Installation & User Manual
®
HAULWAY
Swingaway
1-YEAR WARRANTY. Please register at www.ezaccess.com/warranty-satisfaction.
© Homecare Products, Inc. All rights reserved. All text and images contained in this document are
proprietary and may not be shared, modified, distributed, reproduced, or reused without the express
written permission of EZ-ACCESS®, a division of Homecare Products, Inc.
Manufactured in the USA
15062 REV 04-04-17
Advertisement
Table of Contents
Related Manuals for EZ-ACCESS HAULWAY Swingaway
Summary of Contents for EZ-ACCESS HAULWAY Swingaway
- Page 1 © Homecare Products, Inc. All rights reserved. All text and images contained in this document are proprietary and may not be shared, modified, distributed, reproduced, or reused without the express written permission of EZ-ACCESS®, a division of Homecare Products, Inc. Manufactured in the USA...
-
Page 2: Table Of Contents
INTRODUCTION, IMPORTANT INFORMATION & WARNINGS The HAULWAY SWINGAWAY enables full access to the vehicles tailgate, rear door, or cargo area. If rear cargo access is not a concern, you will need an L-tube. The SWINGAWAY is available in Class III only. -
Page 3: Shipping Contents And Tools Typically Needed
Disconnect the vehicle battery before you begin installation. “Hot” (positive) on the HAULWAY SWINGAWAY license plate lamp is the white wire; your vehicle wiring may be different. Reversing polarities will result in an unsafe and potentially hazardous, situation. Is this applicable to this manual? “Ground”... -
Page 4: Identifying Your Swingaway
IDENTIFYING YOUR SWINGAWAY Before installing the HAULWAY, check your vehicle’s owner manual for towing capacities. NEVER exceed the towing capacity and tongue weights of your vehicle. The SWINGAWAY is offered in NO DROP, 2” DROP, and 4” DROP with RIGHT hand swing (shown below). It is also offered in a NO DROP with LEFT hand swing (not shown), which opens on the opposite side of those shown below. -
Page 5: Attaching The Swingaway To The Haulway
1. ATTACHING THE SWINGAWAY TO THE HAULWAY Prior to installing the SWINGAWAY, the vehicle and hitch must be inspected to ensure the vehicle is in proper condition to safely use the HAULWAY SWINGAWAY. Consult your auto manufacture, hitch dealer, and HAULWAY SWINGAWAY dealer for additional information. -
Page 6: Attaching Swingaway To Vehicle
2. ATTACHING SWINGAWAY TO VEHICLE 2.1 Insert SWINGAWAY (FIG. 3, item 1) into the vehicle’s receiver (FIG. 3, item 2) until one of the pre-drilled holes in the receiver (FIG. 3, item 5) aligns with one of the holes in the SWINGAWAY (FIG. 3, item 3). When aligning holes, make sure to keep the SWINGAWAY as close to the bumper as possible, while still allowing the fold up lever (FIG. -
Page 7: Attaching Electrical Connectors To Swingaway
3. ATTACHING ELECTRICAL CONNECTORS TO SWINGAWAY 3.1. Referencing FIG. 5, the electrical circuit drawing below, connect vehicle to HAULWAY SWINGAWAY as follows: 3.1.1. Plug (1) into (2), (3) into (4), (5) into (6), and (7) into (8) HAULWAY SWINGAWAY Standard is shown below; note electrical works the same for all HAULWAY SWINGAWAY lifts. -
Page 8: Swingaway Operation
NEVER USE YOUR SWINGAWAY WITH A MOBILITY DEVICE LOADED ON IT (FIG. 6.4). Do not swing your HAULWAY SWINGAWAY into any type of traffic areas; always ensure the HAULWAY SWINGAWAY does not obstruct, or become a safety hazard, to others. -
Page 9: Opening And Closing The Swingaway
5. OPENING THE SWINGAWAY 5.1. Remove mobility device from HAULWAY. 5.2. Remove cotter pin (FIG. 7, item 1) from hitch pin (FIG. 7, item 2). Cotter pin is attached to a cable lanyard to help prevent loss. 5.3. Remove hitch pin (FIG. 7, item 2). DO NOT LOSE HITCH PIN. 5.4.
