MINATO MODEL400 Series Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATION MANUAL
MODEL400 SERIES PROGRAMMER
2010/06
M400-020A-K1
2010/11
M400-020A-K2
2011/03
M400-020A-K3
2013/10
M400-020A-K4
2015/07
M400-020A-K5
2017/06
M400-020A-K5
2017/09
M400-020A-K6
2018/05
M400-020A-K6
2018/10
M400-020A-K6
Revision
Rev.1.0
Rev.2.0
Rev.3.0
Rev.4.0
Rev.5.0
Rev.5.1
Rev.6.0
Rev.6.1
Rev.6.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MODEL400 Series and is the answer not in the manual?

Questions and answers

Related Manuals for MINATO MODEL400 Series

Summary of Contents for MINATO MODEL400 Series

  • Page 1 OPERATION MANUAL MODEL400 SERIES PROGRAMMER Revision 2010/06 M400-020A-K1 Rev.1.0 2010/11 M400-020A-K2 Rev.2.0 2011/03 M400-020A-K3 Rev.3.0 2013/10 M400-020A-K4 Rev.4.0 2015/07 M400-020A-K5 Rev.5.0 2017/06 M400-020A-K5 Rev.5.1 2017/09 M400-020A-K6 Rev.6.0 2018/05 M400-020A-K6 Rev.6.1 2018/10 M400-020A-K6 Rev.6.2...

  • Page 2: Preview

    Preview Dear Customer, We are pleasure to see you purchasing Minato Gang Programmer MODEL400 Series. This manual explains how to use MODEL400 Series correctly, so please read this manual before operation. Register for Warranty MINATO ADVANCED TECHNOLOGIES will implement support for our products, please register all the information on our web.

  • Page 3: Pc Requirements For Control M400

    PC Requirements for control M400 PC Requirements for control M400 OS requirements  Windows XP （SP3 higher）  Windows Vista  Windows 7 ( 32bit, 64bit )  Windows 8, 8.1 ( 32bit, 64bit ) Recommended PC requirements  CPU Pentium4 1GHz or Higher ...

  • Page 4: Simple Guide

    Simple Guide Simple Guide Preview ・・・・・・ 26 Installation  Software ・・・・・・ 26  Hardware ・・・・・・ 28 ・・・・・・ 31 Notice for first time connecting to PC Hardware Software ・・・3 ・・・35 PC Requirements Outline ・・・15  Outline ・・・35 Outline  Outline  Start ・・・36 ...

  • Page 5: Model400 Series Packing List

    ※The MODULE number for each MODEL (MODEL404, 404e+ / 1pcs, MODEL408, 408e+ / 2pcs , MODEL416, 416e+ / 4pcs )  Power Cable  USB Cable  CD (MODEL400 Series control software, USB driver, Operation manual ) MODEL404, 404e+ MODEL408, 408e+ MODEL416, 416e+ M400-020A-K6...

  • Page 6: Warranty Terms

    Warranty Terms Warranty Terms Minato gives a guarantee on programmer for one-year from the date of purchase (Just for customer who has registered their programmer). The warranty does not apply to products on some conditions, so please read below contents.
  • Page 7 Warranty Terms 3. Please keep the box provided by Minato which can be reused while transportation for repair. Please make sure the package is strong, otherwise you should pay for the damage of programmer. 4. Minato will pay for the transportation fee after repairing.

  • Page 8: Maintainance Of M400 Series

    About repair, calibration and version up Minato does not provide on-the-spot service no matter free charge or not. And we can not provide spare programmer, please understand. Customer should pay for the transportation fee from you to minato for repair, calibration and version up. Minato will bear the transportation cost for return.

  • Page 9: Safety Precaution

    Safety Precaution Safety Precaution Warning and Cautions This operation manual includes safety precautions for safely use M400 Series programmer. To prevent the operator or others people from injury and property damage, please following below pictographs to operate. Before reading this manual, fully understand these pictographs and the meanings. Keep this manual at hand and refer to it while necessary.
  • Page 10 If the programmer is dropped or shocked, please remove the power plug immediately. Otherwise it may cause a fire or electric shock due to short-circuit. Consult with Minato or distributor. Unplug Power Cord If any liquid or foreign matter enters the programmer, please remove the power plug immediately.
  • Page 11 Safety Precaution Cautions The operator should fully understand the manual before operation. Miss operation may damage the programmer or ICs. Compulsion Before touching the programmer, please touch a nearby large metal to remove static electricity from your body. Static electricity may damage the programmer or ICs. Compulsion Please clean the surfaces, the socket and the air filter screen of programmer.
  • Page 12 Safety Precaution Caution for accessories Standard power cable complies with Japanese regulation. If you will use this programmer in others country, please follow the local safety Standard. Compulsion M400-020A-K6...

