Wen 49103 Manual

3.6v lithium-ion
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3148819
Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
3.6V LITHIUM-ION
SCREWDRIVER
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
CORDLESS
Model # 49103
(M-F 8AM-5PM CST)
bit.ly/wenvideo

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 49103 and is the answer not in the manual?

Questions and answers

Related Manuals for Wen 49103

Summary of Contents for Wen 49103

  • Page 1 3148819 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.

  • Page 2: Table Of Contents

    Know Your Screwdriver Charging Your Screwdriver Operation Maintenance Disposal Exploded View and Parts List Warranty TECHNICAL DATA 49103 Model Number: 120V AC, 60 Hz, 0.15A Charger Input Voltage: Charger Output Voltage: 5V DC, 0.5A 3.6V DC Li-ion, 1.3 Ah Battery:...
  • Page 3 Customer Service at (800) 232-1195, M-F 8-5 CST. NOTE: The following safety information is not meant to cover all possible conditions and situations that may oc- cur. WEN reserves the right to change this product and specifications at any time without prior notice.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instruc- tions may result in electric shock, fire and serious injury. To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood.
  • Page 5 GENERAL SAFETY RULES POWER TOOL OPERATION 1. Avoid accidental start-ups. Make sure the power switch is in the OFF position before connecting the plug to a power source or carrying the tool. 2. Check power tool for damaged parts. Check for misalignment of moving parts, jamming, breakage, improper mounting, or any other conditions that may affect the tool’s operation.

  • Page 6: Specific Rules For Screwdrivers

    SPECIFIC RULES FOR SCREWDRIVERS 1. Hold the screwdriver only by the insulated gripping surfaces during operation. Fasteners that contact hidden wir- ing may make the exposed metal parts of the power tool “live” and could electrically shock the operator. Store the screwdriver and charger indoors in dry condition. Do not expose the screwdriver or the charger to temperatures over 104°F (40°C).
  • Page 7 SAFETY RULES FOR BATTERIES AND CHARGERS 7. Do not charge the tool inside a box or container of any kind. The tool must be placed in a well-ventilated area during charging. Do not allow anything to cover or clog the charging vents. 8.

  • Page 8: Electrical Information

    ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS FOR PRODUCTS WITH GROUNDING PLUGS WARNING: This tool must be grounded while in use to protect the operator from electric shock. 1. In the event of a malfunction or breakdown, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock.

  • Page 9: Know Your Screwdriver

    KNOW YOUR SCREWDRIVER Make sure all the following parts are accounted for before discarding the packaging. If any part is missing or broken, contact our customer service at 1-800-232-1195. Battery and Charger Indication Lights Quick Release Chuck INCLUDED ACCESSORIES : •...

  • Page 10: Operation

    OPERATION WARNING: To avoid personal injury and damage to the tool, do not attempt to operate the tool until the following operation instructions have been fully read and understood. LOCKING THE POWER SWITCH Before installing bits or making any adjustments, make sure to lock the power switch in the OFF position to prevent accidental starting.

  • Page 11: Maintenance

    OPERATION LED WORKING LIGHT The LED work lights (Fig. 7 - 1) are located on the front of the screw- driver, allowing workpieces to stay illuminated when the screwdriver is running. Fig. 7 MAINTENANCE This tool is permanently lubricated at the factory and requires no additional lubrication. There are no user ser- viceable parts in your power tool.

  • Page 12: Exploded View And Parts List

    EXPLODED VIEW & PARTS LIST...
  • Page 13 EXPLODED VIEW & PARTS LIST Part No. Name Qty. 49103-001 Nameplate Sticker 49103-002 Screw 49103-003 Screw 49103-004 Right Housing 49103-005 Charger 49103-006 Screw 49103-007 Output Shaft 49103-008 Small Washer 49103-009 Steel Ball 49103-010 Shaft Sleeve 49103-011 Front Cover 49103-012 Outer Gear...
  • Page 14 LIMITED TWO YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
