- Page 1 Display Module Door Station Operating Manual with 2-wire QwikBUS Technology DBM40 (Translation of the original instructions)
- Page 2 Legal information Document Type: Operating Manual Product: Display Module Door Station with 2-wire QwikBUS Technology, DBM40 Target audience: Authorized technicians Language: English DocumentNumber_Version: Publication date: 08/2014 Publisher/Manufacturer STR Elektronik Josef Schlechtinger GmbH Auf dem Ohl 9, D-57482 Wenden, Germany © STR Elektronik Josef Schlechtinger GmbH Reproduction of this manual, in whole or in part, is permitted only with the written consent of Joseph Schlechtinger GmbH.
-
Page 3: Table Of Contents
Installation and wiring Safety instructions for installation and wiring Important information Wiring Installation Programming and operation General information Programming the device with DBM40 Editor Programming on the DBM40 Operation Errors Troubleshooting safety Error causes and troubleshooting Removal and disposal Removal safety... -
Page 4: General
CAUTIOn! This symbol/word combination indicates a potentially hazardous situation that could result in minor injury if not avoided. IMPOrTAnT! This symbol/word combination indicates important information that can help avoid physical or environmental damage. Operating Manual DBM40 - 08/2014... -
Page 5: Copyright
Germany), BGR (rules supplementing the BGV) and BGI (additional information regarding the BGV) were applied: > VDE 0100 > VDE 0800 > VDE 0805 > Health and safety regulations (VSG) > Accident prevention regulations (UVV) Operating Manual DBM40 - 08/2014... -
Page 6: Security
They must be able to provide proof of knowledge of the relevant safety standards, regulations and accident prevention rules and have read the manual. Operating Manual DBM40 - 08/2014... -
Page 7: Structure And Function
• a mini-CD containing the programming software and • these operating instructions. 3.2 Structure and function of DBM40 The Display Module Door Station consists of a 3.5 inch TFT display and three operating buttons. Fig. 1: Structure of the Display Module Door Station 3.5"... - Page 8 Operation via three buttons directly on the module Operation via external keypad (optional) Customizable background image (2.16 and 256 colors bitmap graphic, max. 320 x 180 pixels) Up to 500 entries in DBM40 256 colors (RGB332) Function The STR Display Module Door StationDBM40 provides access control and communication between the front door of a building and the residences or offices inside.
-
Page 9: Installation And Wiring
Use cable grips to prevent pulling. IMPOrTAnT! Possible damage to property from electrostatic charging! Electrostatic charging may cause devices to be destroyed through direct contact with printed circuit boards. Discharge yourself before touching the device. Operating Manual DBM40 - 08/2014... -
Page 10: Important Information
(transformers, contactors, etc.). Maximum cable lengths: Wire diameter in mm (AWG) Audio in m (ft) Video in m (ft) 0.6 (22) 150 (500) 75 (250) 0.8 (20) 300 (1000) 150 (500) 1.0 (18) 450 (1500) 225 (750) Operating Manual DBM40 - 08/2014... - Page 11 Installation and wiring Wiring diagramm DBM40 with TSMB-3 TSMB3 Reset DBM40-AM EEPROM DBM 40 Keyboard DBM40- back 12V~ Door opener can connect at TSMB3 SP333 or alternative Tö at TSMB-3 (DIP-3 „ON“) TSMB-3 back TSMB3-AM Tö Keyboard (optional)
- Page 12 Installation and wiring Wiring diagram DBM40 with TT33-3 TSMB3 Reset DBM40-AM EEPROM DBM 40 Keyboard DBM40 back DBM40/TT TT33-3 12V~ Door opener can connect at SP333 or alternative at TSMB-3 (DIP-3 „ON“) 12V~ TT33-3 back Tö Keyboard (optional)
-
Page 13: Installation
Installation and wiring 4.4 Installation Fig. 5: Installation of DBM40 in the Varoflex module system > Insert the 6-pin connector for connecting to the TSMB3 or TT33-3 (adapter required). > Connect the power supply (12 VAC) to the TSMB3-AM. Operating Manual DBM40 - 08/2014... -
Page 14: Programming And Operation
5.2 Programming the device with DBM40 Editor The DBM40 Editor can be used to fully manage the display. All settings as well as the database can be stored in a so-called project file and re- opened later. Data can be uploaded to the DBM40 via a USB connection (USB adapter required) or an SD/SDHC card. - Page 15 The memory entry number is preassigned by the system. It corre- sponds to a memory entry on the intercom. If alphabetical sorting is turned off on the DBM40, the entries will ap- pear on the device screen in order by their memory entry number.