  • Page 13: Table Of Contents

    Module Position ........................22 ABOUT VARIOUS ADAPTERS ....................24 INSTALLATION ........................26 Installation of Software ......................26 Installation for Hardware ....................... 28 NOTICE FOR FIRST TIME CONNECTING TO PC ..............31 MODEL400 SERIES CONTROL SOFTWARE ( UNIVERSAL CONTROL PROGRAM ) ..35 M400-020A-K6...
  • Page 14 Contents Outline ............................ 35 Start Running the Universal Control Program ..............36 Description of the main screen ....................38 BASIC OPERATION ......................... 47 Select Device ........................... 48 COPY ............................51 ERASE ............................ 53 BLANK ............................ 55 PROGRAM ..........................57 VERIFY ........................... 59 CONT ............................

  • Page 15: Outline

    Outline Outline Outline M400 Series are Gang Programmer which can be controlled by PC (windows OS) software through USB Port and supports large capacity devices. M400 Series are equipped with 32GByte（256Gbit）SD Memory or 64GByte（512Gbit）microSD Memory and provide high performance for mass programming . Features ...

  • Page 16: Model400 Series Element And Function

    M400 Series Element and Function MODEL400 Series Element and Function In order to operate MODEL400 Series properly, please understand the function of each part and its name.The details are described in following pages. When used, MODEL 400 series of products shall be accompanied by dedicated control software and socket unit.

  • Page 17: Module Position

    Module Position Module Position Example) MODEL404 STATUS START SOCKET Number（#1～#4） Module Connector Module SOCKET Number Each SOCKET has a corresponding number. And we use “#+number” to express it in this manual. Example) SOCKET 2 is described as ”#2” M400-020A-K6...
  • Page 18 Module Position Module Connector Module Interface Connector Socket LED（Indicating PASS/FAIL） Different color means the operating result. PASS Green FAIL STATUS START M400-020A-K6...
  • Page 19 Rear Panel Rear Panel USB Connector Air Vent REV.No MODEL 404 Serial Number Power Switch Revision Number Power Connector Power Connector AC power supply connector with (3A)FUSE. Power Switch USB Connector Air vent Air vent is designed for the external air sucked for cooling the interior of MODEL 400 series.

  • Page 20: Optional Items

    Optional Items Optional Items MODEL 400 series of products are supplied with standard socket unit. In addition to standard socket unit, user may optionally use the following socket units and adapters. Please make sure the socket unit and adapter are matched with the device used. M400-020A-K6...

  • Page 21: About Module

    There are various Modules. Here just introduce several typical modules and describe how to install them on M400 Series. For others Module installation, please contact with Minato or distributor. ※Never fail to mount socket unit in the body. No operation would be activated even if the product is mounted when the power supply for body is turned on.

  • Page 22: Module Position

    About Module Module Position Describe the direction of Module installation. Lock lever IC Socket Gap of PCB (Open / Close) PASS / FAIL LED Lock lever (open/close) Before inserting device, push up the lever (open) After inserting device, push down the lever (close) IC SOCKET Most modules (TSOP, BGA, etc) except DIP can be opened or closed by pressing the socket.
  • Page 23 About Module Direction of Module installation In the case of socket unit with locking rod, the locking rod shall be mounted at a neighboring point. As for socket unit with base plate notch, the notch shall be mounted at a neighboring point.

  • Page 24: About Various Adapters

    About Various Adapters About Various Adapters This chapter describes adapters for M400 Series 1. Just adapters which have been supported by M400 Series. 2. Some others adapter can be supported by M400 Series after version up. (Not all) 3. Due to too many types adapters, we call them “Various Adapters” Notice! Module SU400-48DP/3v is necessary for adapters.
  • Page 25 About Installation (Software and Hardware) ※ Matters needing attention when connecting MODEL400 series of products to PC for the first time （Important ） M400-020A-K6...

  • Page 26: Installation

    Installation Installation The CD-ROM contains M400 Series Control software (Universal Control Program), USB drive and operation manual. In order to control the programmer by software, you must correctly install the USB driver and software first. ※The software must be installed before connecting the programmer with PC. Installation of Software Please insert the CD-ROM to install below software.
  • Page 27 Installation Creating a short-cut on the desktop after selecting This screen means the installation has been fininshed. Please click（finish） ※ Installing the USB_driver.exe by the same method. M400-020A-K6...

