- Page 1 CDA/CDD54.xxx,W Ausführungsbeschreibung Specification Antriebsregler 22 kW to 90 kW 45 A to 170 A Inverter Drive Systems 22 kW to 90 kW 45 A to 170 A...
- Page 2 Piktogramme/ Achtung! Attention! Misoperation may result in Fehlbedienung kann Pictograms Beschädigung oder Fehlfunktion des damage to the drive or malfunction. Antriebs führen. Gefahr durch elektrische Spannung! Danger from electrical tension! Impro- Falsches Verhalten kann Menschenle- per behaviour may endanger human life. ben gefährden.
-
Page 3: Table Of Contents
Table of Contents Mechanical installation Please note! ....................1-1 Wall mounting .................... 1-1 Installation Overview ..................... 2-1 2.1.1 CDA54.xxx ....................2-2 2.1.2 CDD54.xxx ....................2-3 2.1.3 Position plan CDA54.xxx,W ..............2-4 2.1.4 Position plan CDD54.xxx,W ..............2-4 EMC compliant installation ................ 2-5 Electrical isolation concept ............... - Page 4 Specification CDA/CDD54.xxx...
- Page 5 This specification supplements the operation manuals: Validity • CDA3000 Id.-No.: 0840.00B.x • CDD3000 Id.-No.: 0931.00B.x This specification replaces the following chapters in the above mentioned operation manuals: Operation Instructions CDA/CDD3000 Specification Chapter Subject Replaced Inside of cover, front Device overview, validity of software Mechanical installation Installation - overview EMC compliant installation...
- Page 6 Device overview Operation Instructions CDA/CDD3000 Specification Chapter Subject Replaced Inside of cover, front Device overview, validity of software CDA/CDD54.xxx BG 7 BG 7a 2 2 - 3 7 k W 45 - 55 kW 75 - 90 k W 4 5 - 7 2 A 90 - 11 0 A 14 3 - 1 70 A lade...
-
Page 7: Mechanical Installation
1 Mechanical installation Operation Instructions CDA/CDD3000 Specification Chapter Subject Replaced Mechanical installation Please note! Attention: Please strictly avoid that ... - any moisture enters into the device, - aggressive or conductive substances are in the immediate vicinity, - drill chippings, screws or foreign bodies drop into the device, - ventilation openings are covered. - Page 8 1 Mechanical installation ∅ CDx54...,Wx.x BG7a Weight ~32 kg ~32 kg ~37 kg 267,5 382,5 ∅ 5.6 (M5) 9.5 (M9) 9.5 (M9) Please provide additional space for bending radii of the connection cables! Table 1.1 Wall mounting dimensions (dimensions in mm) Specification CDA/CDD54.xxx...
-
Page 9: Installation
2 Installation Operation Instructions CDA/CDD3000 Specification Chapter Subject Replaced Installation - overview EMC compliant installation / PE-terminal Electrical isolation concept Motor connection Mains connection Overview Terminals X1, X18 and X21 on devices CDA54.xxx and CDD54.xxx have following cable cross- sections, depending on sizes: Size U, V, W, PE: 95 BG7a... -
Page 10: Cda54.Xxx
2 Installation 2.1.1 CDA54.xxx optional power supply unit 24 V ... 48 V DC : 1 A ... 2 A BG7/7a: 3 A ... 6 A CDA54.xxx < 0,3 m* *Use > 0.3 m shielded cables RS232 start Normaly open Relay Relay output Normaly... - Page 11 2 Installation Designation Function Connection possibility for control terminals, PC with D RIVE ANAGER RS232 port CM-RS485 - interface converter see chapter 2.1.3 Expansion board slot for e.g. optional module PROFIBUS-DP (CM- X8, X9 Optional slot 1 and 2 DPV1), IO-expansion (UM-8I4O), CAN-BUS, DSP402 (CM-CAN1, CM- CAN2) optional, 24 V -20 % ...
