SENSTAR Intelli-FLEX II Product Manual

Perimeter protection system-relay output processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
™
Intelli-FLEX
II
Perimeter Protection System-Relay Output Processor
Product
Guide
C6DA0602-001, Rev K
First edition
October 9, 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Intelli-FLEX II and is the answer not in the manual?

Questions and answers

Related Manuals for SENSTAR Intelli-FLEX II

Summary of Contents for SENSTAR Intelli-FLEX II

  • Page 1 ™ Intelli-FLEX Perimeter Protection System-Relay Output Processor Product Guide C6DA0602-001, Rev K First edition October 9, 2008...
  • Page 2 The information provided in this guide has been prepared by Senstar Corporation to the best of its ability. Senstar Corporation is not responsible for any damage or accidents that may occur due to errors or omissions in this manual. Senstar Corporation is not liable for any damages, or incidental consequences, arising from the use of, or the inability to use, the software and equipment described in this guide.

  • Page 3: Table Of Contents

    Installing the Intelli-FLEX II processor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 4 Intelli-FLEX II Processor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...

  • Page 5: Overview

    Overview What is Intelli-FLEX II Intelli-FLEX II is an outdoor perimeter intrusion detection sensor system. It employs a passive coaxial cable detector, which is installed on the perimeter fence, to detect intrusion attempts. The cables can sense any vibration along the fence caused by climbing, cutting, or otherwise disturbing the fence fabric.

  • Page 6: Purpose Of This Guide

    Purpose of this guide Purpose of this guide This is the product guide for the Intelli-FLEX II DC/DC powered relay output processor. This guide includes information to assist you in selecting, installing, calibrating and maintaining the components of your Intelli-FLEX II system.

  • Page 7: Principles Of Operation

    The Intelli-FLEX II system monitors the processor’s power level. If there is a significant fluctuation in the power, a supervision alarm will be generated. In most applications, the processor can be programmed by the user for optimum performance.

  • Page 8: Intruder Detection

    Climb scenario variation 2 (crawl-under) - An intruder attempts to gain access to a secure area by lifting the fence fabric, and crawling under it. The Intelli-FLEX II system recognizes these scenarios and can discriminate between them and environmental activity.

  • Page 9: System Supervision

    System supervision The Intelli-FLEX II system monitors itself to ensure that its protection capability is not compromised. If that capability has been compromised, the system will generate a supervision alarm. Supervision alarms can occur for several reasons: •...
  • Page 10 11 VDC, the condition will clear and the system will resume operation. Tamper The Intelli-FLEX II system uses a solid-state sensor to detect if the enclosure door is open. A magnet is mounted on a standoff on the enclosure door. The magnet must be close to the tamper sensor located on the processor for the tamper alarm to be deactivated.

  • Page 11: System Components

    Load / Self Test (optional) configuration module Figure 3-1 Intelli-FLEX II system diagram Each Intelli-FLEX II system is a self contained detection system. The basic Intelli-FLEX II system requires the following The following optional components can be added to components: the basic system: •...

  • Page 12: Standard Components

    The Intelli-FLEX II dual zone processor contains the circuitry necessary to monitor one or two independent sensor zones. Generally, these two zones are located beside each other. When used to monitor two zones, the Intelli-FLEX II dual zone processor is capable of monitoring 610 meters (2,000 ft.) of sensor cable, 305 meters (1,000 feet) per zone.
  • Page 13 Standard components A plug-in connector allows you to connect the configuration module to the processor. Intelli-FLEX II processors containing relay outputs can be used with existing E-Flex sensor cable installations. They can replace existing EIIA, EIIAHR, EIIB, EIIBHR and E3i processors.
  • Page 14 The cable junction device is a moisture proof splice kit. It is used to splice non-sensitive feed cable to sensor cable, or to connect two pieces of sensor cable together. 3 - 4 • • • Intelli-FLEX II product guide...
  • Page 15 A detachable configuration module enables the operator to monitor the system operation and response, and to view or change the system configuration. Power supply options The Intelli-FLEX II DC/DC dual zone processor can be powered one of two ways: • DC power/float charger and rechargeable battery •...
  • Page 16 DC power supply may be located indoors, and the 24 VDC output, (48 VDC in large installations), is run along the perimeter to each of the Intelli-FLEX II processors. The central DC power supply may be plugged into a readily accessible UPS system to provide additional isolation and a non- interruptible source of power.

