Summary of Contents for Samsung WS-32A208P

  • Page 1 Pre_AA68-03304A-01Eng 6/29/04 5:23 PM Page 1 COLOUR TELEVISION Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. ON-SCREEN MENUS PICTURE IN PICTURE TELETEXT WISE LINK (OPTION)
  • Page 2 Pre_AA68-03304A-01Eng 6/29/04 5:23 PM Page 2...
  • Page 3 Pre_AA68-03304A-01Eng 6/29/04 ONNECTING AND View of Your Television (depending on the model) ... Infrared Remote Control (depending on the model) ... Inserting the Batteries in the Remote Control... Connecting to an Aerial or Cable Television Network ... Switching Your Television On and Off... Placing Your Television in Standby Mode ...
  • Page 4 Pre_AA68-03304A-01Eng 6/29/04 SING THE Using Wise Link (depending on the model)... Switching to WISE LINK Mode (depending on the model) ... Selecting Image (JPEG) Files/Music (MP3) Files (depending on the model) ... Picture (JPEG) Playback (depending on the model) ... Rotating the Picture (JPEG) (depending on the model) ...

  • Page 5: View Of Your Television

    Pre_AA68-03304A-01Eng 6/29/04 View of Your Television ➢ The actual configuration on your TV may be different, depending on your model. Control Panels 1) Standby Indicator 2) Remote Control Sensor 3) Power On/Off 4) Channel Selection W.LINK Mode 8) Move Button 9) Select Button ➢...

  • Page 6: Connection Panels

    Pre_AA68-03304A-01Eng 6/29/04 View of Your Television Connection Panels Side of the TV Audio Input (R, L) Video Input S-Video Input English - 6 5:23 PM Page 6 (depending on the model) (continued) SCART Audio/ Video Input/Output 75Ω Coaxial Connector for Aerial/Cable Network Rear of the TV Monitor Audio Output...

  • Page 7: Infrared Remote Control

    Pre_AA68-03304A-01Eng 6/29/04 Infrared Remote Control TELEVISION STAND-BY PICTURE SIZE SELECTION SOUND MODE SELECTION DIRECT CHANNEL SELECTION ONE/TWO-DIGIT CHANNEL SELECTION VOLUME INCREASE TEMPORARY SOUND SWITCH-OFF VOLUME DECREASE MENU DISPLAY MOVE TO THE REQUIRED MENU OPTION/ ADJUST AN OPTION VALUE RESPECTIVELY SOUND MENU DISPLAY TURBO SOUND STILL PICTURE DNIe ON/OFF/DEMO...
  • Page 8 Pre_AA68-03304A-01Eng 6/29/04 Infrared Remote Control TELETEXT SIZE SELECTION TELETEXT SUB-PAGE TELETEXT PAGE HOLD SUB PICTURE(PIP) NEXT CHANNEL PIP ON/OFF PROGRAMME SELECTION BY NAME SUB PICTURE(PIP) LOCATION SELECTION SUB PICTURE(PIP) SOURCE SELECTION English - 8 5:23 PM Page 8 (depending on the model) (continued) TELETEXT DISPLAY/ MIX BOTH TELETEXT INFORMATION AND THE NORMAL BROADCAST...

  • Page 9: Inserting The Batteries In The Remote Control

    Pre_AA68-03304A-01Eng 6/29/04 Inserting the Batteries in the Remote Control You must insert or replace the batteries in the remote control when you: N Purchase the television N Find that the remote control is no longer operating correctly Remove the cover on the rear of the remote control by pressing the symbol ( ) downwards and then pulling firmly to remove it.

  • Page 10: Switching Your Television On And Off

    Pre_AA68-03304A-01Eng 6/29/04 Switching Your Television On and Off Placing Your Television in Standby Mode English - 10 5:23 PM Page 10 The mains lead is attached to the rear of your television. Plug the mains lead into an appropriate socket. ➢...

  • Page 11: Becoming Familiar With The Remote Control

    Pre_AA68-03304A-01Eng 6/29/04 Becoming Familiar with the Remote Control The remote control is used mainly to: N Change channels and adjust the volume N Set up the television using the on-screen menu system The following table presents the most frequently used buttons and their functions.

  • Page 12: Plug & Play Feature

    Pre_AA68-03304A-01Eng 6/29/04 Plug & Play Feature Plug & Play Language English âe‰tina Srpski Deutsch Français Hrvatski Român™ Nederland Magyar Español Polski Italiano êÛÒÒÍËÈ Svenska Å˙΄‡ÒÍË Português ∂ÏÏËÓÈο Türkçe Move Skip Check antenna input. œ œ √ √ Move Skip Auto Store œ...

