  • Page 1 Technical Manual SensorMATe 3 Version 1...
  • Page 2 Copyright Possum 2017 SensorMATe 3 Technical Manual Version 1 January 2017 Page 2...

  • Page 3: Table Of Contents

    Table of Contents 1. General description . ..4 2. Parts List ..5 3. Important Do’s and Don’t’s............6 4. Battery Power................7 5. LCD Input Status Display............8 6. Button operation / Menu Navigation..........10-12 7. Functionality Explained..........13-18 8. Fault Finding Guide..............21 Refurbishment Instructions............22 10.

  • Page 4: General Description

    1 General description The SensorMATe 3 is a universal radio transmitter that can be used to transmit specific alarm events to the Possum Telecare range of receivers such as the Infopager 2G or Neo Carephone units. The unit can be interfaced directly to two separate sensor mats using the RJ12 and RJ10/RJ22 input sockets located on the top of the device.

  • Page 5: Parts List

    2 Parts List SensorMATe (Pt No 034-892) The table below indicates the kit sets, products and spare parts that are available and can be used with the SensorMATe 3. Sensor Mats/Spare Parts list Part Number Description 035-247 SensorMATe 3 Paper thin (Tyvek) Sensor Kit 035-248 SensorMATe 3 Paper Thin (Mylar) Sensor Kit 035-249...

  • Page 6: Important Do's And Don't's

    3 Important Information – “Do’s and Don’ts” To ensure equipment operation and maintain equipment condition always carry out the following actions: Do not use this device for any other purpose than that specified by the manufacturer. • Always carry out a “Prior to use check” to confirm equipment operation. •...

  • Page 7: Battery Power

    4 Battery Power Under normal operating conditions battery life expectancy should exceed 1 Year. However be aware that high fluctuations in temperature may seriously affect expected battery life. To ensure battery life exceeds one year in the SensorMATe 3 please use only high quality Alkaline AA cells.

  • Page 8: Lcd Input Status Display

    5 LCD Input Status display (Main Screen) The Status of the connected inputs is displayed at the top of the main screen in reverse video adjacent to the connected input device. The device temperature “Room Temperature” or the “Low Battery” indication is situated in the middle of the display.
  • Page 9 Paper Thin Calibration – Main Page Pod Calibration Menu – “Set bed EMPTY” shown Pod Calibration Menu – “Set bed OCCUPIED” shown Pod Calibration – Test menu Paper Thin DISCONNECTED prompt Test Menu Display Page 9...

  • Page 10: Button Operation / Menu Navigation

    6 Button Operation / Menu Navigation Navigation between the user menus and the functionality of SensorMATe 3 is controlled and programmed accordingly via the push button membrane switches. 6.1 Button Functionality Functionality of the push buttons is as listed below: Membrane Button Functions Button Operation...
  • Page 11 6.2 Initial Configuration Upon initial switch on the LCD will momentarily display (approx. 2 Seconds) the SensorMATe welcome screen. This screen contains information on the SensorMATe variant and firmware version of the device. Possum SensorMATe VX.XX Copyright <C>Possum 2015 <UK English / UK DST> After the version information has been displayed the user will be prompted to enter the current date and time into the unit Please Set Time &...
  • Page 12 6.3 Menu Navigation To navigate to the “Settings” menu momentarily press the enter button The “Settings” menu will be displayed on the SensorMATe screen. The menu structure of the SensorMATe is shown below; navigation between the required pages and entry of the required data is achieved by using the relevant navigation buttons.

