- Page 1 V NYL-12U PROFESSIONAL Hi-Fi TURNTABLE INSTRUCTION MANUAL...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. - Page 4 DESCRIPTION The model VINYL-12U is a professional Hi-Fi turntable that plays vinyl records with belt drive transmission and manual drive system, DC precision servo mechanism with quick start/stop. It has two rotation speeds: 33 and 45 rpm with LED indicators. It allows fine speed and tone adjustment using a sliding potentiometer ±8%.
-
Page 5: Rear Panel
REAR PANEL 11.- Grounding screw. 12.- Turntable output, 2 x RCA connectors. The output level can be selected with the PHONO/LINE selector. 13.- PHONO/LINE: turntable output level selector: phono level or line level. 14.- USB: PC connection port, female USB B connector. 15.- Power supply input for mains adapter provided. - Page 6 ANTI-SKATING CONTROL ADJUSTMENT Place the ANTI-SKATING control at the same value selected on the scale ring so that it corresponds to the weight of the needle on the record. If the weight is 2 grams, the control must be set at value 2. SPEED PITCH CONTROL ADJUSTMENT 1.- This slider allows the rotation speed to be varied in a range of ±16% for DJ effects.
-
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS VINYL-12U CHARACTERISTICS Professional belt drive turntable. Precise DC servo motor with rapid start-stop. USB port for PC connection. Phono/line switch. 2 speeds: 33 and 45 rpm with strobe. Pitch Bend + and - speed controls. Professional s-shaped tonearm with slow rise and fall. -
Page 8: Warranty
2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
