Samsung AV-R620 Instruction Manual

Digital surround av receiver system
Hide thumbs

Advertisement

Quick Links

Digital Surround
AV Receiver System
HT-AS620
AV-R620
THIS APPLIANCE IS MANUFACTURED BY:
Instruction Manual
AH68-02012B

Advertisement

loading

  Related Manuals for Samsung AV-R620

  Summary of Contents for Samsung AV-R620

  • Page 1 Digital Surround AV Receiver System HT-AS620 AV-R620 THIS APPLIANCE IS MANUFACTURED BY: Instruction Manual AH68-02012B...
  • Page 2: Safety Warnings

    Safety Warnings This symbol indicates that dangerous voltage which CAUTION can cause electric shock is present inside this unit. RISK OF ELECTRIC SHOCK. DO NOT OPEN This symbol alerts you to important operating and maintenance instructions accompanying the unit. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO WARNING: To reduce the risk of fire or electric shock, do not NOT REMOVE REAR COVER.
  • Page 3: Table Of Contents

    Features Digital AV Receiver This product is a pure digital AV receiver that performs digital signal processing to minimize signal distortion and loss. Dolby Pro Logic II Dolby Pro Logic II is a new form of multi-channel audio signal decoding technology that improves upon existing Dolby Pro Logic. DTS (Digital Theater Systems) DTS play backs 5.1 channel sound with less compression than Dolby Digital for richer sound.
  • Page 4: Description

    Description [ Front Panel ] INPUT MODE button POWER STANDBY Indicator POWER button HEADPHONE Jack [ Display ] LIVE SURROUND INDICATOR INDICATOR DOLBY SPEAKER INDICATOR L.PCM INDICATOR INDICATOR DOLBY DIGITAL INDICATOR DOLBY PRO LOGIC II RADIO STEREO INDICATOR INDICATOR RADIO BROADCASTING RECEIVING INDICATOR FRONT DISPLAY [ Rear Panel ]...
  • Page 5: Remote Control

    Description [ Remote Control ] TV button AMP button POWER button NUMBER(0~9) buttons SLEEP button MO/ST button TUNER button EXTERNAL DEVICE PLAYBACK button MUTE button VOLUME CONTROL button MENU button CURSOR/ENTER button SUBWOOFER button INFO button STEREO button SPK DISTANCE button SPK LEVEL button SFE MODE button Insert Remote Batteries...
  • Page 6: Connecting The Speakers

    Connecting the Speakers Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Position of AV Receiver Surround Speakers • Place AV Receiver on a dedicated stand or rack. • Place these speakers behind your listening position. •...
  • Page 7: Connecting External Components

    Connecting External Components Connecting Video Component Before moving or installing the product, be sure to turn off the power and disconnect the power cord. DVD Player Video Projector • Disconnect the power plug from the outlet if you will not use this unit for a long period of time. •...
  • Page 8: Connecting The Fm And Am Antennas

    Connecting External Components Connecting Audio Component Before moving or installing the product, be sure to turn off the power and disconnect the power cord. CD Player Connecting the FM and AM Antennas If AM reception is poor, connect an outdoor AM antenna(not supplied). FM Antenna (supplied) FM antenna connection AM antenna connection...
  • Page 9: Before Using The Av Receiver

    Before Using the AV Receiver Turning On/Off REMOTE CONTROL Press the POWER button of the remote control. • This unit will be turned on or set to Standby mode. MAIN UNIT Connect the power plug to the outlet. Press the POWER button of the main unit. This unit will be turned on or set to Standby mode.
  • Page 10: Selecting Digital/Analog Input

    Selecting Digital/Analog Input You can listen to sound in 2 Channel analog or Dolby Digital 5.1 Channel using this unit. REMOTE CONTROL For DVD Function Follow steps 1-4 in DVD setup on page 26 before selecting the DVD Input Mode. Press the INPUT MODE DIGITAL button.
  • Page 11: Setting The Speaker Mode

    Setting the Speaker Mode Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Frequency response from the speaker will be adjusted according to your speaker configuration and whether certain speakers are used or not. REMOTE CONTROL Press SPK SELECT button to select the speaker you want.
  • Page 12: Setting The Speaker Listening Distance

    Setting the Speaker Listening Distance REMOTE CONTROL Press the SPK DISTANCE button to select the speaker you want. Each time you press this button, F.L ➝ CEN ➝ F.R ➝ S.R ➝ S.L ➝ S.W • ➝ DIST OFF will be selected in turn. Press …†...
  • Page 13: Setting Drc (Dynamic Range Compression)