  • Page 17: Optional Components

    The sliding gate disconnect assembly is used to provide security across a sliding gate within an Intelli-FLEX II zone that is not frequently used. With this device the gate may be left securely unattended, however, the gate can be opened and closed by manually separating the connection to open the cable line.
  • Page 18 Figure 3-7 Local and remote gate bypass modules Two options of the gate bypass module are available: • Model 2490-1 - manual (or local) operation (keylock switch) • Model 2490-2 - remote operation (remote-controlled relay). 3 - 8 • • • Intelli-FLEX II product guide...

  • Page 19: Site Planning

    Site planning guidelines Follow these guidelines to create an operating environment that allows the Intelli-FLEX II system to perform well. Perform regular inspections to ensure that the fence remains in good condition. Timely repairs to fence damage, the control of vegetation, and regular visual inspections of all detection zones, will provide years of effective operation.

  • Page 20: Site Survey

    A survey should be conducted before installing any system hardware to ensure that the site conditions are suitable for optimum function of an Intelli-FLEX II system. The primary concern of the site survey is the condition of the fences and gates where the sensor cable will be attached.

  • Page 21: Upgrade Existing Structures

    This section details the procedures that are required to upgrade several types of fences so that they are sufficient barriers against climb over and crawl under intrusions. If you do not see your specific fence type, please contact your Senstar representative.
  • Page 22 Upgrade existing structures Chain-link fences Chain-link fences are one of the most popular types of perimeter fences, hence, Intelli-FLEX II is often installed on an existing chain-link fence. The chain-link fence fabric should meet the following minimum specifications: • 9 GA (2.9 mm dia.) galvanized steel, 2.5 to 7.5 cm (1 to 3 in.) mesh chain-link (or weld-mesh) •...
  • Page 23 Palisade fences The effectiveness of Intelli-FLEX II installed on this type of fence will depend entirely on the characteristics and construction of the specific fence. There are several types of palisade fences.
  • Page 24 Other structures The Intelli-FLEX II system has been used on other types of fence structures. It has been deployed on wooden fences, on indoor walls to detect break through, in conduit along the top of concrete or brick walls to detect climb-over, along wire conduits to protect sensitive data cables, even in the handrails of a yacht to detect intrusion onto the ship while it is moored.
  • Page 25 Ambient weather conditions such as a tendency for electrical storms, high precipitation and strong winds may affect the configuration parameters for the Intelli-FLEX II system. Determine the normal weather conditions for the site. If it is determined that your site is in a severe weather environment, the cut count and climb time may have to be increased by 1 or 2 units.

  • Page 26: Perimeter Layout Guidelines

    Intelli-FLEX II system. Use a site plan to mark the locations for the Intelli-FLEX II components as follows: • sensor cables - indicate layout of cable in each zone...
  • Page 27 4.5 m (15 ft.) in height - three or more passes of sensor cable. This depends on fence fabric and structure, and on the level of security required by the system. These cable passes should be equally spaced. Intelli-FLEX II product guide • • • 4 - 9...
  • Page 28 In a barbed wire outrigger array, if the wires in the array are less than 10 cm (4 in.) apart, the sensor cable will be laid out on the array in a saw-tooth pattern. 4 - 10 • • • Intelli-FLEX II product guide...
  • Page 29 (heavier gauge) sensor cable fence 30 to 45 cm height (12 to 18 in.) fence height chain-link or weld mesh fence Figure 4-8 Corner posts, heavier gauge posts, and service loops Intelli-FLEX II product guide • • • 4 - 11...
  • Page 30 0.025 in.) in diameter to fit the coaxial F-connector on the processor. The maximum length of non-sensitive feed and bypass cables may be extended, provided the length of the Intelli-FLEX sensor cable is reduced accordingly. 4 - 12 • • • Intelli-FLEX II product guide...
  • Page 31 Perimeter layout guidelines Gate bypass If a gate is within an Intelli-FLEX II sensor zone, the length of non-sensitive feed cable within the zone must include a sufficient amount to bypass the gate, and to the connect the processor to the sensor cable. The length of the bypass cable is determined by the following equation: Length of bypass cable = (width of gate + 2 X 15 cm [6 in.]) +...
  • Page 32 The maximum number of processors that can be used usually depends on the limitations of the system control panel. The Intelli-FLEX II processor is designed to be mounted outdoors inside a NEMA 4 rated enclosure. The enclosure is then mounted on a wall, or other stable flat surface, that is located close to, but separate from, the fence where the sensor cable is mounted.
  • Page 33 These relays are to be connected to monitoring equipment. Grounding considerations The Intelli-FLEX II sensor must have a single ground reference. This earth ground must be located at each processor. A stable earth ground is required at the processor mounting location.
  • Page 34 Small installations can be operated from a 24 VDC power supply, whereas larger installation with many processors, may require a 48 VDC power supply. Intelli-FLEX II processors consume 3 Watts maximum load (this includes the Configuration module). 4 - 16 • • • Intelli-FLEX II product guide...

