SENSTAR Flash Maintenance Manual

Personal alarm locating system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Personal Alarm Locating System
Regional
Senstar Corporation
offices
Address:
119 John Cavanaugh
Dr.
Carp, Ontario
Canada K0A 1L0
Phone:
+1 (613) 839-5572
Toll Free:
Fax:
+1 (613) 839-5830
Website:
www.senstar.com
E-mail:
info@senstar.com
All material, including technical data, designs, knowledge, and ideas contained in this document
are considered proprietary, and the exclusive property of Senstar Corporation, and shall not be
used, disclosed, reproduced, or transmitted in any form or by any means, electrical or
mechanical, including photocopying, recording, or by any information storage or retrieval
system, without permission in writing from Senstar Corporation.
Flash
PPD Maintenance Manual
T1DA0502-002, Rev. A
Software Version 1.7 and above
U.S.
43180 Osgood Rd.
Fremont, CA
USA 94539
+1 (510) 249-1450
1-800-676-3300
+1 (510) 249-1540
™
Flare
/
May 26, 2008
U.K.
Europe
Orchard House,
Reidheimer Str. 8
Evesham Rd.
Broadway, Worc.
88677 Markdorf
U.K. WR12 7HU
Germany
+44 (1386) 834433
+49 (7544) 95910
+44 (1386) 834477
+49 (7544) 959129
®
Latin America
Nueva Italia No. 5
Col. Lomas De La
Selva
Cuernavaca,
Morelos
62270, Mexico
+52 (777) 313-0288
+52 (777) 317-0364

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flash and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SENSTAR Flash

Summary of Contents for SENSTAR Flash

  • Page 1 All material, including technical data, designs, knowledge, and ideas contained in this document are considered proprietary, and the exclusive property of Senstar Corporation, and shall not be used, disclosed, reproduced, or transmitted in any form or by any means, electrical or mechanical, including photocopying, recording, or by any information storage or retrieval system, without permission in writing from Senstar Corporation.
  • Page 2 Technical Manual (T1DA0502) with PPD Programmer Operation Manual (T1DA0602) Flash is a trademark of Magal-Senstar, Inc. and is used under license by Senstar Corporation. Flare is a registered trademark of Magal-Senstar, Inc. and is used under license by Senstar Corporation.

  • Page 3: Table Of Contents

    PPD Maintenance Manual Table of Contents INTRODUCTION....................... 5 ..........................5 COPE ....................5 ELATED OCUMENTATION PPD ID SETTING OVERVIEW..................5 PPD ID G ......................6 UIDELINES 2.1.1 PPD Offsets......................... 6 2.1.2 Range Type 0 (early Flare systems - circa 2002) ............6 2.1.3 Range Type 1.......................
  • Page 4 PPD Maintenance Manual MDM ......................18 ALIBRATE PPD MAINTENANCE ..................... 20 ....................... 21 ARE AND LEANING ................21 ACCESSORIES PARTS AND OPTIONS ..................... 21 ATTERY ONSIDERATIONS 7.3.1 Battery Life Specification..................21 7.3.2 Battery Life Considerations ..................21 7.3.3 Battery Replacement ....................22 PPD TRANSMITTER SPECIFICATIONS ..............

  • Page 5: Introduction

    Senstar's Flare (Personal Alarm Locating System - PALS) and Flash (Personal Portable Alarm System - PPAS). The PPD is also known as a Personal Portable Alarm (PPA). The PPD and its setup are identical for both of these systems. In this manual the duress system (the RF receivers, communications network, display and control PC and software) may also be referred to as personal alarm system or simply the system.

  • Page 6: Ppd Id Guidelines

    PPD transmit ID for LB = 1001 + 467 + 500 = 1968 The system (Flash or Flare) in which the PPD is used must be configured with the same offset values in its ini file as those used to program all of the PPDs. When configured correctly, the system software subtracts the same offsets from the received PPD transmit ID and displays the original user set PPD ID.

  • Page 7: Range Type 1

    IDs 1501-1600). 2.1.3 Range Type 1 In the Range type 1 Flare and Flash systems, the range programmed into the sensors is translated by offset, (for the example in section 2.1.1, the range downloaded to the sensors would be 1468- 2068).

  • Page 8: Ppd Programming Software

    PPD Maintenance Manual PPD PROGRAMMING SOFTWARE The PC software Transmitter Programmer (p/n T1SW0800) and a programmer adapter (p/n T1FG0600) are required to configure PPD IDs and other parameters. PC System Requirements The PPD Programming Software (Transmitter Programmer.exe) requires a PC running a Windows operating system with a serial port available.

