Summary of Contents for Samsung HT-THX22
- Page 1 Instruction Manual DIGITAL HOME CINEMA SYSTEM HT-THX22 HT-THX25 AH68-01978B COMPACT AH68-01660E REV: 01 DIGITAL AUDIO...
-
Page 2: Safety Warnings
Safety Warnings CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE REAR COVER (or BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CLASS 1 LASER PRODUCT This Compact Disc player is classified as a CLASS 1 CLASS 1 LASER PRODUCT LASER product. -
Page 3: Table Of Contents
TV Screen Saver Function If the main unit remains in Stop mode for 3 minutes, the Samsung logo appears on the TV screen. The HT-THX22/HT-THX25 will automatically switch to the Power Saving mode after 20 minutes in the Screen Saver mode. -
Page 4: Notes On Discs
Notes on Discs DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital surround sound and MPEG-2 video compression technology. Now you can enjoy these realistic effects in the home, as if you were in a movie theater or concert hall. DVD players and the discs are coded by region. -
Page 5: Description
Description Front Panel 1. Disc Tray 5. Volume Control 2. Function button 6. USB Connector 3. Stop ( ) button 7. Power ( ) button 4. Play/Pause ( ) button 8. Standby indicator Display 1. DOLBY DIGITAL indicator 7. PROGRAM indicator 2. - Page 6 Description (Con’t) Remote Control Insert Remote Batteries 1. DVD RECEIVER button 2. TV button 3. TV/VIDEO button 4. POWER button 5. Number (0~9) buttons 6. REMAIN button 7. STEP button 8. Tuning Preset/CD Skip buttons 9. VOLUME button 10. MENU button 11.
-
Page 7: Connecting The Speakers
Connecting the Speakers Before moving or installing the product, be sure to turn off the power and disconnect the power cord. HT-THX22 Center Speaker Front Speaker (R) Rear Speaker (R) Subwoofer Position of the DVD Player Selecting the Listening Position •... -
Page 8: Speaker Installation
Stand Base. Connecting the Optional Wireless Receiving Amplifier To connect the rear speakers wirelessly, you have to purchase the wireless receiving module and TX card from your Samsung retailer. When you have Purchased the Wireless Receiving Module (SWA-3000) HT-THX22... - Page 9 Connecting the Optional Wireless Receiving Amplifier Slanted side faces down Connect the front, center and Subwoofer speakers to the DVD Player, reffering to pages 12~14. With the DVD Player turned off, insert the TX card into the TX Card Connection(WIRELESS) on the back of the main unit. Hold the TX card so that the slanted side faces downward and insert the card into the port.
-
Page 10: Connecting The Video Out To Your Tv
Connecting the Video Out to your TV Choose one of the four methods for connecting to a TV. METHOD 4 METHOD 1 (supplied) • This product operates in Interlace scan mode (576i, 480i) for component output. METHOD 1 : HDMI ... (Best Quality) Connect the HDMI cable (not supplied) from the HDMI OUT jack on the back of the DVD Player to the HDMI IN jack on your TV. -
Page 11: Hdmi Function
HDMI Function Resolution Selection This function allows the user to select the screen resolution for HDMI output. In Stop mode, press and hold the SD/HD (Standard Definition/High Definition) button on the remote control. Resolutions available for the HDMI output are 576p(480p), 720p and 1080i. SD(Standard Definition) resolution is 576p(480p) and HD(High Definition) resolution is 720p/1080i. -
Page 12: Connecting The Fm Antenna
Connecting the FM Antenna FM Antenna (supplied) Connect the FM antenna supplied to the FM 75 COAXIAL Jack. Slowly move the antenna wire around until you find a location where reception is good, then fasten it to a wall or other rigid surface. •... -
Page 13: Before Using Your Home Theater
Before Using Your Home Theater To Operate your Samsung TV and the Home Theater with the HT-THX22/HT-THX25's Remote Control The DVD Home Theater's remote can be used to control Samsung TVs. Plug the main unit's power cord into the AC power supply. -
Page 14: Mp3/Wma-Cd Playback
MP3/WMA-CD Playback Data CDs (CD-R, CD-RW) encoded in MP3/WMA format can be played. Place the MP3/WMA disc on the disc tray. The MP3/WMA menu screen will appear and playback will start. The appearance of the menu depends on the MP3/WMA disc. WMA-DRM files cannot be played. -
Page 15: Divx Playback
DivX Playback DivX The functions on this page apply to DivX disc playback. Skip Forward/Back During playback, press the Goes to the next file whenever you press the Goes to the previous file whenever you press the Fast Playback To play back the disc at a faster speed, press the playback. -
Page 16: Using The Playback Function
Using the Playback Function Displaying Disc Information You can view disc playback information on the TV screen. Press the INFO button. Each time the button is pressed, the display changes as follows: Display disappears JPEG DivX Display disappears • Depending on the disc, the disc information display may appear different. •... -
Page 17: Skipping Scenes/Songs
Using the Playback Function Skipping Scenes/Songs Press the button. Each time the button is pressed during playback, the previous or next chapter, track or directory (file) will be played. You cannot skip chapters consecutively. TITLE 01/05 CHAPTER 002/045 (Con’t) Repeat Playback Repeat playback allows you to repeatedly play a chapter, title, track (song), or directory (MP3 file). -
Page 18: A-B Repeat Playback
Using the Playback Function A-B Repeat Playback You can repeatedly play back a designated section of a DVD. Press the INFO button twice. Press the Cursor button to move to REPEAT PLAYBACK ( Press the Cursor button to select <A-> and then press the ENTER button at the beginning of the desired segment. -
