FireFlex Systems Inc. N2 BLAST Owner's Operation & Maintenance Manual page 25

Figure 5.3 – Air supply Style "A"
(Cabinet mounted air compressor)
TO PNEUMATIC ACTUATOR
(plugged when not used)
Air option components:
E1 Air compressor
E2 Air compressor "Cut-off" pressure switch
E3 System air pressure gauge
E4 Air supervisory pressure switch
E9 Float check valve
FM-076B-0-6A
F F
IRE LEX
Integrated Fire Protection System
O ' O
WNER S PERATION
E1
This section replaced
by Dehydrator option A
(when used)
E4
(plugged with
SureFire trim)
E10
E9
E2
3
E3
® ®
N B
LAST
2
& M M
AINTENANCE ANUAL
E11
Copper tubing
TO OPTIONAL ACCELERATOR
(plugged when not used)
E12
2 TO DRAIN COLLECTOR
1
TO SPRINKLER RISER
CONTRACTOR'S
HYDROSTATIC TEST PORT
(system side)
E10 Soft-seat check valve
E11 Air compressor check valve
E12 Air option drain valve
E13 Air supply accumulator
E15 Compressor isolating switch (not shown)
FM-061H-0-118B
Page 21 of 25