- Page 16 The door code can be entered while the device is on standby by first pressing the C key on the external keypad. The DBM40 will then ask you to enter the door code. To keep bystanders from seeing the code, shortly after each key is pressed, the number is replaced by an *.
- Page 17 Special Entries • Up to three Special Entries may be stored on the DBM40. These entries will appear at the top of the list (regardless of whether alphabetical sorting is activated). For example, if you want "Main Office" to always be listed first, you can make Main Office a Special Entry.
- Page 18 Up to 256 colors can be displayed on the device screen. The user can adjust three color settings: Selected entry color Text color Background color Each color can be adjusted via the slider or color chart. Operating Manual DBM40 - 08/2014...
- Page 19 Database, Configuration and Image. Fig. 9: Data synchronization read Database [USB] • This button establishes a USB connection to the DBM40 and reads the entries from the database. Send Database [USB] • This button establishes a USB connection to the DBM40 and overwrites the existing entries on the DBM40 with the entries from the DBM40 Editor.
- Page 20 This button reads the database, configuration and standby image for the DBM40 from an SD/SDHC card. However, you must first synchro- nize the card with the DBM40. You can do this from the Service menu on the DBM40 under "Manage Database."...
-
Page 21: Programming On The Dbm40
Fig. 10: Rear view of the DBM40 with Reset button reset > Press the button while restarting the device. The DBM40 will remain in standby mode for a brief time after being restarted. reset > Press the button a second time. - Page 22 To apply the new color, select the "Save and Restart" button on the Service screen. Manage Database You can manage the database directly on the DBM40. All fields except "Personal Information," "Unit Information," and "Door Code" can be altered. Manage Database >...
-
Page 23: Operation
If you delete the entire name and select "Save," the memory entry will be deleted. 5.4 Operation Once plugged in, the DBM40 will start and system information will be displayed. A default background image will appear with the word "Welcome" in the default local language. - Page 24 "B" will be shown. The unit number may be displayed after each entry if desired. This feature can be deactivated via the Service menu or DBM40 Editor. > Select an entry from the list by using the Up and Down keys.
-
Page 25: Errors
The following tables provide an overview of the most common problems and how to solve them: Error Cause Solution External keypad Cable/plug is loose Check cables and plugs does not respond on the DBM40 External keypad is defec- Replace the keypad tive Operating Manual DBM40 - 08/2014... -
Page 26: Removal And Disposal
> Remove all components of the Indoor Video Station. > Turn the power back on. 7.3 Disposal Unless a return or disposal agreement is in place, dispose of the disassem- bled components in a reusable manner: > Scrap metals > Recycle plastic items. Operating Manual DBM40 - 08/2014... -
Page 27: Technical Information
Technical information Technical information 8.1 Display Module Door Station DBM40 Display Module Door Station Unit DBM40 General Information Power usage on standby (approx.) Power usage in operation (approx.) Weight (approx.) g (lbs) 150 (0.33) Optimal installation height cm (ft) 150 (5) -
Page 28: Appendix
The LT2 output is triggered by pressing the lighted button/round button inside the home. The output voltage for all outputs (TÖ and LT) is 12 V AC 1 A for approxi- mately 1.5 seconds. The tripping time for TÖ1 - TÖ4 varies (see separate instructions). Operating Manual DBM40 - 08/2014... - Page 29 Secondary voltage: 1 x 12 V AC / 1.6 A; 1 x 8 V AC / 1.6 A Mounting width: 107 mm / 6 HP Fuse F1 (primary): T80 mA, Fuse F2 (secondary): T630 mA Operating Manual DBM40 - 08/2014...
- Page 30 Operating Manual DBM40 - 08/2014...
- Page 31 Operating Manual DBM40 - 08/2014...
- Page 32 STR Elektronik Josef Schlechtinger GmbH Auf dem Ohl 9 D - 57482 Wenden Telefon : +49 (0)2762-9316-0 Telefax : +49 (0)2762 -9316-18 E-mail : info@str-elektronik.de Internet : www.str-elektronik.de...