  • Page 35: Equipment Requirements

    Equipment requirements After the site layout is complete, compile a list of equipment requirements for your site. The Intelli-FLEX II sensor system is supplied in kits for single and dual zone applications. Components can also be purchased individually. Refer to Appendix b - Spare parts list for a list of components.

  • Page 37: Installation Instructions

    Install junction device(s) between the sensor cable and non-sensitive feed cable. • Install the enclosure complete with the Intelli-FLEX II dual zone processor. • Complete the wiring connections for all components. For site planning and equipment requirement guidelines refer to chapter 4, Site planning.

  • Page 38: Basic Sensor Cable Installation

    Intelli-FLEX sensor cable. Sensor cable routing guidelines • The sensor cable can be mounted on either side of a fence. However, Senstar strongly recommends installing the cable on the secure side of the fence. • Make sure that the sensor cable is not trapped between the fence fabric and the support posts.
  • Page 39 Overlap Wherever two Intelli-FLEX II zones meet, there should always be an overlap to prevent an area with reduced detection sensitivity. Overlap the sensor cables from the two zones by approximately 1.5 m (5 ft.).
  • Page 40 Secure the cable to the fence so that it follows the contour of the ground while it maintains a constant distance from the ground (i.e., if the fence steps up a hill, the cable should also step up the hill). 5 - 4 • • • Intelli-FLEX II product guide...
  • Page 41 Install a corner loop at all fence corners and at heavier gauge fence posts. Corner loops may be required at all fence posts in a vinyl fence installation due to the insulating properties of the vinyl coating. Intelli-FLEX II product guide • • • 5 - 5...
  • Page 42 Figure 5-8 Double cable pass Pointers Keep the following in mind when handling the sensor cables: • Handle the cable carefully. Sensor cable MUST not be jerked, stretched, knotted, kinked, nicked, or scraped. 5 - 6 • • • Intelli-FLEX II product guide...
  • Page 43 Installation instructions For fences other than chain-link or weld-mesh, refer to cable installation on different fence types. The following procedure requires two people. Intelli-FLEX II product guide • • • 5 - 7...
  • Page 44 (point 9). 6. Continue applying the tension to the sensor cable, while you attach the cable to the fence fabric adjacent to the second support post (point 10). 5 - 8 • • • Intelli-FLEX II product guide...

  • Page 45: Cable Installation On Different Fence Types

    In such cases the processor gain and the signal threshold may require further adjustments. Intelli-FLEX II product guide • • • 5 - 9...
  • Page 46 • Attach the sensor cable to the horizontal wires of the weld-mesh fence at the same distance above ground as for a chain-link fence of the comparable height. 5 - 10 • • • Intelli-FLEX II product guide...
  • Page 47 • Unlike chain-link or weld-mesh fences, palisade fences have a uniform construction along the entire fence line including the corners. Therefore, no special sensor cable deployment is required at corners. Intelli-FLEX II product guide • • • 5 - 11...
  • Page 48 On barbed wire fence Figure 5-13 Sensor cable installed on barbed wire fence Keep the following in mind when installing Intelli-FLEX II sensor cable on a barbed wire fence: • Take care not to damage the sensor cable on the barbs during installation and to ensure that there is no possibility of subsequent damage from the barbs.