  • Page 9: Man-Down Module Parameters

    PPD Maintenance Manual The values depend on requirements for non-overlapping PPD ID ranges (in the case of adjacent sites), the site Range Type (0 or 1), and the PPD firmware version. COMM_PORT - the port connected to the programmer adapter (1=COM1) 3.3.1 Man-Down Module Parameters The ini file contains a number of parameters under the heading [ManDown].

  • Page 10: Connect Adapter Box (Dongle) To Pc

    PPD Maintenance Manual Connect Adapter Box (dongle) to PC Connect the dongle to the PC using a 9 Pin EIA-232 straight-through cable maximum length of 3 m (10 ft.). Connect the adapter to the appropriate COM port on the PC on which the Transmitter Programmer software has been installed.

  • Page 11: Programming

    PPD Maintenance Manual adapter connector pins into the PPD connector. Gentle pressure is all that is required when the pins are properly aligned. A wiggle motion can aid in applying incremental gentle pressure. The adapter will only fit in properly in one orientation due to the notch guides. Forcing a misaligned connector may cause damage to both the adapter and the PPD.
  • Page 12 PPD Maintenance Manual Figure 4.5 Transmitter Programmer Main Screen The allowable fields are PPD ID, ARP and Frequency, edit any of these to the desired setting and select the Program PPD button. If there are no errors a pop-up box will inform you of programming success.

  • Page 13: Reset Low Battery In Legacy Ppds

    PPD Maintenance Manual Reset Low Battery in Legacy PPDs With PPD unit serial numbers prior to 5599, it may be necessary to manually reset the low battery detection system when a new battery is installed in the unit. After replacing the battery, select the Reset Low Battery button to reset the low battery condition.

  • Page 14: Man-Down Module

    PPD Maintenance Manual MAN-DOWN MODULE This section describes programming of the user-configurable parameters of the optional Man- Down Module (MDM) for the PPD. Programmable Options The MDM includes several user configurable parameters. Included among these are the ability to change the angle at which the device goes into alarm mode, enable or disable a tilt warning and transmission tones, and changing the time between tilt and activation and retransmission.

  • Page 15: Tilt Angle For Alarm

    PPD Maintenance Manual 6.1.3 Tilt Angle for Alarm The value of this parameter sets the angle at which the unit will enter the alarm mode. For example, when this value is set to 45 degrees, the unit will enter alarm mode when the unit is tilted by 45 degrees or more.

  • Page 16: Beeper Period

    PPD Maintenance Manual 6.1.8 Beeper Period The value of this parameter sets the frequency of the warning tone. The default value is 65 (2.5 kHz). The user may experiment to determine the desired setting. Programming the Man-Down Module The section describes the steps required to program the user configurable options of the Man- Down Module.

  • Page 17: Program Module

    PPD Maintenance Manual Figure 6.2.2 Man-Down Module Programming Dialog 6.2.3 Program Module When all parameters have been set, select the Program Module button. If there are no errors, a pop-up will inform you of programming success. If desired you can select Get Info to read the parameters from the MDM.

  • Page 18: Calibrate Mdm

    PPD Maintenance Manual Figure 6.2.4 Get Info Screen Calibrate MDM The calibrate function is factory performed and most likely not need to be performed again. However if a unit goes out of tolerance and exhibits high sensitivity to tilt, a field calibration may be required.
  • Page 19 PPD Maintenance Manual After the Calibrate button is selected the program will display the following prompt box. Place the PPD-MDM unit upright and perpendicular to the earth's surface as shown in figure to the right and then select the OK button. gravity direction Earth’s...

  • Page 20: Ppd Maintenance

    PPD Maintenance Manual automatically displayed (Figure 6.3). If calibration values are within valid limits ok will be listed in the range check column. Figure 6.3 Calibration Results Box After verifying the range check column shows Ok for all results select the OK button to close the calibration results window.

  • Page 21: Care And Cleaning

    PPD Maintenance Manual Care and Cleaning The PPD outer protective case (carrying pouch) is made from leather. It should be cleaned and cared for as any leather product (e.g., periodically clean and moisturize with saddle soap or other leather cleaner). Remove the PPD from the leather case before cleaning the pouch to avoid contacting the PPD with the cleaning solution.

  • Page 22: Battery Replacement

    If this occurs, take the unit out of service immediately. [NOTE: Senstar PPD transmitters have been independently tested and shown to achieve over 3,000 transmissions at -40 degrees Celsius before the low battery threshold was observed].

  • Page 23: Ppd Transmitter Specifications

    PPD Maintenance Manual For legacy PPD units (serial numbers below 5600) the ARP and low battery reset may need to be performed. This may also be required for units with no pull-pin that have a non-zero pull-pin ARP setting. The ARP and battery low reset is performed as described in section 5. It can also be similarly performed without the programmer software or adapter.

This manual is also suitable for:

Flare

Table of Contents
