Operator's Manual
T2212 PRINTER PERFORATOR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T2212 and is the answer not in the manual?

Questions and answers

Related Manuals for TE Connectivity T2212

Summary of Contents for TE Connectivity T2212

  • Page 1 Operator's Manual T2212 PRINTER PERFORATOR...
  • Page 2 Doc. # 412-121039 revision 1 Copyright This documentation as well as translation hereof are property of TE Connectivity (TE). The replication, conversion, duplication or divulgement of the whole manual or parts of it for other intentions than its original intended purpose demands the previous written authorization by TE Connectivity.

  • Page 3: Table Of Contents

    Table of Contents Introduction ..................4 Instructions ..................4 Intended Use ...................5 Safety Instructions ................6 Environment ..................6 Technical Data .................7 Mounting ..................8 Removing the Tear-off Plate ............8 Mounting the Perforator ..............9 Operation ..................10 Loading Material ................10 Reference to the Programming ............11 Standard Operation ...............12 Printer Configuration ..............13 Cleaning and Replacing the Blades ...........15...

  • Page 4: Introduction

    Introduction 1.1 Instructions Important information and instructions in this documentation are designated as follows: Danger! Draws your attention to an exceptionally grave, impending danger to your health or life. Warning! Indicates a hazardous situation that could lead to injuries or material damage.

  • Page 5: Intended Use

    1.2 Intended Use • The device is intended exclusively as an option for the T2212 printers for perforating suitable materials that have been approved by TE Connectivity. Any other use or use going beyond this shall be regarded as improper use.

  • Page 6: Safety Instructions

    Introduction 1.3 Safety Instructions • Disconnect the printer from the electrical outlet before mounting or removing the perforator. • The perforator may only be operated when it is mounted on the printer. • Risk of injury, particularly during maintenance, the perforator blades are sharp.

  • Page 7: Technical Data

    Introduction 1.5 Technical Data Perforator for printer type T2212 PRINTER Perforating Web distance Web width Material Width ≤ 45 Weight cardboard g/m² 60 - 240 Thickness 0.05 - 1.1 Cutting length ≥ 10 Cut frequency 1/min ≤ 200 Power Supply...

  • Page 8: Mounting

    Mounting 2.1 Removing the Tear-off Plate Before mounting the perforator the tear-off plate mounted on the printer must be removed. Figure 1 Removing the tear-off plate  Gently pull the Tear off plate forward (1), pull the axles (2) of the tear-off plate out of the holders (3) and remove the tear-off plate.

  • Page 9: Mounting The Perforator

    Mounting 2.2 Mounting the Perforator Figure 2 Mounting the perforator 1. Put snap arm (2) of the perforator (5) into the guide (1). 2. Push the axles (3) into the holders (4). 3. Gently push the perforator unit forward (5) so that it snaps onto the printer.

  • Page 10: Operation

    Operation 3.1 Loading Material  Gently pull the perforator unit forward as shown in Figure 3,  Insert labels or continuous tube between the Printhead and drive roller, so that the front edge reaches through the perforator unit. Figure 3 Guiding labels and tube into the perforator unit ...

  • Page 11: Standard Operation

    Operation 3.2 Standard Operation  Switch on the printer. The perforator performs a synchronization action. Note! To operate the perforator with continuous material in the printer menu Setup - > Labels - > Label sensor the setting Continuous media has to be selected.
  • Page 12 Printer Configuration Note! The values of the setup are basic settings for the current printer/ perforator combination. After changing the perforator or printer a re-adjustment may be necessary. Changes required for print jobs should be made in the label printing software. The offset values from setup and software are added together for execution.

  • Page 13: Printer Configuration

    Printer Configuration Backfeed  Start menu.  Select Setup > Printing. Parameter Meaning Default Method for backfeeding the label medium. Backfeed smart Backfeeding is necessary in the cutting and peel-off modes since a label is pushed out passed the front edge of the next label above the print line when peeling off/cutting.

  • Page 14: Cleaning And Replacing The Blades

    Cleaning and Replacing the Blades Warning!  Disconnect the printer from the electrical outlet. Warning! Risk of injury. The perforator blades are sharp. Notice! When cutting through the label material instead of the label gap remains of adhesive may accumulate on the blades. If operating in backfeed mode, such remains of adhesive may be deposited on the drive roller as well.
  • Page 15 Cleaning and Replacing the Blades Figure 5 Replacing the Blades Figure 6 Springs 4. If the blades are very dirty with residues of adhesive or if they are worn, change blades:  Turn the shaft (6) clockwise using a torx wrench TX10 until the gear racks (7) cannot engage anymore.

  • Page 16: Licenses

    Directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment EU Declaration of Conformity Please follow the link below, to download the latest T2212 Perforator, EU Declaration of Conformity, TE document, T2212-Perforator-CE-EU-C-of- C. EU Declaration of Conformity ...