  • Page 49: Installation Of Cable At Gates

    PVC conduit Figure 5-14 Swinging gate bypass If a swinging gate is to be part of an Intelli-FLEX II zone, a non-sensitive, bypass cable must be run from one side of the gate to the other in order for the sensor cable to be usable on both sides of the gate.
  • Page 50 See “Cable devices” on page 34 for installation details. 7. Seal the ends of the conduit. Swinging gate without cable protection no protection on gates cable bypass Figure 5-15 Swinging gate without protection 5 - 14 • • • Intelli-FLEX II product guide...
  • Page 51 Swinging gate with cable protection Gates that have occasional use, such as maintenance gates, are usually included in the Intelli-FLEX II zone. These gates can be protected by installing a loop of Intelli-FLEX sensor cable on the gate panel. Installation on a single panel swinging gate 1.
  • Page 52 13. Sliding gate with cable protection Sliding gates can be included as part of the Intelli-FLEX II zone by installing sensor cable on the gate panel, and connecting it to the fence sensor cable with RG-59 cables.
  • Page 53 C sensor cable on gate section D non-sensitive bypass cable from prior section to sensor cable beyond gate gate closed gate open RG-59 cables Figure 5-19 Single sliding gate on inside of perimeter Intelli-FLEX II product guide • • • 5 - 17...
  • Page 54 5. Run a bypass cable from one side of the first gate to the far side of the second gate. See “Swinging gate bypass cable” on page 13 for installation instructions. 6. Join the RG-59 cables to the sensor cables and bypass cable using splice kits. 5 - 18 • • • Intelli-FLEX II product guide...
  • Page 55 1 cable guide bar (customer supplied) • Cable ties (amount determined by gate size) • non-sensitive RG - 59 cable (length determined by gate size) • Sensor cable (length determined by gate size) Intelli-FLEX II product guide • • • 5 - 19...
  • Page 56 D non-sensitive bypass cable from prior L-bracket secured to section to sensor cable beyond gate gate at this point ONLY gate closed RG-59 cables gate open Figure 5-21 Single sliding gate on outside of perimeter 5 - 20 • • • Intelli-FLEX II product guide...
  • Page 57 To provide security across a sliding gate that is NOT frequently used, and that is included in an Intelli-FLEX II zone, use the sliding gate disconnect assembly. With this device the gate may be left securely unattended, but the gate can be opened and closed by manually separating the connection to open the cable line.
  • Page 58 The connectors should be capped when the gate is to remain open for extended periods. 7. Attach the rubber boot cover over the disconnect assembly. 5 - 22 • • • Intelli-FLEX II product guide...

  • Page 59: Gate Bypass Module

    Gate bypass module Gate bypass module The Intelli-FLEX II gate bypass module is used to bypass a protected gate without triggering an intrusion alarm. Local gate bypass module Remote gate bypass module MODEL 2490-1 SECURE ACCESS MODEL 2490-2 Figure 5-23 Gate bypass module This section outlines the cable layout and wiring requirements for the gate bypass variations using the gate bypass module.
  • Page 60 Connection details are given for each situation in the following sections. 5 - 24 • • • Intelli-FLEX II product guide...
  • Page 61 - bypass status - common bypassed section from annunciator - bypass status - N/C Figure 5-25 Single panel swinging gate Intelli-FLEX II product guide • • • 5 - 25...
  • Page 62 - bypass status - common panel from annunciator - bypass status - N/C Figure 5-26 Double panel swinging gate 5 - 26 • • • Intelli-FLEX II product guide...
  • Page 63 - bypass status - common bypassed section from annunciator - bypass status - N/C Figure 5-27 Sliding gate Intelli-FLEX II product guide • • • 5 - 27...
  • Page 64 - bypass status - common center conductor of cable to the gate or from annunciator - bypass status - N/C ending sensor section not used Figure 5-28 End of zone 5 - 28 • • • Intelli-FLEX II product guide...
  • Page 65 Connection details are given for each situation in the following sections. Intelli-FLEX II product guide • • • 5 - 29...
  • Page 66 -+12 VDC bypassed section center conductor from prior section of the from annunciator - ground zone Figure 5-30 Single panel swinging gate 5 - 30 • • • Intelli-FLEX II product guide...
  • Page 67 -+12 VDC section center conductor from prior section of the from annunciator - ground zone Figure 5-31 Double panel swinging gate Intelli-FLEX II product guide • • • 5 - 31...
  • Page 68 -+12 VDC bypassed section center conductor from prior section of the from annunciator - ground zone Figure 5-32 Sliding gate 5 - 32 • • • Intelli-FLEX II product guide...
  • Page 69 (closed when cover is in place) ending sensor section center conductor from prior section of the from annunciator -+12 VDC zone from annunciator - ground Figure 5-33 End of zones Intelli-FLEX II product guide • • • 5 - 33...