  • Page 28: Installation For Hardware

    Installation Installation for Hardware Before start the Universal Control Program, please connecting M400 Series to PC by USB cable. Windows will detect new hardware, please follow below method to install the driver. M400 Series will be detected by windows and installation will start automatically. Please insert the CD-ROM.
  • Page 29 Installation Wizard start searching programmer and install driver automatically. Confirming the installation. M400-020A-K6...
  • Page 30 Installation After successfully installing you will see following window: Click “Finish” button to finish the setup. ※ Notice ※ In addition, MODEL 400 series of products will detect the new hardware in the connected unit (COM port), and programmers M416 and M408 will perform hardware installation for 4 times and 2 times, respectively.

  • Page 31: Notice For First Time Connecting To Pc

    Notice for first time connecting to PC Notice for first time connecting to PC After installing the hardware driver Please perform the following operations after hardware installation. Where the following operation is not performed, PC would be unable to identify MODEL400 series of products.
  • Page 32 Notice for first time connecting to PC ④ [ Start ] → [ Setting ] → [ Control Panel ] → [ System ] → [ Hardware ] → [ Device Manager ] If you can find the the Model of M400 Series, it means the Programmer has been recognized and please remember the USB port.
  • Page 33 Notice for first time connecting to PC ②”usbser.sys” will be found and copy this file to below folder. C:/Windows/system32/drivers or D:/Windows/system32/drivers ③ Power on both the M400 Series and the PC [ Start ] → [Setting] → [ Control Panel ] → →...
  • Page 34 M400 Series Control Software (Universal Control Program) Operation Manual This chapter explains how to use this Universal Control Program of M400 Series. This Control Software will be updated without giving notice due to improvement. Any effects will be fixed by new software. M400-020A-K6...

  • Page 35: Model400 Series Control Software ( Universal Control Program )

    MODEL400 Series Control Software (Universal Control Program) MODEL400 Series Control Software ( Universal Control Program ) Outline M400 Series Control Software is suitable for MODEL404, MODEL408, MODEL416. Main features: ① MODEL404, MODEL408, MODEL416 can be controlled by the same software.

  • Page 36: Start Running The Universal Control Program

    MODEL400 Series Control Software (Universal Control Program) Start Running the Universal Control Program After installation was finished, please double click the icon on the desktop. And below dialog box will display. [ Connect a programmer Dialog box ] Automatically detect and connect the programmer (Online mode) On the dialog box [Connect a programmer], choose [Connect] and click [Select].
  • Page 37 MODEL400 Series Control Software (Universal Control Program) Demo mode for MODEL 416 On the dialog box [Connect a programmer], choose [Model 416] and click [Select], the control software will be forced to MODEL 416 Demo mode and [DEMO] will be showed on the main screen of software.

  • Page 38: Description Of The Main Screen

    MODEL400 Series Control Software (Universal Control Program) Description of the main screen Here will introduce the function of the main screen and the sample is MODEL404(It’s the same for MODEL408 and MODEL416 except the programmer’s Model.） Description of the main screen（MODEL404 Main Screen）...
  • Page 39 MODEL400 Series Control Software (Universal Control Program) ② Menu bar There are below 7 menus, [File], [Edit], [Programmer], [Device], [Operation mode] [View], [Help]. Each menu contains many functions for operation, example you can select IC by click [Select device...] under [Device] menu.
  • Page 40 MODEL400 Series Control Software (Universal Control Program) [View]  「Toolbar」  「Status Bar」  「Function progress bar」(Special：Show the progress at the time point when error occurs)  「Contact check NG mark」(Show/hide error mark in the case of Contact error)  「Handler NG code」(For Auto Handler：OFF state normally) ...
  • Page 41 MODEL400 Series Control Software (Universal Control Program) ③ Tool bar 17 tools were divided to 6 groups [Project], [Data], [Device], [Operation], [Connection], [Version]. [1] Project Load Project Open the Project file which already exists. Save Project Save all the setting to a new Project file.
  • Page 42 MODEL400 Series Control Software (Universal Control Program) VERIFY Compare the data of IC with Buffer. PROG Write the data of Buffer to IC. ERASE Clear all the contents of IC CONT It’s a continuous function of ERASE, PROG and VERIFY.
  • Page 43 MODEL400 Series Control Software (Universal Control Program) ⑤ Data File Show the file name, size, CheckSUM and CRC. (CheckSUM and CRC are calculated according to the buffer not file, so they will be changed after loading another file or editing the buffer) ⑥...
  • Page 44 MODEL400 Series Control Software (Universal Control Program) MODEL408 is showed 2 sites (8 Sockets). MODEL416 is showed 4 sites (16 Sockets). The Progress bar shows the status of every operation. Example：while you run PROG, it will show PROGRAMMING 0→100%, VERIFYING 0→100%.
  • Page 45 MODEL400 Series Control Software (Universal Control Program) ⑩ Control Panel Additionally, the in-service operation mode will be displayed in ONLINE state during operating process, and the normal display status would be restored upon the completion of operation. Running You can confirm whether it is running by not only the “Programmer state” but also the “Socket status”.
  • Page 46 Basic Operation This chapter will describe below operatios.  Power Setting  Selcet device  Copy  Erase  Blank check  Program  Verify  Cont  Contact and ID check For M400 Series you must use the special control software to operate. Here just describe the operation of M404 (It's the same for M408 and M416 except the programmer model.) M400-020A-K6...