  • Page 13: Viewing The Demonstration

    Pre_AA68-03304A-01Eng 6/29/04 Viewing the Demonstration To become familiar with the various menus provided by your television, you can view the inbuilt demonstration. Press the MENU ( ) button. Result: The main menu is displayed. Press the M or L button to select Setup. Result: The options available in the Setup group are displayed.

  • Page 14: Storing Channels Automatically

    Pre_AA68-03304A-01Eng 6/29/04 Storing Channels Automatically Channel Auto Store Manual Store Add/Delete Sort Name † † More œ œ √ √ Move Enter Auto Store œ œ UK Country Search : -/+ œ œ √ √ Move Adjust Auto Store Country : UK œ...

  • Page 15: Sorting The Stored Channels

    Pre_AA68-03304A-01Eng 6/29/04 Sorting the Stored Channels This operation allows you to change the programme numbers of stored channels. This operation may be necessary after using auto store. You can delete the channels you do not want to keep. Press the MENU ( ) button.

  • Page 16: Storing Channels Manually

    Pre_AA68-03304A-01Eng 6/29/04 Storing Channels Manually Channel Auto Store Manual Store Add/Delete Sort Name † † More œ œ √ √ Move Enter Manual Store œ œ P 1----- √ √ Programme Colour System : AUTO Sound System : DK Search Channel : C-- Store...
  • Page 17 Pre_AA68-03304A-01Eng 6/29/04 Storing Channels Manually If you know the number of the channel to be stored, see the following steps. N Press the M or L button to select Channel. N Press the √ button. N Press the M or L button to select C (Air channel) or S (Cable channel).

  • Page 18: Skipping Unwanted Channels

    Pre_AA68-03304A-01Eng 6/29/04 Skipping Unwanted Channels Channel Auto Store Manual Store Add/Delete Sort Name † † More œ œ √ √ Move Enter Add/Delete œ œ Added : Added : Added : Added œ œ √ √ Move Adjust Add/Delete œ œ Deleted : Added : Added : Added...

  • Page 19: Assigning Names To Channels

    Pre_AA68-03304A-01Eng 6/29/04 Assigning Names to Channels Channel names will be assigned automatically when channel information is broadcast. These names can be changed, allowing you to assign new names. Press the MENU ( ) button. Result: The main menu is displayed. Press the M or L button to select Channel.

  • Page 20: Fine Tuning Channel Reception

    Pre_AA68-03304A-01Eng 6/29/04 Fine Tuning Channel Reception Channel … … More Fine Tune œ œ √ √ Move Enter Fine Tune Reset Move Save œ œ √ √ Adjust Return English - 20 5:23 PM Page 20 If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store operation.

  • Page 21: Using The Lna (Low Noise Amplifier) Feature

    Pre_AA68-03304A-01Eng 6/29/04 Using the LNA (Low Noise Amplifier) feature This function is very useful in the situation that the TV is used in weak signal. LNA amplifies the TV signal in the weak signal area, but not noise. This feature is working only weak signal condition, and that is memorized on current channel, additional.

  • Page 22: Adjusting The Picture Settings

    Pre_AA68-03304A-01Eng 6/29/04 Adjusting the Picture Settings Picture Mode : Dynamic Custom Colour Tone : Normal Size : Auto Wide Scan Mode : Natural † † More œ œ √ √ Move Enter Custom œ œ 70 Contrast Brightness : 55 Sharpness : 50 Colour...

  • Page 23: Selecting The Colour Tone

    Pre_AA68-03304A-01Eng 6/29/04 Selecting the Colour Tone Press the MENU ( ) button. Result: The main menu is displayed. Press the M or L button to select Picture. Result: The options available in the Picture group are displayed. Press the œ or √ button. Press the M or L button to select Colour Tone.

  • Page 24: Extra Picture Settings

    Pre_AA68-03304A-01Eng 6/29/04 Extra Picture Settings Picture Mode : Dynamic Custom Colour Tone : Normal Size : Auto Wide œ œ Natural Scan Mode † † More œ œ √ √ Move Adjust Picture … … More œ œ On Digital NR DNIe : On Tilt...

  • Page 25: Setting The Blue Screen

    Pre_AA68-03304A-01Eng 6/29/04 Setting the Blue Screen If no signal is being received or the signal is very weak, a blue screen automatically replaces the noisy picture background. If you wish to continue viewing the poor picture, you must set the “Blue Screen”...

  • Page 26: Freezing The Current Picture

    Select the required sound effect by pressing the œ or √ button repeatedly. Result: The following sound effects are available: Standard - Music - Movie - Speech(SVE) - Custom. N SVE : SAMSUNG Voice Enhancement Technic ➢ You can also set these options simply by pressing the S.MODE( )” button.

  • Page 27: Adjusting The Sound Settings

    Pre_AA68-03304A-01Eng 6/29/04 Adjusting the Sound Settings The sound settings can be adjusted to suit your personal preferences. Press the MENU ( ) button. Result: The main menu is displayed. Press the M or L button to select Sound. Result: The options available in the Sound group are displayed.

