11.1.

11.1. Signal output configuration

Signal output configuration
11.1. 11.1. Signal output configuration Signal output configuration
The signal header can be configured as a speed signal output or as a switching
output.
Option "Power switch (53216)": This mode can be used for emergency shutdown
of the PC, if the "signal" header is connected to the power switch header of the
motherboard using a suitable cable (art. 53216). Before connecting the cable,
make sure the signal output is configured correctly! After connecting the cable, test
the setup by deliberately creating an alarm condition. If the PC is not shut down,
the cable header connected to the motherboard must be rotated by 180 degrees
and the test has to be repeated. Emergency shutdown may result in data loss as
operating system and running programs are not shut down properly!
11.2.

11.2. Alarm reporting and alarm limits

Alarm reporting and alarm limits
11.2. 11.2. Alarm reporting and alarm limits Alarm reporting and alarm limits
If desired, activate alarm monitoring and set an appropriate alarm limit. If the cur-
rent reading is higher/lower than the limit, an alarm can be raised.
While an alarm condition is detected, the device display will permanently show a
corresponding information screen. Additionally, the RGBpx illumination can be
configured to flash red.
On the alarm page within the aquasuite, all sources that currently raise an alarm
are highlighted with a red background color. Alarms that have been active at least
once since device start-up, but are not active presently, are highlighted with a yel-
low background color.

12. Profiles

12. 12. 12. Profiles Profiles Profiles
Select "Profiles" from the device list below the "high flow NEXT" entry.
The profile management can be used to to save four configurations as
profiles and activate them manually or automatically. Profile manage-
ment is a software feature of the aquasuite and requires a USB connection to the
high flow NEXT.
12.1. 12.1.

12.1. Manual profile selection

12.1. Manual profile selection Manual profile selection Manual profile selection
Select the profile to be activated by clicking the corresponding button.
12.2. 12.2. 12.2.

12.2. Automatic profile selection

Automatic profile selection Automatic profile selection Automatic profile selection
Profiles can be activated automatically using the global profiles feature of the
aquasuite, see chapter 14.2. for details.
