Overview
The front panel has 3 buttons. The lower two are used most often, while the
third button is behind the
program mode.
Fig.1
Channel
Indicator
Set empty bucket
weight to zero
Display Units
The instrument can display up to 9999 tons. If you prefer to work in lbs units,
this option is selectable from the program mode.
When set to the "USA" readout option, the display will read up to 9990 lbs
rounded to the nearest 10 lbs. Above this threshold (e.g. when displaying any
of the totals) the display will alternate between "lbs x 1000" and any
remainder. The instrument can display up to 99,990 lbs
For example, for a total of 22,563 lbs the display will alternate between :
Fig. 2
4
logo.
This button is used to enter the
Select Sub-total
Enter Program
Mode
channels 1-5
or
Grand Total
(Ch. 6)
