- Page 1 Oracle® Talari D6000 Hardware Guide F29965-02 April 2020...
- Page 2 Oracle Corporation and its affiliates disclaim any liability for any damages caused by use of this software or hardware in dangerous applications.
-
Page 3: Table Of Contents
Contents About this Guide My Oracle Support Emergency Response Revision History Oracle Talari D6000 Hardware Guide Hardware and Software Requirements Overview Talari APN Overview Front Panel Configuration Rear Panel Configuration NIC Indicator Codes Hardware Specifications Installing the Talari Appliance Rack Mounting... -
Page 4: About This Guide
You are connected to a live agent who can assist you with My Oracle Support registration and opening a support ticket. My Oracle Support is available 24 hours a day, 7 days a week, 365 days a year. Emergency Response If a critical service situation occurs, the Tekelec Customer Care Center offers emergency response twenty-four hours a day, seven days a week. - Page 5 About this Guide • Inability to perform maintenance or recovery operations • Inability to provide any required critical or major trouble notification • Any other problem severely affecting service, capacity, traffic, and billing. Maintenance capabilities may be defined as critical by prior discussion and agreement with the Tekelec Customer Care Center.
-
Page 6: Revision History
Table 1 Revision history table Date Change June 2019 • Initial Release October 2019 • Oracle Branding change March 2020 • Adds ILOM Snapshot setup and capture procedure • Adds Creating bootable USB drive (on Windows and Linux) procedure •... -
Page 7: Oracle Talari D6000 Hardware Guide
Oracle Talari D6000 Hardware Guide The following sections explain how to use your Oracle Talari D6000 Hardware and Software Requirements D6000 appliances have the following hardware and software requirements. Hardware D6000 appliances require a standard 19 inch (480 mm) 4-post rack for mounting. -
Page 8: Front Panel Configuration
Conduits is controlled and optimized to use network resources available across all WAN Links. Front Panel Configuration For more information on the front panel status indicators, please see the Oracle Server X7-2 Service Manual. Rear Panel Configuration Table 1-1... -
Page 9: Nic Indicator Codes
Chapter 1 NIC Indicator Codes Table 1-1 (Cont.) Ports Console RJ45 console port (115200/8-N-1). Used for service and maintenance. NIC Indicator Codes All Ethernet ports on the D6000 have indicator lights for information on network activity and link status. Table 1-2 Indicator Location Color... -
Page 10: Hardware Specifications
Height 1.68” (42.6mm) Width 18.9” (482mm) Depth 29.02” (737mm) Gross Weight 40 lbs (18.1kg) Mounting Options Rack mount, rail kit (included) Oracle Server X7-2 Service Manual System LEDs Link LEDs Link activity Link speed Operating Temperature 41°F to 95°F (5° to 35°C) Storage Temperature -40°F to 154°F (-40°C to 68°C) -
Page 11: Lan/Wan Connections
Do not move racks by yourself; at least two people are recommended to move a rack. • Cables should be easily identifiable. Please refer to the Oracle® Servers X7-2 and X7-2L Installation Guide for additional appliance specifications and detailed rackmounting instructions: https:// docs.oracle.com/cd/E72435_01/html/E72440/index.html. -
Page 12: Installation Option: Easy 1St Install
Use this option if recommended by your Sales Architect, or if you have an MPLS/Internet hybrid network and will not be using the CE Router Replacement functionality of Oracle SD-WAN Edge. Other Options There are other deployment options, and our Talari Implementation team members will assist you with planning and deploying your new appliance. -
Page 13: Installation Option: Manual Install
PC which can be connected to the console port of the Talari Appliance. The console port connects the user to the Oracle ILOM command line interface. Cable management, LAN, and WAN ports according to the Talari configuration for site. - Page 14 Connect the PC directly to the console port of the D6000 and console into the appliance using a bit rate of 115200/8-N-1. Log in to Oracle ILOM as an Administrator. To enable first time login and access to Oracle ILOM, a default Administrator account and its password are provided with the system.
-
Page 15: Collecting Ilom Diagnostics For D2000 And D6000
Collecting ILOM Diagnostics for D2000 and D6000 Enabling ILOM on your D2000 or D6000 appliance provides hardware support at the component level by means of an ILOM snapshot. Oracle's technical support center can analyze the snapshots and access data such as FMA reports to determine which components require replacement in a fault situation. - Page 16 Password: ******* Oracle(R) Integrated Lights Out Manager Version 4.0.4.33 r128860 Copyright (c) 2019, Oracle and/or its affiliates. All rights reserved. Warning: password is set to factory default. Warning: HTTPS certificate is set to factory default. Hostname: ORACLESP-1907XC3025 ->...
- Page 17 Chapter 1 Collecting ILOM Diagnostics for D2000 and D6000 In one command, initiate Snapshot and transfer the file to /tmp on host with the talariuser login credentials. -> set /SP/diag/snapshot dump_uri=sftp://talariuser@169.254.182.77/tmp Enter remote user password: ********* // Enter talariuser password Set 'dump_uri' to 'sftp://talariuser@169.254.182.77/tmp' ->...
-
Page 18: Creating A Bootable Usb Drive On Linux
Chapter 1 Creating a Bootable USB Drive on Linux Creating a Bootable USB Drive on Linux Before starting this process, ensure that the capacity of your USB drive is at least 4 To create a bootable USB drive on Linux: Download the D2000 or D6000 image from MOS. -
Page 19: Creating A Bootable Usb Drive On Windows 1-13
112140980 52274060 69% /home /dev/sdd2 2755604 2389404 222896 92% /run/media/oracle/USBBoot To unmount the partition on the drive, run the command:umount /run/media/ oracle/USBBoot. Run the df command again to make sure that there are no mounts matching your USB device name (/dev/sdd in the example.) Insert the USB drive. -
Page 20: Booting With The Usb Drive
Chapter 1 Booting with the USB Drive Click Start. You will be asked if it is OK to destroy all the data in the device. Click Yes. The USB burn process on a USB3 device can take 15 minutes. It may take longer if the device or port is USB2. - Page 21 Detecting screen size; please wait...done Oracle(R) Integrated Lights Out Manager Version 4.0.4.33 r128860 Copyright (c) 2019, Oracle and/or its affiliates. All rights reserved. Warning: password is set to factory default. Warning: HTTPS certificate is set to factory default. Hostname: ORACLESP-1907XC3025 ->...
- Page 22 Chapter 1 Booting with the USB Drive Figure 1-4 Boot Pop Up Menu The Boot Device menu is displayed in about 2 minutes. Figure 1-5 Boot Device Menu Using the Up/Down arrows keys, position the cursor on your install USB boot device.
- Page 23 Chapter 1 Booting with the USB Drive The GNU GRUB menu is displayed. It has a 5 second timeout. Figure 1-7 GNU GRUB Menu The system is now booting the USB. This process may take up to 5 minutes. After the process is complete, a login prompt is displayed.
- Page 24 Chapter 1 Booting with the USB Drive Figure 1-9 Device IP Address Configuration Note: After accepting the IP4 configuration, the installation script creates the partitions, formats the partitions, and loads the SDWAN OS and application software on the system. When this is complete, you are asked to type reboot and remove the USB drive.
- Page 25 Chapter 1 Booting with the USB Drive Figure 1-11 Appliance Ready for Use The appliance is ready for use. 1-19...