  • Page 47: Basic Operation

    Basic Operation Basic Operation Power setting Here will describe the sequence of power on. You should avoid the noise caused by other machine like electric generator and welding machine. ※ Notice 1. Making sure to put M400 Series at a level palce, no shocking 2.

  • Page 48: Select Device

    Basic Operation Select Device Click [ Select device ] to choose target IC. You can select device by choosing [Device] → [Select device] or click below button on the tool bar. The window for selecting device Tab ( ① All ② Only selected type ③ Only selected manufacturer) Title bar IC list Key in the IC P/N...
  • Page 49 Basic Operation Confirm the device While you clicking the device, all the informaitons will be displayed for your confirming. All the informations of the device you have selected are displayed. Clicking [OK] button to confirm your selected device and then the device will be called out and all the settings are updated.
  • Page 50 Basic Operation Click the tab of [Only selected type], you can more easily find the device by select the [Type] and [Sub type], because just the type you have defined will be listed. (example： Set [Type] as”Flash”,and [Sub type] ”512M-bit (x16)”, then just 512Mbit Flash will be listed) If there is no device being displayed, it means this type has not been supported.

  • Page 51: Copy

    Basic Operation COPY Using the COPY button to copy data from IC to buffer of M400 Series. Notice before COPY！ 1. Please calculate the checksum before copy to confirm whether it is correct. 2. Just #1Socket can be used for COPY and make sure no IC in others Socket. 3.
  • Page 52 Basic Operation Flow chart of COPY Select device Put IC into SOCKET#1 Push down the Lock Lever COPY VERIFY PASS/FAIL LED Supplement To modify the setting in "Device operation option", skip the VERIFY after COPY. When Pick up IC doing so, please be sure to perform data validation using SUM and CRC32.

  • Page 53: Erase

    Basic Operation ERASE For EEPROM and FLASH devices, the data can be erased by click ERASE button. Notice before ERASE ! The device which is failed by contact checking or ID checking must be removed from the module before ERASE, otherwise may damage. The operation Sequence for ERASE Example) For M404 1.
  • Page 54 Basic Operation Flow chart of ERASE Select device Put IC into Socket Push down the Lock Lever Empty socket is in existence. All sockets are connected with device. ERASE Fail Stop Fail Socket is detected through BLANK connection inspection. PASS/FAIL LED Supplement Pick up IC To modify the setting in "Device operation...

  • Page 55: Blank

    Basic Operation BLANK Click BLANK button to confirm whether the content of IC is empty. Notice before BLANK ! The device which is failed by contact checking or ID checking must be removed from the module before blank check, otherwise maybe be damaged. The operation Sequence for BLANK Example) For M404 1.
  • Page 56 Basic Operation Flow chart of BLANK Select device. Put IC into Socket. Push down the Lock Lever. Empty socket is in existence. All sockets are connected with device. BLANK Fail Stop Fail Socket is detected through PASS/FAIL LED connection inspection. Pick up IC M400-020A-K6...

  • Page 57: Program

    Basic Operation PROGRAM Write the data from buffer to IC. Notice before PROGRAM ! The device which is failed by contact checking or ID checking must be removed from the module before program function, otherwise may be damaged. The operation Sequence for PROGRAM Example) For M404 1.
  • Page 58 Basic Operation Flow chart of PROGRAM Select device. Put IC into Socket. Push down the Lock Lever. Empty socket is in existence. All sockets are connected with device. BLANK Fail Stop Fail Socket is detected through ERASE connection inspection. BLANK All the devices are blank.

  • Page 59: Verify

    Basic Operation VERIFY Compare the data between IC and buffer of M400 Series. Notice before VERIFY ! The device which is failed by contact checking or ID checking must be removed from the module before verify function, otherwise maybe be damaged. The operation Sequence for VERIFY Example) For M404 1.
  • Page 60 Basic Operation Flow chart of VERIFY Select device. Put IC into Socket. Push down the Lock Lever. Empty socket is in existence. All sockets are connected with device. VERIFY Fail Stop Fail Socket is detected through PASS/FAIL LED connection inspection. Pick up IC M400-020A-K6...