  • Page 70: Cable Devices

    If the center conductor is not damaged as described above, you can use cable splices for repair. Splice kit terminal block enclosure snaps closed upper half shell lower half shell Figure 5-34 Splice kit 5 - 34 • • • Intelli-FLEX II product guide...
  • Page 71 7. Snap the two halves of the shell together. 8. Secure the completed assembly to the fence fabric horizontally at the top of the drip loop, (see “Drip loop” on page 4), using two UV-resistant tie wraps. Intelli-FLEX II product guide • • • 5 - 35...
  • Page 72 6. Snap the two halves of the shell together. 7. Secure the completed assembly to the fence fabric horizontally at the top of the drip loop, (see “Drip loop” on page 4), using two UV-resistant tie wraps. 5 - 36 • • • Intelli-FLEX II product guide...

  • Page 73: Installing The Intelli-Flex Ii Processor

    Figure 5-36 Intelli-FLEX II dual zone processor The Intelli-FLEX II dual zone processor is shipped mounted inside a NEMA 4 rated weatherproof enclosure. The processor should remain inside the enclosure during the installation of the enclosure. The enclosure must be mounted on a wall, or a flat stable surface that is at least 36 cm w X 41 cm h (14 in.

  • Page 74: Installation Guidelines

    Installation guidelines Consult the local electrical code for power and grounding requirements. When installing an Intelli-FLEX II processor, keep the following points in mind: • to help prevent tampering Senstar, recommends that you install the processor on the secure side of the perimeter at a location other than on the fence where the sensor cable is installed •...

  • Page 75: Intelli-Flex Ii Processor Settings

    JP-3 Unused processor A/D inputs • Three jumpers hold the inputs to three A/D inputs on the microprocessor at 0 VDC. DO NOT remove this shunt unless specifically instructed. Intelli-FLEX II product guide • • • 5 - 39...
  • Page 76 Reserved for future use. The shunt must remain installed on JP-6. Alarm and supervision relays The dual zone Intelli-FLEX II processors may be connected to many types of alarm monitoring/report systems using the two form C, single-pole, double-throw latching type, output relays for each zone.
  • Page 77 Intelli-FLEX II relay contacts. Relay contact ratings The connections to the Intelli-FLEX II processor are rated at 0.5 amp maximum, 30 VAC/DC maximum. NO - opens to report alarm...

  • Page 78: Wiring Connections

    (e.g., black-negative, black with white stripe-positive). If the wire color is different than what is specified in this figure, use a meter to confirm the polarity. Figure 5-40 Powering a single Intelli-FLEX II processor 5 - 42 • • • Intelli-FLEX II product guide...
  • Page 79 On the DC power/float charger connect: • Black lead to (—) and to earth ground • Red lead to (+) • Install the gel cell battery inside the NEMA enclosure. Intelli-FLEX II product guide • • • 5 - 43...
  • Page 80 Use a minimum of #14 gauge wire for power runs up to 1.2 km (4000 ft.). For longer runs use #12 gauge wire. 5 - 44 • • • Intelli-FLEX II product guide...
  • Page 81 • Splice the distribution cable to the DC output wire from the central power supply. A terminal strip may be used instead of wire nuts. Figure 5-43 Obtaining 48 VDC Intelli-FLEX II product guide • • • 5 - 45...
  • Page 82 If a UPS system is not already a part of the overall security installation, a small standalone UPS system may be used to power the Intelli-FLEX II perimeter system. The UPS system may be purchased from a local supplier or from Senstar.
  • Page 83 Intelli-FLEX II processor settings Each Intelli-FLEX II processor requires approximately 1 W of power, making the total power consumption of even large systems very small. A small UPS system that is designed to run a personal computer system (typically 300 Watts) for 15 or 20 minutes will power an Intelli-FLEX II perimeter system for several hours.
  • Page 84 18 VDC and 56 VDC. • For processors using DC power/float charger, check TB1 terminals 3 and 4. Verify voltage is between 11.5 VDC and 16 VDC. 5 - 48 • • • Intelli-FLEX II product guide...

  • Page 85: The Configuration Module

    Select Figure 6-1: Configuration Module The Intelli-FLEX II Configuration module is a support tool for the Intelli-FLEX II Processor. It allows you to configure the Intelli-FLEX II sensor's operating parameters to the specific site conditions for each sensor zone. It also acts as a monitoring device by allowing you to observe the Intelli-FLEX II system activity during setup and operation.