  • Page 28: Extra Sound Settings

    Pre_AA68-03304A-01Eng 6/29/04 Extra Sound Settings Sound Mode : Custom Equalizer Auto Volume Dolby Virtual Turbo Sound Pseudo Stereo œ œ √ √ Move Adjust Sound Mode : Custom Equalizer Auto Volume Dolby Virtual Turbo Sound Pseudo Stereo œ œ √ √ Move Adjust Sound...

  • Page 29: Selecting The Melody

    Pre_AA68-03304A-01Eng 6/29/04 Selecting the Melody The sound settings can be adjusted to suit your personal preferences. Press the MENU ( ) button. Result: The main menu is displayed. Press the M or L button to select Setup. Result: The options available in the Setup group are displayed.

  • Page 30: Selecting The Sound Mode

    Pre_AA68-03304A-01Eng 6/29/04 Selecting the Sound Mode English - 30 5:23 PM Page 30 (depending on the model) The “DUAL I-II” button displays/controls the processing and output of the audio signal. When power is switched on, the mode is automatically preset to either “DUAL-I ” or “STEREO”, depending on the current transmission.

  • Page 31: Setting And Displaying The Current Time

    Pre_AA68-03304A-01Eng 6/29/04 Setting and Displaying the Current Time You can set the television’s clock so that the current time is displayed by pressing the “INFO ( )” button. You must also set the time if you wish to use the automatic on or off timers. ➢...

  • Page 32: Setting The Sleep Timer

    Pre_AA68-03304A-01Eng 6/29/04 Setting the Sleep Timer Setup Plug & Play Language : English Time Blue Screen : On Melody : On Demonstration œ œ √ √ Move Enter Time Clock 11 : 00 Sleep Timer On Timer -- : -- Off Off Timer -- : -- Off On Timer Volume...

  • Page 33: Switching The Television On And Off Automatically

    Pre_AA68-03304A-01Eng 6/29/04 Switching the Television On and Off Automatically You can set the On/Off timers so that the television will: N Switch on automatically and tune to the channel of your choice at the time you select N Switch off automatically at the time you select ➢...

  • Page 34: Setting The Preferred Volume Level/Channel

    Pre_AA68-03304A-01Eng 6/29/04 Setting the Preferred Volume Level/Channel Setup Plug & Play Language : English Time Blue Screen : On Melody : On Demonstration œ œ √ √ Move Enter Time Clock 11 : 00 Sleep Timer On Timer 06 : 00 On Off Timer -- : -- Off On Timer Volume...
  • Page 35 Pre_AA68-03304A-01Eng 6/29/04 Viewing an External Signal Source/Edit Name Use the remote control to switch between viewing signal from connected equipment, such as VCR, DVD, Set-Top-boxes and the TV source (broadcast or cable) Press the MENU button. Result: The main menu is displayed. Press the œ...

  • Page 36: Viewing The Picture In Picture (Pip)

    Pre_AA68-03304A-01Eng 6/29/04 Viewing the Picture In Picture (PIP) Picture … … More Digital NR : On DNIe : On Tilt œ œ √ √ Move Enter œ œ Off œ œ √ √ Move Adjust : On œ œ TV Source Swap Size...
  • Page 37 Pre_AA68-03304A-01Eng 6/29/04 Viewing the Picture In Picture (PIP) Press the M or L button to select Size. Select a size of sub picture by pressing the ➛¤or ❿ button. Result: The sizes are displayed in the following order: Large - Small - Double Window - 16 PIP. ➢...
  • Page 38 Pre_AA68-03304A-01Eng 6/29/04 Using Wise Link Wise Link is used to play JPEG files (*.jpg) and MP3 files (*.MP3) stored in the memory card on the TV. N What is a Memory Card? A memory card is an auxiliary storage device used in AV equipment to exchange data between devices.
  • Page 39 Pre_AA68-03304A-01Eng 6/29/04 Using Wise Link (depending on the model) (continued) N Cautions on using WISE LINK Mode - Do not insert foreign objects into the slot. - Insert the memory card in the proper direction - Do not remove the memory card when it is in use. - The manufacturer’s responsibility does not include damaged data.