  • Page 61: Cont

    Basic Operation CONT After clicking CONT button, programmer will carry out ERASE -> BLANK -> PROGRAM -> VERIFY automatically. The operation flow is different between EEPROM & Flash and EPROM which can not be erased electrically. Notice before CONT ! The device which is failed by contact checking or ID checking must be removed from the module before cont function, otherwise may be damaged.
  • Page 62 Basic Operation Flow chart of CONT（For FLASH/EEPROM） Select device. Put IC into Socket. Push down the Lock Lever. Empty socket is in existence. All sockets are connected with device. BLANK Fail Stop Fail Socket is detected through ERASE connection inspection. BLANK All the devices are blank.
  • Page 63 Basic Operation Flow chart of CONT (for EPROM） Select device. Put IC into Socket. Push down the Lock Lever. Empty socket is in existence. All sockets are connected with device. BLANK Fail Stop Fail Socket is detected through PROGRAM connection inspection. VERIFY PASS/FAIL LED Pick up IC...

  • Page 64: Contact Check, Id Check

    Basic Operation Contact check, ID check Contact check Contact check is to detect whether the position (direction) of device is correct or the device is not damaged ,and this function is carried out before others operation. Since there are various specifications of devices, some devices including microcontroller does not allow carrying out a contact check, we will define it according to IC and there is no menu setting or button for Contact check.

  • Page 65: Protect

    Basic Operation Protect The case, selected device has the lock-bit / sector-protect etc..., is able to set by [Device operation options]. ・How to use PROTECT [Device operation options] is opened by clicked [Device] -> [Operation option...] or on toolbar. And, Display on the [Device operation options] window. 1.Protection checkbox 2.Setting Protection Edtor 3.Select Button...

  • Page 66: Function Description

    Function Description Function Description This chapter will describe below functions.  Load file  Save buffer  Buffer editor (Edit)  Project management  Lot management  Status of operation  Setting of programmer  Operation of programmer The performance of M400 Series is excellent due to below functions. Here will introduce the operation and functions of software for M404.

  • Page 67: Load File

    Function Description Load file You must edit the data of PC and programmer before operation and device must be selected before loading data. Load file Choose menu [File] -> [Load file to buffer] or click [Load] button , then below dialog box will be displayed.
  • Page 68 Function Description ① Select file name Set the file name to [File name] Box by clicking [Browse] button. ※ Default folder The folder which you choosed last time will be set as default. ② Format type Indicate the file format which you will load to buffer by drop-down list of [Format type].
  • Page 69 [Yes]/[No]. For SD buffer Memory, the data file can be saved as history and also can be cleared. So there will be 2 kinds message: ※ Minato has no warranty for the data be saved in BufferMemory. M400-020A-K6...
  • Page 70 Function Description 2 kinds message about Data File Load The file is not in the history(not ever be used before). The message means this file did not been used before and you want to transfer the data to programmer, please click [yes] button. This message will also be displayed while you want to clear the history.

  • Page 71: Save Buffer

    Function Description Save buffer The data in buffer editor or copyed from IC can be saved to PC as a file. Choose menu [File] -> [Save buffer to file] or click [Save] button ,then the dialog box will be displayed as below. Click [Browse] to set the file name and folder to save.
  • Page 72 Function Description Save buffer Click [Save] button to save file and the （SUM／CRC32） value will be updated on the main screen. A message will be displayed for whether transfering the data to programmer [Yes]/[No]. And there will be 2 kinds message about the history.(Refer to Load file) Close the Save buffer window Click [Cancel] button close or to this window without change of the data file.

  • Page 73: Buffer Editor (Edit)