  • Page 86: Modes Of Operation

    This chapter describes the Configuration module features. Modes of operation The Intelli-FLEX II system has three modes of operation - monitor, configure and level. All three modes are accessible with the Configuration module installed. The processor automatically returns to monitor mode after the configuration module has been disconnected from the processor board.
  • Page 87 These parameters should not be altered by personnel who do not have an in- depth knowledge of the Intelli-FLEX II processor signal processing program. Access to functional parameters requires a special cipher code. Intelli-FLEX II product guide • • • 6 - 3...
  • Page 88 The displayed value is peak trigger parameter for the indicated zone Ambient Compensation The displayed value is the ambient compensation parameter for the indicated zone Common Mode The displayed value is the common mode parameter for the indicated zone 6 - 4 • • • Intelli-FLEX II product guide...
  • Page 89 The Climb LED will also illuminate along with the Alarm LED and appropriate Zone LED when a cut scenario from either zone triggers an intrusion alarm. Intelli-FLEX II product guide • • • 6 - 5...
  • Page 90 To return to Auto Clear mode press Function Select twice. Alarm LED Indicates an alarm condition is being reported by the processor. Supervision LED Indicates that a supervision condition exists in the processor. 6 - 6 • • • Intelli-FLEX II product guide...
  • Page 91 30 seconds. The Time Window for Climb may be set from a minimum of the climb time parameter, to a maximum of 99 seconds. The factory preset value for climb is 20 seconds. Intelli-FLEX II product guide • • • 6 - 7...
  • Page 92 Monitor Level mode. To enter Level mode press Function Select. To access the features in this mode you are required to enter a cipher code. Contact Senstar for more information. Relay Time LED Indicates that the displayed parameter is the length of time that the alarm relays will activate when there is an alarm condition.
  • Page 93 (01) the ambient readings in both zones must be similar or Ambient Compensation will not take place, When Common Mode is disabled (00) Ambient Compensation will always take place. The factory setting is 00. Intelli-FLEX II product guide • • • 6 - 9...

  • Page 94: Function Key Descriptions

    Function key operation in monitor mode The following section describes the Configuration module key functions. When the configuration module is in the Monitor mode (Monitor LED lit) the keys function as described below. 6 - 10 • • • Intelli-FLEX II product guide...
  • Page 95 This key is used to acknowledge a supervision alarm message if one has been output to the module. In Level mode, pressing Clear will reset the display value to 00 and will set the processor to Manual Clear Mode. Intelli-FLEX II product guide • • • 6 - 11...
  • Page 96 2. If already in configure mode select Zone 1-Cut-Time Window. 3. Press Function Select, then Clear. 4. Observe decimal point goes out, if it was on. 5. Check configuration parameters. They should all be the factory default values. 6 - 12 • • • Intelli-FLEX II product guide...
  • Page 97 Pressing Increase will increase the value of a parameter displayed by one unit. Decrease Pressing Decrease will decrease the value of a parameter displayed by one unit. Clear The Clear key has no effect in Configure mode. Intelli-FLEX II product guide • • • 6 - 13...

  • Page 99: System Calibration

    It will sequence through the following steps: • On the Configuration module - the Monitor LED will light up. On the processor - the 2 alarm, 2 supervision and 1 power LEDs will light up. Intelli-FLEX II product guide • • • 7 - 1...
  • Page 100 PF to indicate that input power is low. • Press Clear to continue operation. (The power fail supervision alarm may be disabled by removing the jumper cap from JP5 on the processor board). 7 - 2 • • • Intelli-FLEX II product guide...

  • Page 101: Configuration Settings

    1. If there is some sensor input the value may immediately change from 00. The reading will automatically clear. If you wish to change to manual Clear Mode, press Clear. This will hold the peak value until Clear is pressed. Intelli-FLEX II product guide • • • 7 - 3...
  • Page 102 3. Procedure as in steps 3 to 5 in for Gain setting procedure - Zone 1, but adjust R26, on the processor board, instead of R19. 4. Exit the level mode by pressing Function Select. This will toggle the Configuration module back to the Monitor mode display. 7 - 4 • • • Intelli-FLEX II product guide...
  • Page 103 (i.e., nuisance alarms would not be caused by bad weather). • To simulate a threshold event use a medium length screwdriver 20 to 30 cm (8 to 12 inches) long. Intelli-FLEX II product guide • • • 7 - 5...
  • Page 104 Zone 1, Cut and Alarm LED’s light • the audible alarm is heard • L1 is displayed indicating that Zone 1 is in alarm • on the processor board, the Zone 1 alarm LED is lit 7 - 6 • • • Intelli-FLEX II product guide...
  • Page 105 Although each is reported separately by the Configuration module, they energize the same alarm relay. Intelli-FLEX II product guide • • • 7 - 7...
  • Page 106 Configuration settings The following are detailed step-by-step examples of how to view and change the Intelli-FLEX II configuration settings. A procedure similar to the examples below is used to sequence, view or change the other configuration settings. Cut Count - Zone 1...
  • Page 107 To view or change the length of time for the Climb Window in Zone 2, set up the Configuration module so that Zone 2 is selected instead of Zone 1, then proceed with the instructions for Zone 1. Intelli-FLEX II product guide • • • 7 - 9...

