Operating Motion Sensor

Sensitivity Description
H High. In this setting, the sensitivity is the highest. The fixture will illuminate when the motion sensor
detects motion within 3 - 30 ft from the motion sensor.
M Medium. In this setting, the sensitivity is average. The fixture will illuminate when the motion sensor
detects motion within 3 - 15 ft from the motion sensor.
L Low. In this setting, the sensitivity is the lowest. The fixture will illuminate when the motion sensor
detects motion within 3 - 5 ft from the motion sensor.
Mode Timer Switch
Stand-by Test, 2, or 6
Auto 2 or 6
Detection
Test Test
Manual N/A
Override
with Auto
Reset
Dusk-to- D-D
Dawn
Description
This is the initial state. If you have turned off the power for a long period of time and then
restore power to the fixture, the light will illuminate and remain illuminated for
approximately 20 seconds regardless of motion. Then it enters the Auto Detection Mode
or Test Mode based on the setting of the Timer switch.
This is the normal motion detection mode. The motion sensor illuminates the light
automatically after sensing movement in the coverage area at dusk and stays on as long
as motion is detected. When motion stops, the light remains on for either 2 minutes or 6
minutes (as set on Timer Switch) and then automatically turns off.
This mode allows you to adjust the sensitivity of the motion sensor to a desired level at
dusk or dawn. When motion stops, the light will turn off in about 5 seconds.
This mode allows you to keep the fixture illuminated for about 8 straight hours. The
manual override mode only works at night (when the outside light intensity level is below
20 Lux). To activate the feature, turn the wall switch off then back on within 2 seconds.
After 8 hours, the fixture resets itself back to Auto Detection Mode.
In this mode, the light turns on at dusk and off at dawn automatically, regardless of the
presence of motion. The "D-D" setting ensures lights are non-operational in daylight and
only function at night. To activate, set the Timer switch to the "D-D" position.