Page 19: Ez View Function
Using the Playback Function EZ VIEW Function Press the EZ VIEW button. Each time the button is pressed, the zoom function will switch between On and Off. When a movie is played in Widescreen format, black bars at the top and bottom of the TV screen can be removed by pressing the EZ VIEW button. -
Page 20: Moving Directly To A Scene/Song
Using the Playback Function Moving Directly to a Scene/Song Press the INFO button. Press the Cursor button or numeric buttons to select the desired title/track ( ) and then press the ENTER button. Press the Cursor button to move to the Chapter ( Press the Cursor button or numeric buttons to select the desired chapter and then press the ENTER button. -
Page 21: Playing Media Files Using The Usb Host Feature
Playing Media Files using the USB Host Feature You can enjoy media files such as pictures, movies and music saved on an MP3 player, USB memory stick or digital camera in high quality video with 5.1 channel Home Theater sound by connecting the storage device to the USB port of the Home Theater. Connect the USB device to the USB port on the front of the unit. -
Page 22: Settings
Settings Setting the Language OSD(On-Screen Display) language is set to English by default. In Stop mode, press the MENU button. Press the Cursor button to move to <Setup> and then press the ENTER button. Select <LANGUAGE> and then press the ENTER button. Press the Cursor button to select <OSD LANGUAGE>... -
Page 23: Setting Parental Controls (Rating Level)
This selects one of the 3 wallpaper screens Press the EXIT button to exit the setup screen. • ORIGINAL : Select this to set the Samsung Logo image as your wallpaper. • USER : Select this to set the desired image as your wallpaper. -
Page 24: Divx (R) Registration
Settings (Con’t) DivX (R) Registration Please use the Registration code to register this player with the DivX (R) video on demand format. To learn more, go to www.divx.com/vod. Setting the Speaker Mode Signal outputs and frequency responses from the speakers will automatically be adjusted according to your speaker configuration and whether certain speakers are used or not. -
Page 25: Setting The Test Tone
Settings (Con’t) Setting the Test Tone Use the Test Tone feature to check the speaker connections. In Stop mode, press the MENU button. Press the Cursor button to move to <Audio> and then press the ENTER button. Press the Cursor button to move to <TEST TONE>... -
Page 26: Setting The Drc (Dynamic Range Compression)
Settings (Con’t) Setting the DRC (Dynamic Range Compression) This feature balances the range between the loudest and quietest sounds. You can use this function to enjoy Dolby Digital sound when watching movies at low volume at night. In Stop mode, press the MENU button. Press the Cursor button to move to <Audio>... -
Page 27: Sound Field (Dsp)/Eq Function
Settings (Con’t) Sound Field (DSP)/EQ Function DSP(Digital Signal Processor) : DSP modes have been designed to simulate different acoustic environments. EQ : You can select ROCK, POP, or CLASSIC to optimize the sound for the genre of music you are playing Press the DSP/EQ button. -
Page 28: Dolby Pro Logic Ii Effect
Settings (Con’t) Dolby Pro Logic II Effect This function works only in Dolby Pro Logic MUSIC mode. Press the PL II MODE button to select <MUSIC> mode. Press the PL II EFFECT button to select <PANORAMA>, then press the Cursor button to select the desired effect setting. -
Page 29: About Rds Broadcasting
Listening to Radio (Con’t) Presetting Stations Example : Presetting FM 89.10 in the memory Press the TUNER button to select the FM band. Press the button to select <89.10>. Press the TUNER MEMORY button. <PRGM> flashes in the display. Press the button to select preset number. -
Page 30: Convenient Functions
About RDS broadcasting PTY (Program Type) indication and PTY-SEARCH function One of the advantages of the RDS service is that you can locate a particular kind of program from the preset channels by specifying the PTY codes. To search for a program using the PTY codes Before you start, remember... -
Page 31: Operating A Tv With The Remote Control
TV. • If you do not set the remote control with the code for your brand of TV, the remote control will work on a Samsung TV by default. TV Brand Code List... -
Page 32: Troubleshooting
Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact the nearest authorized dealer or Samsung Electronics Service Center. Symptom •... -
Page 33: Cautions On Handling And Storing Discs
Cautions on Handling and Storing Discs Small scratches on the disc may reduce sound and picture quality or cause skipping. Be especially careful not to scratch discs when handling them. Handling discs Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints will not get on the surface. -
Page 34: Usb Host Feature Supported Products
Optio-S50 Pentax Digital Camera SI-M500L Optio 33LF Pentax Digital Camera Optio MX Pentax Digital Camera YP-T5 VB YP-53 Digimax-420 Samsung Digital Camera Digimax-400 Samsung Digital Camera Sora PDR-T30 Toshiba Digital Camera Coolpix 5900 Nikon Digital Camera Coolpix S1 Nikon Digital Camera... -
Page 35: Specifications
Center 3.25kg/3.0kg Front/Rear Weights 0.7kg Center Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. 5.1ch speaker system Subwoofer speaker 45Hz ~160Hz 86dB/W/M 100W 200W 175 x 320 x 390 mm 4.6kg...