-
Page 12: Position Plan Cda54.Xxx,W
2 Installation Designation Function H1, H2, H3 Light emitting diodes Equipment status display Mains connection Mains supply connection, 3 x 460 V -25 % +15 % 5 digital inputs, 2 analog inputs, (10 bit / 12 bit) Control connection 2 digital outputs, 1 relay (normally open), ENPO PTC, following DIN 44082 Motor temperature monitoring linear temperature sensor KTY 84-130 or... -
Page 13: Position Plan Cdd54.Xxx,W
2 Installation H1-3 Fig. 1.4 Position plan BG7/7a 2.1.4 Position plan CDD54.xxx,W H1-3 Fig. 1.5 Position plan BG6 H1-3 Fig. 1.6 Position plan BG7/7a Specification CDA/CDD54.xxx... -
Page 14: Emc Compliant Installation
2 Installation EMC compliant Drive controllers are components intended for installation into industrially and commercially used equipment and machines. installation Commissioning (i. e. starting intended operation) is only permitted when strictly complying with EMC-directive (89/336/EEC). The installer/operator of a machine and/or equipment must provide evidence of the compliance with the protection targets stipulated in the EMC-directive. - Page 15 2 Installation Subject Projecting and installation regulations Use a bright backing plate. Use cables and/or ground straps with cross sections as large as possible. Route PE-conductors of components in a star shaped pattern. To create a low-resistance HF-connection both grounding (PE) and shield connection must have large-area contact to the PE-bar on the backing plate.
-
Page 16: Electrical Isolation Concept
2 Installation Electrical isolation concept Option 3 x 460 V -25 % +10 % Mains fuses Mains contactor 24 V ... 48 V DC -25 % +10 % Option: single stage line filter 3 A-C Optional: 24 V supply control print DS power choke external controller : X2.05 (+24 V), X2.06 (GND) -
Page 17: Appendix
A Appendix Operation Instructions CDA/CDD3000 Specification Chapter Subject Replaced A Appendix Ampacity Technical data Ambient conditions Using a power choke Line filter UL-approval A.1 Permissible Maximum permissible controller output current and peak current depend on the mains voltage, the current load for motor cable length, the power stage switching frequency and the ambient temperature. - Page 18 Drive controller for 400/460 V networks: Rated Rated Power stage Peak current for Peak current for current current switching intermittent intermittent Module frequency operation operation [kHz] 0 to 5 Hz [A] > 5 Hz [A] at 400 V at 460 V CDA54.045,Wx.x CDA54.060,Wx.x CDA54.072,Wx.x...
-
Page 19: Technical Data
Technical data Designation Technical data Output motor side Recommended nominal power with 2-pin standard motor for 22 kW 30 kW 37 kW 47 kW 55 kW 75 kW 90 kW Voltage 3 x 0 ... 400/460 V Continuous current effective (I 45 A 60 A 72 A... -
Page 20: Using A Power Choke
Attention: Do not install the drive controllers in places where they are permanently exposed to vibrations. Using a power choke The use of power chokes is necessary: • where the drive controller is used in applications with disturbance variables corresponding with environment class 3, as per EN 61000-2-4 and above (hostile industrial environment). -
Page 21: Line Filter
Mains load (example) Without power choke With power choke Change without power choke 4 kW drive controller, 4 kW drive controller, compared to with power mains impedance 0.6 mH mains impedance 6 mH choke 99 % 33 % -67 % Voltage distortion (THD) Mains current amplitude 18.9 A... - Page 22 Measures to maintain UL approbation (UL 508C) for size 6, 7, 7a UL-approbation 1. The devices are evaluated to be used in Overvoltage Category III. 2. The devices are suitable for use on a circuit capable of delivering not more than 10 kA rms. symmetrical amperes and maximum 480 Volts.
- Page 23 Max. input- / (output-) Max. motor load [hp] current [A] Max. switching Device frequency 220 - 277 VAC, 380 - 480 VAC, 0 - 265 VAC, 0 - 460 VAC, [kHz] 3 phases 3 phases 3 phases 3 phases 50 Hz - 60 Hz 50 Hz - 60 Hz 0 Hz - 500 Hz CDA/CDD54.072...
- Page 24 Max. input- / (output-) Max. motor load [hp] current [A] Max. switching Device frequency 220 - 277 VAC, 380 - 480 VAC, 0 - 300 VDC, 0 - 530 VDC, [kHz] 3 phases 3 phases 2 phases 2 phases 50 Hz - 60 Hz 50 Hz - 60 Hz 0 Hz - 500 Hz CDD54.090DZ...
- Page 25 Specification CDA/CDD54.xxx...
- Page 26 LTi DRiVES GmbH Gewerbestraße 5-9 35633 Lahnau Fon +49 (0) 64 41 / 9 66-0 www.lt-i.com Id.-Nr. / ID no.: 1001.21B.2-00 • 04/2014 Technische Änderungen vorbehalten. We reserve the right to make technical changes.
