Powering On an EX 8200 series Switch

Before you power on the switch, ensure that:
You have installed all required switch components.
You have installed the required number of power supplies to support redundant
operation for the switch configuration (see Calculating Power Requirements for
an EX 8208 Switch or Calculating Power Requirements for an EX 8216 Switch).
You understand how to protect the switch from electrostatic damage. See
Prevention of Electrostatic Discharge Damage on EX-series Switches.
Ensure that you have the following parts and tools available to power on the switch:
An electrostatic discharge (ESD) grounding strap
An external management device such as a PC
A cable to connect the external management device to the master Switch Fabric
and Routing Engine (SRE) module's console (CON) port or management (MGMT)
port in an EX 8208 switch or the master Routing Engine (RE) module s console
(CON) port or management (MGMT) port in an EX 8216 switch.
For connecting a management device to the console port, see Connecting an
EX-series Switch to a Management Console. For connecting a management device
to the management port, see Connecting an EX-series Switch to a Network for
Out-of-Band Management.
To power on the switch:
Attach the ESD grounding strap to your bare wrist and connect the strap to the
1.
ESD point on the chassis.
Connect the external management device to the master SRE or master RE
2.
module's management (MGMT) port.
Turn on the power to the external management device.
3.
Ensure that the power supplies are fully inserted in the chassis and that each of
4.
their handles is flush against the faceplate.
Ensure that the source power cord is inserted securely into the appliance inlet
5.
for each AC power supply.
If you are using DC power supplies for an EX 8216 switch, ensure that the source
power cables are connected to the appropriate terminal: the positive (+) source
cable to the return terminal (RTN) and the negative (-) source cable to the input
terminal (-48 VDC).
Switch on the site circuit breakers.
6.
7. Flip a power supply s Enable switch to the on position (ON). See Figure 1. Observe
the power supply faceplate LEDs. If the power supply is installed correctly and
functioning normally, the INPUT OK / IN OK and OUTPUT OK / OUT OK LEDs light
and remain constantly lit. The FAIL LED does not light.
