Features; Configuration; Releasing - FireFlex Systems Inc. N2 BLAST Owner's Operation & Maintenance Manual

1.5 FEATURES

Trouble-free design for safe and easy application
Available in 2 cabinet sizes
Uses South-Tek N
Best value in nitrogen generation technology
Limits the liability of early pipe replacement
Significant cost savings by using black pipe in
combination with nitrogen
Uses the Viking deluge valve
Trim is fully assembled and tested at the factory
All trims are galvanized steel, Listed and
Approved for
maximum
Quick connections to water supply and drain on
left side, and sprinkler riser on top of unit, all
available with grooved end or flanged fittings
No open drain cup inside unit
Separate unlocked access hatch to emergency
manual release
Available with or without an integrated release
control panel
Compact, aesthetic and easy to move
User-friendly standardized owner's manual with
every unit
Unique serial number on every unit
Uses UL, ULC and/or FM Approved components
Designed in accordance with NFPA Standards
Sturdy 14 gauge steel cabinet painted fire red with
oven baked polyester powder on phosphate base
Textured rust proof finish
Neoprene gasket on all doors to eliminate
vibrations
Key-alike locks on all cabinet doors
Manufactured under ISO-9001 quality control
procedures
Page 2 of25
F F
IRE LEX
Integrated Fire Protection System
O ' O
WNER S PERATION
®
Blast
2
250 psi (1724 kPa) service
® ®
N B
LAST
2
& M M
AINTENANCE ANUAL

1.6 CONFIGURATION

®
F F N Blast
IRE LEX
2
the Viking trim using straight through deluge valves
Model F-1.
All the valves are rated up to a maximum of 250 psi
WWP (1724 kPa) max. and are available in the
following diameters:
1½" (40 mm)
4" (100 mm)
®
F F N Blast
IRE LEX
2
with groove–groove
flange/flange deluge valves are also available on
request.
The Nitrogen generator is a N
or FPS-750system, made by South-Tek Systems.

1.7 RELEASING

Release trim for the double interlocked preaction
system with electric / pneumatic release utilizes a
normally closed solenoid valve (F1) controlled by the
Viking VFR-400 integrated control panel with a
compatible detection system (supplied by others) and a
pneumatic actuator (F3) normally held closed by
supervisory air pressure maintained in the sprinkler
piping.
In fire condition, when the detection condition is fulfilled,
the control panel energizes the solenoid valve (F1) and
an open sprinkler releases the supervisory air pressure
from the sprinkler piping. Both the electric detection
condition and supervisory pressure relieved from the
sprinkler piping are necessary before the deluge
valve (A1) will open and fill the sprinkler piping with
water. Water will flow from any opened sprinklers in the
system piping.
®
Preaction systems are built around
2" (50 mm) 3" (80 mm)
®
Preaction systems are supplied
deluge valves. Units
®
Blast Type 1 FPS-250
2
FM-076B-0-6A
with