  • Page 108: Zone Profile Evaluation

    20 and 30, the result is an EXCELLENT zone profile. Excellent profiles are most often found on new fences that are in excellent condition. The poles are rigid, and the fabric is tight and consistently tensioned. 7 - 10 • • • Intelli-FLEX II product guide...
  • Page 109 If a high level of performance is expected from the Intelli-FLEX II system, the fence must be improved, so that the zone profile can rate at least GOOD.

  • Page 111: Maintenance/Troubleshooting

    2. Physically test the system (once per week). • use a screwdriver to simulate a cut intrusion and verify a cut alarm is declared Intelli-FLEX II product guide • • • a - 1...

  • Page 112: Troubleshooting

    Troubleshooting This section provides information that will be useful when attempting to locate and correct problems with the Intelli-FLEX II system. It is organized by problem symptom as follows: • Supervision related problems •...

  • Page 113: Supervision Related Problems

    04. 4. The Monitor mode LED will be lit. Supervision related problems Supervision alarms occur in the Intelli-FLEX II system for the following reasons: • The supervision current in a sensor line is outside of prescribed limit. (Supervision alarm in affected zone.) •...
  • Page 114 Supervision alarm persists. Sensor line supervision A supervision alarm occurs when the supervision current on the Intelli-FLEX II sensor line falls outside the prescribed design limits. This usually occurs when there is an open or a short in the sensor cable...
  • Page 115 A tamper supervision alarm occurs when the door of the enclosure that houses the Intelli-FLEX II processor is opened. When the door is tightly closed, a small magnet is held close to a Hall-effect sensor. The output from the sensor to the...
  • Page 116 3. If the magnet clears the door tamper, it is possible the magnet on the door needs to be repositioned. Contact Senstar for instructions on how to reposition the magnet. This should be done with care, since it is possible to damage the processor board and the Hall effect sensor if it is not done properly.

  • Page 117: Detection Problems

    2. Visually inspect all junctions and connections to insure they are well mated. Be suspicious of any connection that is not “Perfect”. Intelli-FLEX II product guide • • • a - 7...
  • Page 118 4. Attach a high impedance input amplified speaker to the pre-amp test point for the zone you are testing. (Contact Senstar for availability.) Compare the sound of the zone that is not working properly with one that is for clues that might lead to the cause of the problem.
  • Page 119 5. Re-install the sensor cable on the fence. If the methods described above DO NOT eliminate the low spot, replace the cable section with a new length of Intelli-FLEX cable. Intelli-FLEX II product guide • • • a - 9...

  • Page 120: False/Nuisance Alarm Problems

    Wiggle the junction slightly while listening to the signal to see if the problem is at the junction. The difference between the sound of the cable reacting to some movement and the sound due to a loose connection is obvious. a - 10 • • • Intelli-FLEX II product guide...
  • Page 121 50/60 Hz hum pick up in the system. Do not use the fence structure as an earth ground reference. See Grounding on page 5 - 47. Intelli-FLEX II product guide • • • a - 11...

  • Page 122: Power Problems

    The Adaptive algorithms used by the Intelli-FLEX II processor are most effective when the preamplifier gain, and the event thresholds are set properly. Power problems This section describes typical problems that might be encountered when operating the Intelli-FLEX II processor from different types of power sources.
  • Page 123 Maintenance/Troubleshooting - Power problems DC power operation If the Intelli-FLEX II Processor is being operated on 12 VDC power using the DC power/float charger and Gel Cell battery, and a low voltage DC shutdown appears to be indicated, proceed as follows: 1.

