troubleshooting

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.12 TRACTOR TROUBLESHOOTING MALFUNCTIONS, CAUSES AND SOLUTIONS The following information is provided to help you identify and correct any malfunctions, which may occur during tractor operation. To ensure better troubleshooting results, it is recommended to have these procedures carried out by an authorized service workshop where a general tractor inspection is also possible.
  • Page 208 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Malfunction Cause Solution Differential lock. differential lock Disengage the differential lock. Refer to the chapter “Tractor console”. engaged. Brakes. Low brake fluid level. Stop the tractor in safe conditions and shut off the engine! Check the brake fluid level and add if necessary.

  • Page 209: Engine Malfunctions

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Malfunction Cause Solution Shut tractor’s engine Engine oil pressure. Low engine oil level. immediately! Check the engine oil level and add if necessary. Refer to the chapter “Maintenance”. If the malfunction persists, consult an authorized service technician. (*) Shut tractor’s pressure,...
  • Page 210 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Malfunction Cause Solution The engine does not Incorrect fuel type. Completely drain and clean the tank and start. fuel lines. Add the correct fuel type. Refer to the chapter “Tank filling”. fuel pump Replace the fuel pump. This operation can working properly.
  • Page 211 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Malfunction Cause Solution The starter is not The starter is damaged. Replace the starter. Consult an authorized working. service technician. (*) Discharged battery. Charge or replace the battery. Refer to the chapter “Changing the battery”. The battery terminals are Clean and grease the surfaces of both terminals.

  • Page 212: Transmission Malfunctions

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Malfunction Cause Solution The engine operating Thermostat malfunction, the Replace the thermostat. This operation can temperature is low. thermostat is damaged. only be performed by an authorized service centre. (*) indicator Consult an authorized service technician. dashboard is damaged.

  • Page 213: Brake System Malfunction

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Malfunction Cause Solution gear The gearbox synchronizers Repair the gearbox or adjust the joint or change any jumps out of or joints on levers of control worn out components. This operation can only be its position. devices are worn.

  • Page 214: Hydraulic Lift Mechanism Malfunctions

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Malfunction Cause Solution steering Presence of air in the steering Bleed the system. This operation can only be wheel does not system. performed by an authorized service centre. (*) allow The seals on steering cylinders are Replace the seals.

  • Page 215: Pto Drive Shaft Malfunction

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.12.7 PTO DRIVE SHAFT MALFUNCTION Malfunction Cause Solution The PTO drive shaft does not The solenoid valve fuse is faulty. Replace the fuse. Refer to the chapter “Fuses”. rotate. The solenoid valve for PTO Check the valve and replace it if drive shaft engagement is faulty.

  • Page 216: Differential Lock Malfunction

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.12.8 DIFFERENTIAL LOCK MALFUNCTION Malfunction Cause Solution The differential lock does not The fuse is faulty. Replace the fuse. Refer to the chapter “Fuses”. engage. solenoid valve Check the valve and replace it if differential lock engagement and necessary.

  • Page 217: Malfunctions In The Cab

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 8.12.10 MALFUNCTIONS IN THE CAB Malfunction Cause Solution The heating in the The coolant level in the Check the coolant level and add if necessary. Refer to the chapter “Maintenance”. cab is not working. system is too low. Replace the fuse.

  • Page 218: Technical Data Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 TECHNICAL DATA OF THE TRACTOR For easier understanding and quick reference purposes, the technical data are divided into several sections with tables. The values given in the tables may variate depending on the method of measurement and the configuration of the tractor.
  • Page 219 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Tractor dimensions. Dimensions (mm) Tyres Tyre width 3290 - 3525 - 29x12.50-15 1190 1380 2067 2107 3550 3895 31x15,50-15 3290 - 3525 - 1190 1380 2108 2148 (400/50-15) 3550 3895 3290 - 3525 - 7.5-16 1190 1380 2101...