    Function Description Buffer Editor (Edit) By clicking Editor button you can choose various tool including Intialize buffer, find text and edit, etc. Menu [Function] [View] [Help] Toolbar [Initialize] [Edit] [Find・Replace] [Jump] [Mode] [Check SUM] [Version] Notice about data transfer Buffer Editor is a tool of Buffer Memory operation. During actual operation of device, it's essential to transfer the data to the body of programmer upon the completion of buffer edition.
  • Page 74 Function Description ① Menu bar There are 3 menus about Buffer Editor: [Function], [View], [Help] and each menu are defined as group. [Function] Contains all the related tools [View] To change the Toolbar, status bar, Byte&Word displaying status.(Toolbar can not be changed) View as Byte Using byte as the unit to view the content of buffer by choosing [View] ->...
  • Page 75 Function Description Using indicated data to fill the Buffer Memory of block. [2] Edit Copy block Copy data from one block to another block. Move block Cut data of Buffer Memory from one block to another block. Swap data in block Swap the data of Buffer Memory.
  • Page 76 Function Description [7] Version About Indicate the version and copyright. ③ Data area ( Editor Window Display the contents of BufferMemroy and the default unit is Byte. There are at most 3 Tabs according to IC type. Clicking Tab to switch and the data of each Tab is independent.
  • Page 77 Function Description data] or clicking [RandomData] button Then click [Yes] button to continue this operation and all the data will be replaced with Random Data. Click [No] button to cancel this operation. Fill block with indicated data . Initialize BufferMemroy with indicated data by choosing [Function] -> [Fill block] or clicking [Fill block] .
  • Page 78 Function Description Copy Copy data from one block to a indicated address. Choose [Function] -> [Copy block] or click[Copy block] button and the operation will start by clicking [OK] button. ① ② ① Block area Indicate the address at [Block start] and [Block end] box. ②...
  • Page 79 Function Description Move Cut Buffer data from one block to another block by choosing [Function] -> [Move block] or clicking. [Move block] button and data will be moved by clicking [OK] button. ① ② The block area and address should be indicated before operation and the block data will be replaced by FF.
  • Page 80 Function Description SWAP Swap buffer data due to different request of byte order. Choosing [Function] -> [Swap data in block] or clicking [SwapData] button .and the operation will start by clicking [OK] button. ① ② ① Indicate the block area at [Block start] and [Block end] box. ②...
  • Page 81 Function Description Find text Search data by choosing [Function] -> [Find text] or clicking [Find text] button and it will start to find by clicking [Find] button. ① ② You can indicate the text (Hex or ASCII) to find, direction and origin. ①...
  • Page 82 Function Description Replace text Search some data and replace them by indicated data. Choosing [Function] -> [Replace text] or clicking [Replace text] button clicking [Replace] button to replace the text. ①Find Text ②Replace text ③Direction/Origin ④ Mode ① Find text Enter retrieval data.
  • Page 83 Function Description the message reading "start next replacement?" will be displayed at the end of each round of replacement. To proceed with the replacement, click [Yes]; to stop the procedure, click [No]. All : Full replacement is to be performed without confirmation message. Close [Replace text] dialog box Click [Cancel] button to close this box without changing the buffer data.
  • Page 84 Function Description Jump Jump to a indicated address by choosing [Function] -> [Go to Address] or clicking [Go to address] button and after clicking [OK] button it will go to the indicated address. Indicate the address. Key in the address at [Current address] Box and the Unit of address should be byte. M400-020A-K6...
  • Page 85 Function Description EDIT MODE Change the Buffer Editor to Edit mode by choosing [Function] -> [Edit buffer] or clicking [Edit buffer] button The [Edit buffer] menu and button will be locked and the data at the cursor can be edited. The data should be Hex (0-9, A-F) The cursor can be moved by [↑] [↓] [←] [→] button or mouse directly and the data will be changed directly after editing without confirming message.
  • Page 86 Function Description View mode Change the Buffer Editor to view mode by choosing [Function] -> [View buffer] or clicking [View buffer] button The [View buffer] menu and button will be locked. The default mode is [view] while opening [Buffer Editor] again. M400-020A-K6...
  • Page 87 Function Description Check SUM , CRC and XOR There are 7 types about SUM or CRC.(ByteSUM、WordSUM (Little endian)、Word SUM (Big endian)、CRC16、CRC32、CRC-CCITT、XOR SUM , CRC and XOR are useful to confirm whether the data loaded to buffer or write to IC is correct. Choosing [Function] ->...
  • Page 88 Function Description After Buffer editing please pay attention to below message: “A buffer memory is being updated! Do you do data transmission?” It means whether you will update the data to programmer after edit. And the data will be saved in Editor before you load another file.

  • Page 89: Project Management

    Function Description Project Management You can save IC P/N, data and settings to a project file for M400 control software and you can reload all of them for next operation. Load Project File Load project file to software by choosing [File] -> [Load project] or clicking [Load project] button Then click [Open] button to load Project File.
  • Page 90 Function Description [Project information] dialog box ① Project file name ② Project ID ③ Note ① Project file name Key in the Project file name at [Proj file name]Box and it will be saved in the default folder.The default folder is ”C:\programmer\m404\support\data”. And the default folder will be changed as you selected last time.

