These numbers are required for warranty and replacement
parts purposes.
8f. RECORDING YOUR KEY NUMBER
Your Battery Pack Keys have numbers stamped into them.
The number is on one side of the silver key just below the
black plastic cap. Record your key number here:
Key Number _________________________________ .
If you should lose your keys or need a replacement you will
need this number. Your bike has no other markings to iden-
tify your keys.
8g. BATTERY REPLACEMENT
When the time comes to replace your battery pack please
see your Merida dealer or contact EWI. Mail your warranty
registration card to EWI within 30 days from purchase date
Feature
Tig-welded Aluminum Frame
SR Suntour Suspension Fork
Lead Acid Battery (18.75 lbs.)
NiMH Battery (10.25 lbs.)
DC24-volt 400 Watt Peak Output Motor
Charger (115/230 volt) off-board
Alex Alloy Rims with Stainless Spokes
Aluminum Adjustable Bar/Stem
Shimano Nexus 4 Speed Hub/Shifter
Kalloy Suspension Seatpost
Comfort Spring Saddle
Front/Rear Generator Lights
Two Foot Kickstand
Rear Rack / Full Fenders
Front Basket (2.5 lbs.)
Quick Release Seatpost Clamp
All Weather Tires 26" x 1.50"
Tektro Direct Pull Brake, Front
Shimano Roller Brake, Rear
Weight (without battery & basket)
Approximate Range Lead Acid
Approximate Range NiMH
Top Speed (Assisted)
Approximate Charge Time - LA
Approximate Charge Time - NiMH
Maximum Load
Tire inflation pressure
Page 26
(figure 41 A)
500 550 550 LTD
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
47 lbs 47 lbs
19 miles 19 miles 19 miles
24 miles 24 miles 24 miles
15 mph 15 mph 15 mph
4/10 hours 4/10 hours 4/10 hours
2.5/7 hours 2.5/7 hours 2.5/7 hours
240 lbs 240 lbs
40-65 psi 40-65 psi 40-65 psi
and you qualify for a 10% discount on Merida battery re-
placements after the warranty period ends.
8h. RECORDING YOUR DEALER INFORMATION
You may need this information for future reference.
Dealer Name: ___________________________________
Address: _______________________________________
City: ___________________________________________
State ______________ Zip: ________________________
Telephone: _____________________________________
Email: _________________________________________
Contact: _______________________________________
8 i. SPECIFICATIONS
Benefit
X Light, Rust Proof, Durable
X Added Comfort & Control
X Good Range, Low Replacement Cost
X Lighter, Longer Range, Quicker Recharge
X Direct Drive, Good Climbing Power
X Transportable, Works everywhere you go
X Rust Proof, Sturdy, Light
X Allows Custom Fit for maximum comfort
X No Exposed Gears, Smooth, Precision Shifting
X Added Shock Absorption - Adjustable
X Ride Longer, Smoothes Out the Bumps
X No Batteries Required
X Sturdy and Stable
X Carry Cargo and Keep Clean
Great for running errands
X Allows fast, easy seat height adjustment
X Durable, Comfortable, Low Rolling Resistance
X Quality Brakes from top brands
49 lbs Not bad for a bike with a motor!
Range Exceeds Most Electric Bicycles
Range Exceeds Most Electric Bicycles
Automatically Delivers Power When You Need It
1st number 90% charge. 2nd number 100%
1st number 90% charge. 2nd number 100%
240 lbs Strength you can rely on
Best performance @ 60 - 65 psi
