Kintech Engineering Geovane Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Guide
LAST UPDATE | 09.10.2020
TM
Geovane
FOR THE PRECISE MEASUREMENT OF THE TRUE NORTH
Get the most accurate wind direction measurement available today
Determine the yaw alignment of wind turbines (True North orientation)
Allows for veer measurement (IEC61400.12.1, 2017)
Very low power consumption: suitable for remote stations

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Geovane Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kintech Engineering Geovane Series

Summary of Contents for Kintech Engineering Geovane Series

  • Page 1 User’s Guide LAST UPDATE | 09.10.2020 Geovane FOR THE PRECISE MEASUREMENT OF THE TRUE NORTH Get the most accurate wind direction measurement available today Determine the yaw alignment of wind turbines (True North orientation) Allows for veer measurement (IEC61400.12.1, 2017) Very low power consumption: suitable for remote stations...