  • Page 220: Dimensions Of The Rear Hydraulic Lift Mechanism

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.1.1 DIMENSIONS OF THE REAR HYDRAULIC LIFT MECHANISM The drawing shows the technical data for the standard lift mechanism. The rear hydraulic lift mechanism is a category 1 mechanism. Fig. 241 The table provides data on the height, depending on the wheels (measured from the ground), and the default length of tensioners adjusted to 430 mm, as well as the distance between the lower lift arms of 840.
  • Page 221 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 The bolt on the lower lift arms can adjusted different positions ensure better adaptation to the connection on the implement. Fig. 242 Adjustment of the bolt in the first position of the lower lift arm Dimensions (mm) Tyres 29x12.50-15...
  • Page 222 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Adjustment of the bolt in the second position of the lower lift arm Dimensions (mm) Tyres 29x12.50-15 31x15,50-15 (400/50-15) 7.5-16 260/70 R16 280/70 R16 250/80 R18 280/70 R18 300/65 R18 260/70 R20 Adjustment of the bolt in the second position of the lower lift arm Dimensions (mm) Tyres 29x12.50-15...

  • Page 223: Equipment)

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.1.2 DIMENSIONS OF THE FRONT HYDRAULIC LIFT MECHANISM (OPTIONAL EQUIPMENT) The drawing shows the technical data for the front hydraulic lift mechanism. The mechanism belongs to category 1. Fig. 243 The table provides data on the height, depending on the wheels (measured from the ground), and the distance between the lower lift arms of 721.

  • Page 224: Dimensions Of The Rear Tow Hook

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.1.3 DIMENSIONS OF THE REAR TOW HOOK The drawing shows the technical data for the rear tow hook. Fig. 244 The table provides data on the height of the hook, depending on the wheels (measured from the ground).

  • Page 225: Tractor Wheelbases

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.1.4 TRACTOR WHEELBASES This chapter describes the wheelbases of the tractor with different rim options, which can be fixed or adjustable. 9.1.4.1 ADJUSTABLE RIMS The drawing shows the tractor wheelbases with all available versions of adjustable rims. Fig.
  • Page 226 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 WARNING: Use appropriate tightening torques when installing wheels or tightening the nuts and screws! 9.1.4.2 FIXED RIMS The drawing shows the tractor wheelbases with all available versions of fixed rims. 1 – standard version tractor 2 –...

  • Page 227: Tyre Pressure

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 TYRE PRESSURE This chapter contains the technical specifications of tyres and rims. Fig. 247 Dimensions (mm) Pressure (bar) Tyres Width Front axle (1) Rear axle (2) 29x12.50-15 10 LB x 15 31x15,50-15 13 LN x 15 (400/50-15) 7.5-16 5.5 x 16...

  • Page 228: Maximum Permissible Mass Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.3.2 MAXIMUM PERMISSIBLE MASS OF THE TRACTOR This table describes the weights for the maximum permissible axle loads according to the tyre type. Fig. 248 Dimensions (mm) Mass (kg) Maximum Tractor Wheel Tyres Tyre load Axle permissible Maximum...

  • Page 229: Maximum Permissible Load On The Connection Point

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.3.3 MAXIMUM PERMISSIBLE LOAD ON THE CONNECTION POINT This table describes the masses for the maximum vertical load on the connection point (tow hook) according to the tyre type. Dimensions (mm) Mass (kg) Tyres Maximum load on the Wheel diameter Tyre load capacity connection point...

  • Page 230: Weights

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 WEIGHTS This table shows the type and the amount of weights, which can be installed to improve the stability of the tractor and to increase the traction power when using heavy implements. Total amount Maximum Amount Weight Weight...

  • Page 231: Noise Level

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 NOISE LEVEL This table provides information on noise level, measured on the tractor under different operating conditions. The values were measured in accordance with testing method, in compliance with the guidelines of the Commission Delegated Regulation (EU) no. 1322/2014 – Annex XIII. Measured value (dB / A) No.

