Wen 49140 Manual

4v max lithium-ion cordless screwdriver
Hide thumbs
Table of Contents

Advertisement

Quick Links

For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability, ease
of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
NOTICE: Please refer to wenproducts.com for the most up-to-date instruction manual.
4V MAX LITHIUM-ION
CORDLESS SCREWDRIVER
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
MODEL 49140

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 49140 and is the answer not in the manual?

Questions and answers

Related Manuals for Wen 49140

Summary of Contents for Wen 49140

  • Page 1 WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.

  • Page 2: Table Of Contents

    Operation ..................12 Maintenance .................. 14 Troubleshooting Guide ..............15 Exploded View & Parts List ............16 Warranty Statement ............... 18 SPECIFICATIONS Model Number 49140 Battery 4.0V (max), 3.6V (nominal), 1.5Ah Chuck Size Ø 1/4 in. Rated Speed 180 RPM Rated Torque 48.7 in.

  • Page 3: Introduction

    INTRODUCTION Thanks for purchasing the WEN Cordless Screwdriver. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and understand this operator’s manual and all the labels affixed to the tool. This manual provides information regarding potential safety concerns, as well as helpful assembly and operating instructions for your tool.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Read and understand all warnings, cautions and operating instructions before using this tool. Failure to follow all instructions listed below may result in personal injury and tool damage.
  • Page 5 GENERAL SAFETY RULES 4. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the switch on invites accidents. 5.

  • Page 6: Specific Safety Rules For The Screwdriver

    SPECIFIC SAFETY RULES FOR THE SCREWDRIVER WARNING: Do not let comfort or familiarity with the product replace strict adherence to product safety rules. Failure to follow the safety instructions may result in serious personal injury. 1. TOOL PURPOSE. This screwdriver is designed to fasten and remove screws from wood, plastic, and light-gauge metal.
  • Page 7 SPECIFIC SAFETY RULES FOR THE SCREWDRIVER 12. Always remove the machine from the charger immediately after re-charging is completed. 13. Do not try to open or disassemble your screwdriver. Do not open and replace the battery cells. 14. CLEANING. Never use solvents to clean plastic parts. Solvents could dissolve or otherwise dam- age the material.

  • Page 8: Safety Rules For Batteries And Chargers

    SAFETY RULES FOR BATTERIES AND CHARGERS CHARGING THE BATTERY 1. Before charging and using the battery, read all cautionary markings on the battery charger, battery cable, and the product using the battery. 2. Only recharge the battery with the charger specified by the manufacturer. Do not use the supplied battery charger to charge other cordless tools as undesirable risks such as fire or death may occur when used with another battery.
  • Page 9 SAFETY RULES FOR BATTERIES AND CHARGERS USING THE BATTERY 1. Only use the tool with the battery specified by the manufacturer. Use of any other battery packs may result in a risk of injury and fire. 2. Under abusive conditions, liquid may be ejected from the battery. Avoid contact with this liquid like you would a fire or an ex-lover.

  • Page 10: Charging Information

    CHARGING INFORMATION WARNING: The battery must be charged fully before the first time use. CHARGING YOUR SCREWDRIVER Fig. 1 1. Inspect the screwdriver, battery charger and power cord for any signs of damage. 2. Plug the micro USB end of the charging cable into the charging port (Fig.

  • Page 11: Know Your Cordless Screwdriver

    KNOW YOUR CORDLESS SCREWDRIVER UNPACKING With the help of a friend or trustworthy foe, carefully remove the screwdriver from the packaging. Do not discard the packaging until all of the parts below are accounted for. If any part is damaged or miss- ing, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@ wenproducts.com.

  • Page 12: Operation

    OPERATION WARNING: Do not plug in or turn on the tool until it is fully assembled according to the instructions. Failure to follow the safety instructions may result in serious personal injury. LOCKING THE POWER SWITCH Fig. 2 Before installing bits or making any adjustments, make sure to lock the power switch in the center position to prevent acci- dental starting.
  • Page 13 OPERATION 1. For clockwise rotation, push the switch to the right (Fig. 5). Fig. 5 2. For counterclockwise rotation, push the switch to the left (Fig. 5). CHARGING INDICATOR LIGHT The light below the charging port (Fig. 6) on the screwdriver indicates the battery’s charging status.

  • Page 14: Maintenance

    Any attempt to repair or replace electrical parts on this tool may be hazardous. Servicing of the tool must be performed by a qualified technician. When servicing, use only iden- tical WEN replacement parts. Use of other parts may be hazardous or induce product failure. ROUTINE INSPECTION Before each use, inspect the general condition of the tool.

  • Page 15: Troubleshooting Guide

    TROUBLESHOOTING GUIDE WARNING: Stop using the tool immediately if any of the following problems occur. Repairs and replacements should only be performed by an authorized technician. For any questions, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@ wenproducts.com.

  • Page 16: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST EXPLODED VIEW & PARTS LIST...
  • Page 17 EXPLODED VIEW & PARTS LIST EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. 49140-001 Gearbox 49140-007 Torque Spring 49140-001.1 Gearbox Cover 49140-008 Lock Button 49140-001.2 Output Shaft 49140-009 Motor 49140-001.3 Washer, 10.5×6.5 49140-010 Front Housing, Right 49140-001.4...

  • Page 18: Warranty Statement

    (2) years from date of purchase. Ninety days for all WEN products if the tool is used for professional or commercial use. SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Limited Warranty and, to the...
  • Page 19 NOTES...
  • Page 20 THANKS FOR REMEMBERING...
