- Page 1 One Revolution Tube Cutter Series 9060 Tube & Pipe Cleaners Tube Testers Tube Plugs Tube Removal Tube Installation Operating and Maintenance Instructions www.elliott-tool.com...
-
Page 3: Table Of Contents
Table Of COnTenTs Introduction ......................4 General Information ....................5 Operation Instructions ..................6 Parts List ......................7 Adjustment & Repair .................... 9 Warranty ......................10... -
Page 4: Introduction
InTRODUCTIOn Thank you for purchasing this Elliott product. More than 100 years of experience have been employed in the design and manufacture of this control, representing the highest standard of quality, value and durability. Elliott tools have proven themselves in thousands of hours of trouble-free field operation. -
Page 5: General Information
For the proper function of the one-revolution tube cutter it is important to select and use the correct cutter for the tube size being punctured or cut. Refer to the chart on page 7 of this manual, your Elliott catalog or the Elliott Product Selection CD for size options. -
Page 6: Operation Instructions
OPeRaTIOn InsTRUCTIOns After selecting the proper one-revolution cutter for the tube being punctured or cut, follow the steps below. 1. Determine the distance down tube you wish to make the cut. Using a 3mm allen wrench, loosen the set screw (item 5 diagram 1, pg 9) and slide the collar (item 4 diagram , pg 9) to the desired setting to a maximum depth of 6”. -
Page 7: Parts List
PaRTs lIsT Tube OD Range body OD Cutter Part # Cutter Cutter blade Collar screw 1 screw 2 Drive Inch Inch 6” Reach 12” Reach 3/8” 0.272 9060-050 9060N375-1 9060P5 9060-050-4 128CB 7/32” 18-19 0.394 10.0 9060-100 9060-100-12 9060-100-4 1/2” 12.7 9060N500-1 5/16”... - Page 8 PaRTs lIsT Tube OD Range body OD Cutter Part # Cutter Cutter blade Collar screw 1 screw 2 Drive Inch Inch 6” Reach 12” Reach 1.713 43.5 9060-435 9060-435-4 1.740 44.2 9060-442 9060-442-4 12-13 1.760 44.7 9060-447 9060-447-12 9060-447-4 2” 50.8 9060N1500-1 9060P3...
-
Page 9: Adjustment & Repair
aDjUsTmenT & RePaIR Replacing a cutter bit. 1. Using an allen wrench, loosen the set screw (item 6) that secures the cutter pin. NOTE: Tube Cutter models 9060-190 and below use a 5/64 allen wrench & Tube Cutter models 9060-193 and above use a 1/8 allen wrench. 2. -
Page 10: Warranty
WaRRanTy Should any part, of Seller’s own manufacture, prove to have been defective in material or workmanship when shipped (as determined by Seller), Seller warrants that it will, at its sole option, repair or replace said part f.o.b., point of manufacture, provided that Buyer notifies, in writing, of such defect within twelve (12) months from date of shipment from the manufacturing plant. - Page 12 Contact Us Elliott Tool offers a complete line of precision tube tools to meet your needs. Locally Supported By: Contact us or your local support. Elliott Tool Technologies, Ltd. 1760 Tuttle Avenue Dayton, Ohio 45403-3428 www.elliott-tool.com/support Phone: +1 937 253 6133 • +1 800 332 0447 Fax: +1 937 253 9189 www.elliott-tool.com...