  • Page 232: Technical Characteristics

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 TECHNICAL CHARACTERISTICS Function Unit Description Engine Kohler KDI 1903 TCR Type 4-stroke, diesel Emission standard Stage 5 cm³ Capacity 1861 Engine power kW / HP 42 / 56 Maximum torque Nm / rpm 225 / 1500 Fuel injection Direct Max.
  • Page 233 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 Function Unit Description Rear hydraulic lift mechanism Standard equipment Type Three-point linkage Category Category I Control Hydraulic through control devices Lifting capacity 1240 At the rear – 4 as standard + 6 optional Hydraulic connections Front hydraulic lift mechanism Optional equipment Type...

  • Page 234: Prescribed Oils, Liquids And Lubricants

    PRESCRIBED OILS, LIQUIDS AND LUBRICANTS This chapter provides the details of all prescribed oils, liquids and lubricants which ensure a long performance life of the tractor in accordance with the technical specifications. To order these products, contact your Agromehanika d.d dealer. 9.8.1 OILS Oils Quantity (l) •...

  • Page 235: Pto Drive Shaft

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 PTO DRIVE SHAFT During work, rotating axes of the universal joint on the tractor and the implement must be aligned as best as possible. It is recommended to avoid angles exceeding 15° to ensure a long service life of the universal joint.
  • Page 236 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.9.2.1 PTO DRIVE SHAFT DRIVEN BY THE ENGINE – SWITCHING THE LEVER (540) Engine revolutions 1000 1200 1400 1600 1800 2000 2200 2400 2600 Gear ratio PTO drive shaft revolutions 225.7 270.9 361.2 406.3 451.5 496.6 541.8 586.9...
  • Page 237 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.9.2.4 PTO DRIVE SHAFT DRIVEN BY THE GEARBOX – SWITCHING THE LEVER (750) Gear Gear Engine revolutions ratio 1000 1200 1400 1600 1800 2000 2200 2400 2600 PTO drive shaft revolutions Forward driving N-1-Z 3.96 252.7 303.3 353.8 404.4...

  • Page 238: Tractor Speed

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.10 TRACTOR SPEED Tractor speed with the engine operating at the maximum torque and 2600 revolutions per minute. FORWARD speed REVERSE speed Diameter (km/h) (km/h) Tyre Gear (mm) Ž Ž 11.9 13.7 29x12.50-15 17.5 19.2 23.5 25.8 12.6...

  • Page 239: Electrical Connection Of The Tractor

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.11 ELECTRICAL CONNECTION OF THE TRACTOR 9.11.1 WIRING DIAGRAM OF FENDERS Fig. 251...

  • Page 240: Wiring Diagram Of The Engine

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.11.2 WIRING DIAGRAM OF THE ENGINE Fig. 252...

  • Page 241: Wiring Diagram Of The Dashboard

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.11.3 WIRING DIAGRAM OF THE DASHBOARD Fig. 253...

  • Page 242: Wiring Diagram Of The Cab

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 9.11.4 WIRING DIAGRAM OF THE CAB Fig. 254...

  • Page 243: Conversions Of Tractor Loads

    OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 10 CONVERSIONS OF TRACTOR LOADS The total weight of the tractor with implements attached to the front or rear hydraulic system must not exceed the maximum permissible total weight, the maximum axle load and the tyre load capacity. At least 20 % of the total tractor weight must always be distributed on the front axle.
  • Page 244 OPERATING INSTRUCTIONS AGT 1060 Rev.09/2020 NOTES...
  • Page 245 When ordering spare parts, always provide the following information: the type and serial number of the tractor. This information is printed on the identification plate on the tractor. AGROMEHANIKA d. d. GUARANTEES THAT THE TRACTOR WILL OPERATE PROPERLY IF ORIGINAL SPARE PARTS ARE USED Any reproduction of texts and images from this manual is prohibited! We are constantly working to improve our products.

Table of Contents