  • Page 40: Switching To Wise Link Mode

    Pre_AA68-03304A-01Eng 6/29/04 Switching to WISE LINK Mode Source List WISE LINK EXT1 : ------ EXT2 : ------ EXT3/S-Video : ------ œ œ √ √ Move Enter English - 40 5:23 PM Page 40 Press the MENU Result: The main menu is displayed. Press the œ...
  • Page 41 Pre_AA68-03304A-01Eng 6/29/04 Selecting Image (JPEG) Files/Music (MP3) Files Press the W.LINK button. Press the M or L button to select which memory card to run and then press the ENTER ( Press the œ or √ button to select the file type to run and then press the ENTER ( ) button.
  • Page 42 Pre_AA68-03304A-01Eng 6/29/04 Picture (JPEG) Playback ➢ JPEG file format is supported. 1) Press the (œ √ML) button to move to the desired file and select it. Press the Selection button and a full page image will be displayed. 2) Press the ( the previous page.
  • Page 43 Pre_AA68-03304A-01Eng 6/29/04 Rotating the Picture (JPEG) Press the ENTER ( ) button while viewing the full page image. Result: The HELP menu is displayed in the lower part of the screen. Press the œ or √ button to select Rotate and then press the ENTER ( ) button.
  • Page 44 Pre_AA68-03304A-01Eng 6/29/04 Music File (MP3) Playback ➢ MP3 file format is supported. 1) Press the M or L button to move to a desired file and it will automatically play. 2) Press the ( the previous page. 3) The active page is displayed. 4) Press the ( the next page.
  • Page 45 Pre_AA68-03304A-01Eng 6/29/04 Playback All JPEG/MP3 Files ➢ JPEG/MP3 files are displayed. 1) Please see pages 41 and 44 on how to playback JPEG & MP3 files. (œ œ œ œ ) 2) Press the button to move to the previous page. 3) The active page is displayed.

  • Page 46: Wise Link Menu Setup

    Pre_AA68-03304A-01Eng 6/29/04 WISE LINK Menu Setup Setup Music Slide Show Slide Show Speed : Normal Slide Show Effect : Full Screen Music Repeat : Off Screen Saver : 5min Move Enter Setup Music Slide Show Fast Slide Show Speed : Normal Normal Slide Show Effect : Full Screen...
  • Page 47 Pre_AA68-03304A-01Eng 6/29/04 WISE LINK Menu Setup Music Slide Show Music Slide Show Slide Show Speed Slide Show Effect Music Repeat Screen Saver Move Slide Show Speed Music Slide Show Slide Show Speed Slide Show Effect Music Repeat Screen Saver Move Slide Show Effects Music Slide Show Slide Show Speed...

  • Page 48: Teletext Feature

    Pre_AA68-03304A-01Eng 6/29/04 Teletext Feature Displaying the Teletext Information English - 48 5:24 PM Page 48 Most television channels provide written information services via teletext. Information provided includes: N Television programme times N News bulletins and weather forecasts N Sports results N Travel information This information is divided into numbered pages (see diagram).

  • Page 49: Selecting A Page By Number

    Pre_AA68-03304A-01Eng 6/29/04 Selecting a Page by Number You can enter the page number directly by pressing the numeric buttons on the remote control. Enter the three-digit page number given in the content by pressing the corresponding numeric buttons. Result: The current page counter is incremented and the page is then displayed.

  • Page 50: Using Flof To Select A Page

    Pre_AA68-03304A-01Eng 6/29/04 Using FLOF to Select a Page Storing Teletext Pages English - 50 5:24 PM Page 50 The various topics included in the teletext pages are colour-coded, and can be selected by pressing the coloured buttons on the remote control.

  • Page 51: Connecting To The External Input/Outputs

    Pre_AA68-03304A-01Eng 6/29/04 Connecting to the External Input/Outputs ➢ “ ” is used for the equipment with an RGB output, such as video game devices or video disc players. Rear of the TV This end can be fitted with: N A SCART connector N Three RCA connectors (Video + Audio-L and R) If you have a second VCR and wish to copy cassettes tape, connect the source VCR to “...

  • Page 52: Connecting To The Rca Input

    Pre_AA68-03304A-01Eng 6/29/04 Connecting to the RCA Input ➢ The RCA (VIDEO and AUDIO-L+R) connectors are used for equipment, such as camcorders, video disc players, and some video game devices. Side of the TV Connecting to the S-Video Input ➢ The S-VIDEO and RCA (AUDIO-L+R) connectors are used for equipment with an S-Video output, such as a camcorder or VCR.

  • Page 53: Viewing Pictures From External Sources

    Pre_AA68-03304A-01Eng 6/29/04 Viewing Pictures From External Sources Once you have connected up your various audio and video systems, you can view different sources by selecting the appropriate input. Check that all the necessary connections have been made. Switch your television on, then press the SOURCE repeatedly.

  • Page 54: Troubleshooting

    Pre_AA68-03304A-01Eng 6/29/04 Troubleshooting: Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer. No sound or picture...
  • Page 55 Pre_AA68-03304A-01Eng 6/29/04 5:24 PM Page 55 Memo English - 55...
  • Page 56 Pre_AA68-03304A-01Eng 6/29/04 5:24 PM Page 56 - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. ELECTRONICS AA68-03304A-01...
