Koheras BOOSTIK
User Guide
Start and connect CONTROL
Note:
The CONTROL installer can be downloaded from the
following URL:
https://www.nktphotonics.com/lasers-fibers/support/software-
drivers/
1 Start the NKT Photonics CONTROL application on the connected
PC.
2 Click the Connect button.
3 Wait for CONTROL to scan all available ports.
4 When CONTROL connects to the module, the Control Panel and
Status Panel will appear.
Set the module amplifier to power or current mode
1 In the status panel, click on the settings gear icon
drop down menu,
2 In the Settings panel, click on the Mode drop down menu, and
select Power or Current.
3 Selecting:
Power mode configures the amplifier booster output power to be
•
held constant at the set level.
Current mode configures the amplifier booster pump current is held
•
constant at the set level.
4 Click the icon to return to the main Control panel view.
and from the
select Power/current mode.
Click the
Connect
button
Control panel
Click Standby:
1: Standby indicator Blinks &
Listen indicator stays ON
2: Standby indicator ON Amber
& Listen indicator extinguished
3. Laser is now warmed up.
5
Status panel
Mode drop
down menu
