DC800
EN
Technical specifications
Power supply:
12 - 24V AC/DC.
Power consumptions:
50 mA.
Temperature range:
-35° - +50° C.
Dimensions:
140 x 80 x 40 mm (hxwxd).
DE
Technische Daten
Stromversorgung:
12 - 24V AC/DC.
Stromverbrauch:
50 mA.
Temperaturbereich: -35° - +50° C.
Maße:
140 x 80 x 40 mm (hxbxt).
M43
Installation Note
EN
SV
FRAME
DC22
14
15
DC12
18
19
F
A
DE
FR
D
E
5
11
+V
12
0V
Tx
13
Rx
14
SV
Tekniska data
Strömförsörjning:
12 - 24V AC/DC.
Strömförbrukning:
50 mA.
Temperaturområde: -35° - +50° C.
Mått:
140 x 80 x 40 mm (hxbxd).
FR
Données techniques
Alimentation :
12 - 24V AC/DC.
Consommation
50 mA.
électrique :
Variation de
-35° - +50° C.
température :
Dimensions :
140 x 80 x 40 mm (hxlxp)
80745-4
06-08
B
ENTRY
EXIT
12-24 V
1
0V
2
C
3
D
4
M43
C