  • Page 91: Lot Management

    Function Description Lot Management It’s easy to confirm the quantity and others status of operation according to Lot management and a report can be created. Lot Size Click [Lot size] button to open [lot information] dialog box. ① Lot size ②...
  • Page 92 Function Description Choose the operation mode of operation programmer from "Programmer mode" in batch management mode. ⑥ Lot Start & End [1] Lot Start Click [Lot start] button to begin and a message “Are you sure to rest statistics counters” will be displayed, accrording to you request to choose [Yes] or [No]. And except [Lot end]&[Report] button, all others item be locked.
  • Page 93 Function Description Clicking to close this dialog box. If you close this dialog box while Lot function is running, then except [Lot End] button all others item are locked while you click [Lot Size] again. Report A report will be created automatically after a Lot is finished. The data and programmer will be created in one report and different operation will be saved in the same report for same day.

  • Page 94: Operation Status

    Function Description Operation Status The counter and Progress can be checked easily.You also can check the elapsed time of operation. Count You can find the PASS, FAIL, TOTAL counter on the Progress Condition Window. And the count will be added up. Progress Condition Window ①...
  • Page 95 Function Description Select the operation mode at <Enable> bar by corresponding CheckBox. Add up the counter When the operation value selected in dialog box after the <Enable> operation is checked, the total would be displayed in both "Total" counter section and the PASS/FAIL/Total in main screen.
  • Page 96 Function Description Others information Showing on the main screen while operation is finished. While the PASS quanity exceed the LotSize, the PassBox will turn to pink automatically. And the operation still can be continued with Pink PASSBOX until the statistics is cleared. ①Turn to pink ②Progress bar ③Average elapsed time...
  • Page 97 Function Description ②Retention period ①Log file path Close [Control of a log file] dialog box Choosing [File] -> [Control of a log file] and clicking [OK] button on Control of a file dialog box to save settings and close the dialog box. M400-020A-K6...

  • Page 98: Auto Start

    Version UniversalControlProgram ・・・V2.06 MODEL400 Series Firmware ・・・V1.25 1. Mount adapter and choose device in the same way as routine operation. 2. Select operation mode. Please choose operation mode from the list of [Operation mode] in menu.
  • Page 99 Function Description 4. Once the adapter is properly mounted, the socket LED would flash red. The failure to flash red after the installation of adapter may be the result of poor contact. Please re-install the adapter. If it doesn’t work, please confirm version about “Universal Control Program”...
  • Page 100 Function Description （Flash） Please set the device. （Flash） The device has been set. If the device flashes red upon the completion of device set up, the cause may be poor contact. Please set the device up again. 7. Auto start would be performed if "red flashing" turns into "green flashing" for each site.

  • Page 101: Programmer Setting

    Programmer Setting Programmer Setting Buzzer Switch the buzzer of programmer to ON/OFF and the setting will be saved. ※ If you choose DEMO or OffLine MODE, the buzzer will not work. Open Buzzer Choosing [Programmer] -> [Buzzer] -> [ON] to open. Close Buzzer Choosing [Programmer] ->...
  • Page 102 Programmer Setting Buffer Setting of PC You also can change the Buffer memory of PC( Default driver is C: or D: ) If the space of C: or D: is not enough for IC, you can use removable device as buffer memory.

  • Page 103: Operation

    Operation Operation ① Operation Mode You can check the operation mode at the box of SOKET Status Window. If no operation is running, it shows [TEND]. ① ② ② Progress Status The progress status of operation is showed as % at the ProgressBar on the Socket status window.
  • Page 104 Operation SOCKET on Progress While running, the Site #1 is flashed on and off with orange color and baby blue while operation is finished. オペレーション終了後、サイト表示は薄緑色に戻ります。 Green： Pass Red： Fail Check by LogWindow You can check the operation mode, site number, time, etc on log window. Other status According to the menu /Tool bar to check the status of operation.
  • Page 105 Operation Stop Clicking button to stop an operation and below status can be checked. Socket colour ： All red Buzzer ： short pi pi pi(・・・・) LED cloure：All red Counter ： No change Recommend not to stop operation while running, because IC may be demaged. M400-020A-K6...
  • Page 106 Operation Operation options It's possible to designate the operations for "option yes/no" and "write-in" to the device. To preset the operation, please choose "Device->Device operation options" menu option. [ Device Address ] Device start Address (Word/hex) (fixed value) Device end Address (Word/hex) (fixed value) Buffer start Address (byte/hex) (fixed value) [ Insertion test ]...
  • Page 107 Operation [ Programming parameters ] Set the part/s which should be programmed [ Erase parameters ] Set the part/s which should be erased. M400-020A-K6...
  • Page 108 システム関連について Help Language You can choose English or Japanese for this control software. And all the information & error message will be displayed using this language. ※ Default language is English. Set as English Choosing [Help] -> [Choice of the language] -> [English] and the main screen will be English.