  • Page 13: Functionality Explained

    7 Functionality explained 7.1 Set Time The SensorMATe contains a real time clock which can be used to allow for the time scheduling of any of the sensor solutions being monitored. It automatically compensates for Daylight Saving Time (DST). The time is adjusted from within the “Settings” menu by navigating to the “Set Time” area and following the on screen prompts.
  • Page 14 7.3 System Settings This area contains settings which can be used to alter installation parameters and protect the current configuration of the SensorMATe. The settings in this area are as follows: Op. Mode – This function allows the Left and Right inputs to be configured •...
  • Page 15 The default settings are: o Operating Mode: Independent Inputs. o LH (RJ12) Socket used with paper thin bed occupancy solutions. o RH (RJ10) Socket used with Enuresis sensing mat. 7.4 Left and Right Input Configuration The SensorMATe can have two individual sensors connected to and continuously monitored using the RJ10/22 (RH socket) and RJ12 (LH Socket) located on the top of the product.
  • Page 16 NormClosed (2&3) - Normally closed sensor device connected between pins 2 and • 3 of the RJ22 plug or pins 3 and 4 of a RJ12 connector. Not Used (off) – Input not being used. (Note: Select this to increase battery life •...
  • Page 17 7.4.5 Tremble (0.5S) This setting is used with bed and chair occupancy solutions. It can reduce the number of false alarms which can be caused by people sitting up or fidgeting whilst being monitored. The setting is defaulted to 1 Second (Setting “2”) and can be adjusted in 0.5 Second adjustments to a maximum of 10 Seconds (Setting “20”).
  • Page 18 7.4.12 Day Start Hour Input the hour you wish “Day time” monitoring to begin. Note leave at “0” if there is no required configuration differences between Night and Day. 7.4.13 Day Start Mins Input the minute you wish “Day time” monitoring to begin. Note leave at “0” if there is no required configuration differences between Night and Day.
  • Page 19 Note: This setting should be set to “No” when there are multiple receivers in a system. This will prevent the first receiver acknowledging receipt of the signal and potentially stopping the SensorMATe transmission before other receivers have received the data. LoBatt.Al.Type –...
  • Page 20 Pressing and holding the “Enter” button causes the unit to continuously transmit the selected Alarm ID. This function is a useful tool for radio range testing as it allows the installer to easily test that the unit transmits reliably to all areas of a property. The unit also has the capability to analyze the serviceability, calibration and operation of the molded capacitive sensing pod and mat.

  • Page 21: Fault Finding Guide

    8 Fault Finding Guide. Fault finding on an installed SensorMATe and any attached sensor can easily be achieved using either a substitution of components methodology or by using the inbuilt test mode. The following table gives a brief outline of potential failure modes and corrective actions.

  • Page 22: Refurbishment Instructions

    9 Refurbishment Instructions. Cleaning Instructions The SensorMATe is not specially protected against spills or ingress of water or other liquids. Do not immerse the monitor in water or any cleaning fluid, and protect it from spills and splashes. Do not use it in a wet environment e.g. shower, bath, or swimming pool.

  • Page 23: Declaration Of Conformity

    10 Declaration of Conformity Page 23...

  • Page 24: Technical Specification And Approvals

    Page 24...
  • Page 25 11 Technical specifications Weight: 280gms Dimensions (including rubber shock protector): 120mm x 75mm x 30mm (L x W x D). Power requirements: 2 x AA Batteries (High Quality Alkaline Cells). Battery Life Expectancy: > 1 Year. Transmitted frequency: 869.2125 Mhz. Radio range: >...

  • Page 26: Rj Cable Grommet And Protective Label Installation

    12 RJ cable grommet and protective label installation. The SensorMATe capacitive sensing cable has a rubber grommet with double sided self- adhesive applied. When correctly installed this prevents connected sensing mats from being inadvertently removed from their respective sockets and provides a seal to prevent moisture or dust ingress.
  • Page 27 13 QR Codes, website links and notes area The following QR Codes and website pages contain links to training videos pertinent to the SensorMATe 3 product. Initial Power up: https://youtu.be/bMSOz3voZco Introduction: https://youtu.be/lfuuA8EVKH0 Keypad Functionality: https://youtu.be/mvG78terz7w Modes of operation: https://youtu.be/G-CJUJqn2Hs Reset to factory default: https://youtu.be/tYcr-QKJMZ0 Temp.
  • Page 28 Enuresis: https://youtu.be/Niv6YwYWA1U Paper Thin Calibration: https://www. youtu.be/OOjuHCvSDik Paper Thin: https://youtu.be/0tXXOHGC4zY Test Page: https://youtu.be/86GAFGscqXw Connectors explained: https://youtu.be/uPAdRYQK708 Radio settings: https://youtu.be/qOIWMNByMJo Page 28...
  • Page 29 Notes: Page 29...

  • Page 30: Weee Information

    14 WEEE Information Page 30...
