Kramer WP-872xr Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
WP-872xr HDMI 4K Line Receiver
Installation accessories
1 Power adapter (with open DC head) and cord
Step 2: Get to know your WP-872xr
US-D Version
Front
# Feature
TM
1 HDMI OUT Connector
2 STATUS LED
3 Ring Tongue Terminal Grounding
Screw
4 Power Supply 2-pin Terminal Block
Connector
5 DGKat-2.0 IN RJ-45 Connector
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
WP-872xr Quick Start
WP-872xr Quick Start Guide
This guide helps you install and use your WP-872xr for the first time.
Go to www.kramerav.com/downloads/WP-872xr
upgrades are available.
EU/UK Version
Front
Function
Connects to an HDMI acceptor.
Lights green when power is connected to the device.
Lights blue when powered and both active source and acceptor are detected.
Connect to grounding wire (optional).
To connect to a power supply (if required). Connect GND to GND, +12V to +12V.
Connect to the DGKat-2.0 OUT connector on the transmitter using CAT 6A cable.
to download the latest user manual and check if firmware
1 Quick start guide
Frame (or frame set) and faceplate
US-D/EU/UK Version
Rear
P/N: 2 9 0 0 - 3 0 1 2 2 6 QS Rev: 3
