Technical Specification - UDI filters UdiMatic 785290 Installation, Operation And Maintenance Manual

1 - TECHNICAL SPECIFICATION

Screen Area & Maximum Flow Rates
Model Inlet/Outlet diameter Max. Flow Rate Flush Flow Rate
inch
785290 1" (thr.)
7851B91 1½"
7851B92 2"
7851B93 3"
7851E94 4"
7851964 4"
785196 6"
785198 8"
The maximum flow rate refers to screens over 200 microns/ less than 80 mesh.
For a finer filtration degrees consult our representative.
Screen Grades
Micron 75 100
Mesh
200 150
* Other screen grades are available.
Electrical Data
Standard 230 V / 110 V – 50 Hz. For use of 110 V internal modifications have to be made.
DC models available on request.
Materials:
● Filter body: Polyester-coated steel (option: stainless steel)
● Rubbers: Natural rubber NR
● Filter element: Super Screen; multiple layers of stainless steel, sintered filter pack (1" and as option:
PVC screen)
Construction
The standard housing of the filter is made of carbon steel with a 120 micron protective coating of extra
durable polyester, applied electro-statically and oven cured on a zinc-phosphate layer, for maximum
anti-corrosion protection both internally and externally.
Access to the internal parts of the filter is through the removable bolted cover.
All immersed parts are made of either plastic materials or non-corrosive metals to ensure many years of
trouble free operation.
For special applications; contact our representative for more information.
3
UDI 12/2019
mm m /h
25 7
40 15
50 25
80 40
100 80
100 80
150 150
200 300
130 200 300 400
120 80 50 40
Manual
UdiMatic
Screen Area
m /h cm
2 - 3 270
5 850
5 850
5 1450
10 2360
10 4500
10 4500
14 6200
