SEPTENTRIO ALTUS NR3 Quick Start Manual

A NR3 Q
LTUS UICK
This Quick Start Guide contains information on how to set
up and begin using your Altus NR3
System components
The following items are shipped as standard:
1. Altus NR3
2. USB data cable
3. 4 x Lithium Ion batteries (Standard 18650 Li-ion)
4. Altus NR3 Battery Charger (4-battery capacity)
5. Battery charger cables for mains and cigarette lighter
6. USB stick containing Altus NR3 manuals
Additional Equipment Required
•
GSM/GPRS cellular modem micro SIM Card with data
service
•
WiFi capable tablet, PC or smartphone
Getting Started
1. Installing the SIM card and batteries
• Install an activated SIM in the
left-hand battery slot
•
Charge the batteries for the
Altus NR3 in the 4-bay
charger provided.
•
Insert 2 fully-charged batteries
into the Altus NR3. The positive
ends of the batteries should
point towards the front panel.
• Press firmly at the position
indicated by the grey arrow to
lock the chamber
S G
TART UIDE
2. Powering up the Altus NR3
•
Power on by pressing the power button once. The unit
takes about 30 seconds to fully boot up.
P
RESS ONCE
*
TO TURN ON
*
To switch off the Altus NR3, press the power button for 2 seconds
3. Turning on WiFi
• WiFi is turned on by default and will be available about
30 seconds after powering on
•
If the WiFi LED is off, you can toggle WiFi on/off by
quickly pressing twice on the power
button
P
RESS TWICE TO
W F
TURN I I ON
4. Connecting to the Web Interface
•
On your PC or mobile device, find the WiFi network
beginning with Altus_NR3 then click Connect
• Open a browser and type 192.168.20.1 in the address bar
/
OFF