  • Page 124: System Shutdown

    A defective battery may never charge to reach 11 volts. If the 0.8 amp-hour battery that is supplied with the Intelli-FLEX II processor does not reach 11 volts after about 10 minutes of charging, it is defective and should be replaced. A defective battery that is fully discharged may quickly charge to a voltage of 11 volts, but not hold a charge.

  • Page 125: Configuration Module Problems

    If the system is powered by distributed low voltage (24 or 48 VDC) a backup battery should not be connected at the processor. The converter used on the Intelli-FLEX II processor will operate over an input range of 18 to 56 VDC. If the input voltage is in this range and you measure less than 11 volts at TP2 (VDD), check to make sure the total load on the processor is less than 250 mA.
  • Page 126 Always confirm the Configuration module is defective by attaching to another processor, if available, and by trying a new cable, before concluding the Configuration module is defective. a - 16 • • • Intelli-FLEX II product guide...

  • Page 127: Spare Parts List

    Provides security across a sliding or swinging gate. Sliding gate disconnect C6KT0101 EJ-9 Sliding gate disconnect assembly for Mark 2 assembly sensor cable, provides security across a sliding or swinging gate Intelli-FLEX II product guide • • • b - 1...
  • Page 128 Intelli-FLEX II dual zone Intelli-FLEX II dual zone processor board C6EM0701 — complete with mounting plate, mounted in a processor & enclosure fiberglass NEMA 4 rated enclosure. b - 2 • • • Intelli-FLEX II product guide...

  • Page 129: Component Specifications

    NEMA 4 fiberglass Enclosure - dimensions 30.0 cm high x 25.0 cm wide x 15.0 Enclosure cm deep (12.00 x 10.00 x 6.00 inches) nominal Type-F coaxial cable input. Other connections made via removable terminal Connector blocks PCB-mounted magnetic Hall-effect sensor Tamper switch Intelli-FLEX II product guide • • • c - 1...

  • Page 130: Gate Bypass Module

    Terminating resistor internal 1 meg ohm, can be used to terminate the sensor cable single-pole, single-throw (SPST) double-pole, single-throw (DPST) Tamper switch microswitch microswitch Environmental -40 to +66 ºC temperature c - 2 • • • Intelli-FLEX II product guide...

  • Page 131: Glossary

    Glossary Ambient compensation Refers to the ability of the Intelli-FLEX II to sense the environmental signal levels in the zone. Adjustments are made to the detection algorithms based on these signal characteristics so that response to weather conditions is minimized without reducing detection capability. This is a technician level adjustment.
  • Page 132 If neither the cut count or climb time requirement is met before the time window resets, the cut count and climb time accumulations are reset. glossary - 2 • • • Intelli-FLEX II product guide...

  • Page 133: Index

    ......7-7 Intelli-FLEX II product guide • • • i - 1...
  • Page 134 Intelli-FLEX II processor installation see processor Intelli-FLEX II system diagram ..... . .3-1 intruder detection ....... .2-2 intrusion alarm.
  • Page 135 ....... 5-45 Intelli-FLEX II product guide • • • i - 3...
  • Page 136 ......7-10 i - 4 • • • Intelli-FLEX II product guide...

  • Page 137: Mark 2 Sensor Cable Installation Procedure

    Intelli-FLEX™ Instruction Sheet #15 September 5, 2008 C6DA1503-001, Rev F Mark 2 sensor cable installation procedure Introduction Carefully remove 30 cm (12 in.) of the outer jacket, shield and dielectric to expose 30 cm of the center conductor at both ends of the cable. Before installing Mark 2 sensor cable (PN C6FG0902) you MUST stabilize the cable.

  • Page 138: Sensor Cable Installation Guidelines

    The sensor cable can be mounted on either side of • the fence (site dependent). When the stabilization procedure is complete, have Senstar strongly recommends installing the sensor cable on both grippers simultaneously release the tension the secure side of the fence. on the center conductor.

  • Page 139: Installation Procedure

    0.5 to 1 m (1.6 to 3.3 ft.) of extra sensor cable at the start point to install a splice kit (for connecting Senstar recommends that you create a 30 to 45 cm • the sensor cable to the lead-in cable).

  • Page 140: Adjusting Low Sensitivity Detection Spots

    Senstar, and Senstar-Stellar are registered trademarks of Senstar-Stellar Corporation. Armour-FLEX, Intelli-FLEX and the Senstar logo are trademarks of Senstar Corporation. Other Product names and Company names included in this document are used only for identification purposes, and are the property of, and may be trademarks of, their respective owners.

Table of Contents
