Axis Pro
Stringing Machine
• 360° Racket Rotation
• Diamond-Dusted Clamps
• Spring-Action Locking Levers
• 6-Point "Wide-Stretch" Mounting Arms
• Height Adjustment
• Sturdy Machine Stand
• Adjustable Level Pads
• Metal Tool Tray
1
ALPHA SPORTS 1-800-922-9024

Advertisement

loading
Need help?

Need help?

Do you have a question about the Axis Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Alpha Axis Pro

  • Page 1 Axis Pro Stringing Machine • 360° Racket Rotation • Diamond-Dusted Clamps • Spring-Action Locking Levers • 6-Point “Wide-Stretch” Mounting Arms • Height Adjustment • Sturdy Machine Stand • Adjustable Level Pads • Metal Tool Tray ALPHA SPORTS 1-800-922-9024...
  • Page 2 GENERAL INFORMATION WARRANTY The Axis Pro has a 5-year limited warranty. The string clamps have a 2-year limited warranty. The limited warranty pertains to any parts deemed defective by the manufacturer. MAINTENANCE • The string clamps will have to be cleaned on a regular basis.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS I. DIAGRAM..........4 II. COMPONENT PARTS LIST....5 III. ASSEMBLY INSTRUCTIONS....6 IV. MOUNTING THE FRAME.....8 V. PREPARATION OF STRINGING..10 VI. STRINGING THE FRAME....11 VII. CALIBRATION OF THE MACHINE..16 VII. CLAMP BASE ADJUSTMENT....18 TS 1-800-922-9024 ALPHA SPORTS 1-800-922-9024...
  • Page 4: Diagram

    DIAGRAM ALPHA SPORTS 1-800-922-9024 ALPHA SPORTS 1...
  • Page 5: Component Parts List

    BASE POLE TENSION ARM TENSION HEAD STRING GRIPPER ANGLED SUPPORTS SWIVEL BASE STRING CLAMP FRAME SUPPORT MOUNTING ARM POST MOUNTING POST ADJUSTMENT KNOB DISK BRAKE LEVER HEIGHT ADJUSTMENT SCREW TOOL TRAY LOCK SCREW FOR POLE TS 1-800-922-9024 ALPHA SPORTS 1-800-922-9024...
  • Page 6: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Lay base on a flat surface. Insert the pole into base, and tighten lock screw with allen wrench. Connect the tool tray with the two 6mm allen screws. ALPHA SPORTS 1-800-922-9024 ALPHA SPORTS 1...
  • Page 7 To adjust the height of the machine, lift the mounting unit/tension arm to the desired height and then tighten the height adjustment screw located on the pole above the tool tray. TS 1-800-922-9024 ALPHA SPORTS 1-800-922-9024...
  • Page 8: Mounting The Frame

    Not doing this will allow the mounting arms to creep forward during the stringing process and cause damage to the racquet. NOTE: Both mounting arms are identical, the racquet can be mounted either way. ALPHA SPORTS 1-800-922-9024 ALPHA SPORTS 1...
  • Page 9 Turn the mounting arm adjustment knobs so that the angled frame supports fit up against the frame. The fit should be snug, but use caution. NOTE: Over-tightening can cause premature stress on the frame. TS 1-800-922-9024 ALPHA SPORTS 1-800-922-9024...
  • Page 10: Preparation Of Stringing

    If the string is of a thin gauge (16L, 17, 18) then the string clamp may need to be tightened. If the string gauge is thick (15, 15L, 16) then the string clamp may need to be loosened. ALPHA SPORTS 1-800-922-9024 ALPHA SPORTS 1...
  • Page 11: Stringing The Frame

    Your tension setting is now 62 lbs. NOTE: When the machine is not in use, release the tension on the spring by setting the tension back down to 9 lbs. TS 1-800-922-9024 ALPHA SPORTS 1-800-922-9024...
  • Page 12 1st left main and the first hole on the right would be the 1st right main. Thread the two ends of the main strings through the 1st left main and the 1st right main. Do this at the throat and head of the racquet. ALPHA SPORTS 1-800-922-9024 ALPHA SPORTS 1...
  • Page 13 Keep rotating until the latch “pops” out and activates the brake. This will keep the tension head in place and allow you to release the string clamp so that it can be repositioned. TS 1-800-922-9024 ALPHA SPORTS 1-800-922-9024...
  • Page 14 CAUTION: Use caution when pushing the lever back, placing the thumb high on the lever can cause the lever to “pinch” it. Rotate the tension head forward towards the racquet. ALPHA SPORTS 1-800-922-9024 ALPHA SPORTS 1...
  • Page 15 ‘notching’. When the crosses are completed, tie off and trim the excess string. To release the racquet, release the pressure on the mounting arms by loosening the adjustment knobs counter clockwise. TS 1-800-922-9024 ALPHA SPORTS 1-800-922-9024...
  • Page 16: Calibration Of The Machine

    Clamp the fixed end of the tension calibrator. Load the string on the other end of the calibrator and pull tension.TIP: Make sure the clamp is positioned far enough from the tension head to allow a proper pull. ALPHA SPORTS 1-800-922-9024 ALPHA SPORTS 1...
  • Page 17 IMPORTANT: Release the tension on the calibrator before making calibration adjustments. Repeat the process until the correct tension is pulled. Lock the locking screw so that the adjustment screw is secure. TS 1-800-922-9024 ALPHA SPORTS 1-800-922-9024...
  • Page 18: Clamp Base Adjustment

    Take the 3mm allen key and insert into the internal adjustment screw. Turn clockwise to increase tension. The ideal locking position for the lever should be down the center of the swivel base. ALPHA SPORTS 1-800-922-9024...
