Panasonic KX-T7720 Quick Reference Manual
Proprietary telephones
Hide thumbs
Also See for KX-T7720:
- Quick reference manual (13 pages) ,
- User manual addendum (16 pages) ,
- User manual (13 pages)
Advertisement
Important Information
When you ship the product:
Carefully pack and send it prepaid, adequately insured and preferably in the original carton.
Attach a postage-paid letter, detailing the symptom to the outside of the carton.
DO NOT send the product to the Executive or Regional Sales offices. They are NOT
equipped to make repairs.
Product service:
Panasonic Servicenters for this product are listed in the servicenter directory.
Consult your authorized Panasonic dealer for detailed instructions.
WARNING:
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR ANY TYPE OF MOISTURE.
THIS HANDSET EARPIECE IS MAGNETISED, AND MAY RETAIN SMALL FERROUS
OBJECTS.
IMPORTANT NOTICE:
Under power failure conditions, this telephone may not operate. Please ensure that a
separate telephone, not dependent on local power, is available for use in an emergency.
Note:
In this manual, the suffix of each model number is omitted.
Included Accessories: for extra orders, call toll free 1-800-332-5368
Handset . . . . . . . . . . . . . . 1
Telephone Line Cord . . . . . 1
Overlay . . . . . . . . . . . . . . . . 1
SERIAL NO.
(found on the bottom of the unit)
NAME OF DEALER
DEALER S ADDRESS
DEALER S TEL. NO.
Please read this manual before using and save for future reference.
All manuals and user guides at all-guides.com
Quick Reference Guide
Model
(KX-T7730, KX-T7735 only)
For your future reference
DATE OF PURCHASE
Proprietary Telephones
KX-T7720/KX-T7730
KX-T7735/KX-T7750
Handset Cord . . . . . . . . . 1
Stand . . . . . . . . . . . . . . . 1
Advertisement
Table of Contents
Related Manuals for Panasonic KX-T7720
Summary of Contents for Panasonic KX-T7720
- Page 1 DO NOT send the product to the Executive or Regional Sales offices. They are NOT equipped to make repairs. Product service: Panasonic Servicenters for this product are listed in the servicenter directory. Consult your authorized Panasonic dealer for detailed instructions. WARNING: TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR ANY TYPE OF MOISTURE.
-
Page 2: Features List
All manuals and user guides at all-guides.com Features List Outside (CO) Line button Programmable Function button Feature number * "Location of Controls" is shown on page 8. Off-hook On-hook Talk Operation Desired Function Making Calls To an extension To an external party Calling extension no. - Page 3 All manuals and user guides at all-guides.com Features List Operation Desired Function Receiving Calls While on-hook Handsfree answerback (KX-T7720/7730 /7735 only) Outside (CO) Line (KX-TA1232 only) Directed Picking up extension no. KX-TA624 a call KX-TA1232 extension no. (Check the type of your Main Unit.)
- Page 4 All manuals and user guides at all-guides.com Features List Operation Desired Function When the Dialled Extension is Busy/No Answer While hearing a busy tone Sender Wait for an answer. KX-TA624 For outside calls Cancel For intercom calls Call Waiting Cancel Receiver KX-TA1232 Cancel...
- Page 5 All manuals and user guides at all-guides.com Features List Operation Desired Function Useful Features To page All extensions Group group no. KX-TA624 All external speakers All extensions & external speakers KX-TA1232 Announce. Paging All external speakers Specific external speaker external speaker no. All extensions &...
- Page 6 All manuals and user guides at all-guides.com Features List Operation Desired Function Useful Features KX-TA624 For Log-In For Log-Out Log-In/Log-Out KX-TA1232 For Log-In For Log-Out (Check the type of your Main Unit.) KX-TA624 All calls extension no. Busy/No answer extension no. To an outside line line access phone no.
- Page 7 All manuals and user guides at all-guides.com Features List Operation Desired Function Useful Features KX-TA624 Do Not Disturb Cancel (DND) KX-TA1232 Cancel (Check the type of your Main Unit.) KX-TA624 (lock code is 4 digits) Lock lock code lock code lock code Unlock Locking your...
-
Page 8: Location Of Controls
CONF (Conference): Used to establish a multiple party conversation. AUTO ANS (Auto Answer) (KX-T7720/7730/7735): Used to receive an INTERCOM: Used to make or receive incoming call in the hands-free mode. intercom calls. MUTE (KX-T7720/7730/7735): Used to mute FWD/DND (Call Forwarding/Do Not the microphone during a conversation. -
Page 9: Initial Settings
(Slow flash), Double (Moderate flash), or function. Triple (Rapid flash) in your PBX, the lamp VOLUME KEY (KX-T7720/7750): Used to flashes. When the other ringing patterns adjust the volume. are set in your PBX, the lamp may not flash. -
Page 10: Wall Mounting
All manuals and user guides at all-guides.com Connection TO MAIN UNIT To the main unit ( The telephone line cord /PABX (included) < Back view> Headset CAUTION Ensure the cord is inserted in the groove to prevent damage to the connector. Wall Mounting Pull down the handset hook until it locks, Remove the attached stand. -
Page 11: Important Safety Instructions
All manuals and user guides at all-guides.com Important Safety Instructions When using this unit, basic safety 11. Unplug this unit from the main unit, precautions should always be followed to and refer servicing to an authorized reduce the risk of fire, electric shock, or servicenter when the following personal injury. -
Page 12: Fcc And Other Information
• When a failure occurs which exposes any internal parts, disconnect the telephone line and mains supply immediately and return the unit to your maintainer. This telephone provides magnetic coupling for hearing aids. Panasonic Consumer Electronics Panasonic Sales Company ("PSC"), Company, Division of Matsushita Division of Matsushita Electric of Electric Corporation of America Puerto Rico, Inc.