    Digital Input Setup You must set the digital input for a DVD or CD player to either Optical or Coaxial depending on which Digital input you have your player connected to. MAIN UNIT DVD SETUP Press SETUP button. “SETUP MODE” appears on the display and enters into Setup Mode. •...
  • Page 14: Test Tone

    Test Tone Use test tone to check the speaker connection status or level. To Automatically Output Test Tone REMOTE CONTROL Press TEST TONE button. Test signal will be automatically output as follows; F.L ➝ CEN ➝ F.R ➝ S.R • ➝...
  • Page 15: Setting Speaker Level

    Setting Speaker Level You can set the balance and level of speakers Remote Control Press SPK LEVEL button to select the speaker you want. Each time you press this button, F.L ➝ CEN ➝ F.R ➝ S.R ➝ S.L ➝ S.W ➝ •...
  • Page 16: Dolby Pro Logic Ll Mode

    Dolby Pro Logic ll Mode This mode provides 5.1 channel sound from 2 channel sources REMOTE CONTROL Press MODE button. Each time you press this button, CINEMA ➝ MATRIX ➝ GAME • ➝ PROLOGIC ➝ MUSIC will be selected in turn. To Exit Setup Mode Wait for about 5 seconds.
  • Page 17: Dolby Pro Logic Ll Effect

    Dolby Pro Logic ll Effect This function works only in Dolby PRO LOGIC II MUSIC Mode. REMOTE CONTROL Press MODE button to select ‘MUSIC’ Mode. Press EFFECT button. Each time you press this button, C-WIDTH ➝ DIMENSION ➝ PANORAMA • will be selected in turn.
  • Page 18: Sfe Mode

    SFE Mode The SFE (Sound Field Effect) function uses 7 different DSP sound field effects to digitally simulate actual music environments such as concert halls or movie theaters. REMOTE CONTROL Press SFE MODE button. Each time you press this button, HALL ➝ THEATER ➝ ARENA ➝ CLUB ➝ •...
  • Page 19: Stereo Mode

    Stereo Mode You can select this mode when listening to sound through the Front Left and Right speakers and subwoofer. REMOTE CONTROL MAIN UNIT Press STEREO button. Press SURROUND button to select ‘STEREO’. Each time you press this button, DPL ll ➝ SFE ➝ STEREO •...
  • Page 20: Listening To Radio

    Listening to Radio You can listen to the chosen band (FM, AM) by using either automatic or manual tuning. REMOTE CONTROL MAIN UNIT Press FUNCTION button to select Press TUNER button. FM or AM. Each time you press this button, FM ➝ AM will be repetitively •...
  • Page 21: About Rds Broadcasting

    About RDS broadcasting Using the RDS (Radio Data System) to receive FM stations RDS allows FM stations to send an additional signal along with their regular program signals. For example,the stations send their station names,as well as information about what type of program they broadcast, such as sports or music,etc.
  • Page 22: Convenient Functions

    Convenient Functions Sleep Timer Function You can set the time that this unit will shut itself off. REMOTE CONTROL Press the SLEEP button. SLEEP : OFF ➝ 15 ➝ 30 ➝ 45 ➝ 60 ➝ 90 ➝ 120MIN will be selected in turn. •...
  • Page 23: Operating Your Vcr (Dvd) With The Remote Control

    The remote control may not work on some brands of TVs. Also, some operations • may not be possible depending on your brand of TV. The remote control will work with Samsung TVs by default. • TV Brand Code List...
  • Page 24 The remote control may not work on some brands of DVD (VCR). • Also, some operations may not be possible depending on your brand of DVD (VCR). The remote control will work with Samsung DVDs (VCRs) by default. • VCR Brand Code List Brand...
  • Page 25: Before Calling For Service

    Before Calling for Service Check Symptom Can't turn it on. Is the power code plugged into the outlet? • It does not work when the Is there static electricity in the air? • button is pressed. Are the speakers and external •...
  • Page 26: Specifications

    Specifications Power Supply Standby Power Consumption Power Consumption GENERAL Weight Dimensions (W x H x D) Operating Temperature Range Operating Humidity Range Frequency Response Usable Sensitivity S/N Ratio FM TUNER Distortion Stereo Separation Tuner Output Level Frequency Response S/N Ratio AM TUNER Usable Sensitivity Distortion...
  • Page 27 Contact SAMSUNG WORLD WIDE f you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.

This manual is also suitable for:

Ht-as620