  • Page 109: Quick Start

    Quick Start Install software and USB driver Run the installation program in the CD:  M400installer_vxxxx.exe ( MODEL400 Series Control Software )  M400_USB_driver.exe ( USB driver) Install them one by one according to the prompt message. Install the programmer ・hardware Connect the programmer to PC by the USB cable.
  • Page 110 Quick Start IC Operation (Program) ①Select device. click ---- > ②Load data to buffer. a) From file click----- > b) From IC ----- >Put IC into ZIF SOCKET and click ③Put IC into the DIP Socket. ④click -----＞ a) Unwritten status (BLANKING) is selected. b) Delete (ERASE) data from the device to which the data have been written.

  • Page 111: Troubleshooting

    Example) MODEL 404 ※It’s just a example because there will be different Port number . If you changed the usb port number, please restart the programmer. Still can not be connected, please contact with minato. M400-020A-K6...
  • Page 112 Message Message ／error Number message Note guide ／ notice ／ dispose C:\ no enough space dispose The blank space of harddisk is not Current space: ***MB enough, please increase it. Required space： ***MB Site # connecting fail error Communication fail Please close the software and power off the programmer.
  • Page 113 Message Number message Guide / error / Note notice / dispose Read setting fail error Read setting again Contact check Fail of error Please check IC. If you want to continue the Socket。 operation, please take the IC from SOCKET. SOCKET: Red ID check Fail of error...
  • Page 114 You can confirm the version of control software by clicking Help -- > About Universal Control Program Version. Version up Minato will release new version software while new device is added and you just need to install the new software. Please contact with minato for the new version M400 Control software (Universal Control Program.)
  • Page 115 起動時の接続モード Connecting mode M400-020A-K6...
  • Page 116 Buzzing situation Buzzing situation Note Power ON UniversalControlProgram Strart finished Changed the device Operation selected Operation finished Different buzzing due to operation result Items saved in Project File Type Items description Save note ○ Project ID Confirmation of Project Key in before saving ○...
  • Page 117 Status bar Display or not × language Displayed language × Items saved in log file Type Item Description Save Note ○ Title Version UniversalControlProgrammer ○ Model 404 / 408 / 416 Programmer P/N × ○ Lot number Lot information before operation ○...
  • Page 118 expected value. Deletion of the data Deletion of data files for operation. file Open log file Open log file (Recent file) Recent project file Exit Exit Edit Edit buffer Buffer Editor Programmer Buzzer Buzzer setting Self test Check programmer Clear data Delete the data.
  • Page 119 Function Erase buffer Clear Buffer Fill random Clear buffer with random data data Fill block Intianalized the buffer with indicated data Copy block Copy partial data Move block Move partial data Swap data in Swap block Find text Search data Replace text Replace data Go to Address...

  • Page 120: Terminology

    Terminology ク Terminology Endian For device which data is more than 9bit, which order will be used to write BufferData (Byte=8bit) to IC? Refer to Little endian and Big endian ※Default is Little endian. <Little endian> "Little Endian" means that the low-order byte of the number is stored in memory at the lowest address, and the high-order byte at the highest address.
  • Page 121 Terminology As one of the logical operations, it is used to check if the data for which the mean value is the same as the value obtained from buffer data through this operation. CRC ( Cyclic Redundancy Check, CRC ) It is another quick way to identify data.
  • Page 122 Terminology ク <NO Format (*.BIN)> Just binary data. Swap Swap a high- and low- order of byte in current buffer Buffer offset Normal the start address of IC is 0,but some Micro tool creates a file from another address, so we should set the offset for some file format. One Time<ＯＴＰ>...
  • Page 123 Terminology <Lot>/Lot size The unit for production quantity. M400-020A-K6...

  • Page 124: Contacts

    Revision Contacts MINATO ADVANCED TECHNOLOGIES INC. Address： ・Headquarters (Origin:Yokohama office) 4105, Minami Yamata-cho, Tsuzuki-ku, Yokohama-shi, Kanagawa, 224-0026, Japan TEL: +81-45-591-5611 / FAX: +81-45-591-6451 E-mail: et-sales@minato.co.jp ・Osaka sales office 2F, Fukushima Miyawaki-Bldg., 5-16-15, Fukushima, Fukushima-ku, Osaka-shi, Osaka 553-0003 , Japan TEL: 06-6453-8911 / FAX: 06-6453-8912 ・Fukuoka sales office...

  • Page 125: Revision

    Revision Revision DATE Contents － Rev1 2010/06/25 Rev2 2010/11/01 Added & revised Rev3 2011/03/31 Changed the name of the manual and added & revised Rev4 2013/10/08 Added & revised Rev5 2015/07/01 Added & revised Rev5.1 2017/06/29 Changed the name of the business establishment. Rev6 2017/09/28 Added the Protect in the contents.
